 39   Mode: Auto-Step # Steps: 10 > Up/Down to start Change Sett ings  Pressing  the  UP  or  DOWN  button  starts  the  cap turing  process.   Here  is  the  sequence  (only  six  pictures  out …

6.2 100mmvs.TheOrchid

InthissetupexamplewehaveaCanon7D,EF100mmmacrolens,andofcourseStackShot.



Figure14‐StackShotOrchidSetup

TheStackShotcontrollercoordinatesthecameraposition,settlingtime,exposure(and

potentiallyexposurebracketing),andautomati creturnuponcompletion.Theoptionalauto‐

returnfeatureallowsadjustmentofthecamera’sparametersandlightingwitho uthavingtore‐

positionthecamera.

FortheOrchiditwasdecidedthat“AutoStep”mode beused(seesection3.7formoredetails).

“#Steps”wasadjustedto10steps(11pictures)which wouldresultinanoutstan dingfinal

stackedimage.

Mode: Auto-Step

> # Steps: 10

Select Start Pos



TheFWDbuttonwaspresseduntilthecamerareachedthedesiredstartingpointofthestack.

Picktheclosestobjectyouwantinfocusforthestackandmovethecamerasuchthatthisisin

sharpfocus.TheSELECTbuttonwasthenpressedtoacknowle dgethestartingposition.Then

theBACKbuttonwaspressedtomovethecameratotheendpointofthestack.Movethe

cameratothepointwherethefurthestawayelementinyourcompositionisinfocus.Againthe

SELECTbuttonwaspressedtoconfirmthefinalposition.Thedisplaythenshowedthe

following:



38



39



Mode: Auto-Step

# Steps: 10

> Up/Down to start

Change Settings



PressingtheUPorDOWNbuttonstartsthecapturingprocess.



Hereisthesequence(onlysixpicturesoutofelevenshown):



Figure15‐OrchidSequence


