 8    3.3 Global  Configuration  To  enter  StackShot ’s  Global  Configuration ,  quickly  press  and  release  the  CONFIG  button.  The  display  will  change  and  list  the  available  use…



7



3. Operation

3.1 Overview



Withmacrophotographyalltoooftenpictureshaveashallowdepthoffield(DOF).Thisis

whereStackShot(andwidelyavailablefocus‐stackingsoftware)shine.StackShotallowsprecise

controloveracamera’spositionintendedforusewithmacrophotography.Itautomatesthe

processoftakingseveralpicturesinincrementalsteps.Thesubsequentimagesarethen

processedbyfocus‐stackingsoftwaretomergetheshallowDOFimagesintoasinglecrispand

highlydetailedpicture.Whilethissameprocesscanbeaccomplis hedmanually,gettingprecise

stepsisdifficult,timeconsuming,andfrustrating.Decreasingthetimespenttakingtheimages

alsoallowsyoutofocus‐stackthingsthatjustwouldn’tcooperateorstaystilllongenough.By

combiningasimpleuser‐interfacewithbehind‐the‐scenesextremeflexibility,StackShotisa

necessityforanyseriousmacrophotographer.



CAUTION:Alwayskeepyourbody,cables,andequipmentclearoftherailwhileitisinmotion.

Beawareoftheenvironmentyouareoperatingin.Thecenterofgravitywillchangeas

StackShotmovesthecamera.Movingtherailcanpotentiallycauseatippinghazard.Besure

thatyourtripodissecuredandbalancedproperlytopreventdamagetoequipment.Monitor

yourcamera,lens,andotherequipmentatalltimeswhile therailismovingtopreventdamage

toyourequipment.Themotorcablemayposeasatrippinghazard.Usecaution.



3.2 TheUserInterface



TherearesevenbuttonstocontrolStackShot.



TheSELECTbuttonmovesthecursor(“>”indicator)fromlinetolineonthedis play.TheUPand

DOWNbuttonadjustthevaluesforeachline.CONFIGwilldisplaya(lengthy)listofuser‐

specifiedconfigurations.FWDmanuallymovesthemotorassemblyforwardwhileBACKmoves

itbackward.SHUTTERwillmanuallyfiretheshutteronthecamera.



Note:Ifthemotorismovingorasequenceisactive,anybuttonpresswillstopthemotor

immediatelyandaborttheactivesequence.



Usersettingswillbesavedacrosspowercycles.



Thedifferentmodesofoperationarelistedinthefollowingsections.



8



3.3 GlobalConfiguration

ToenterStackShot’sGlobalConfiguration,quicklypressandreleasetheCONFIGbutton.The

displaywillchangeandlisttheavailableuserconfigurations.Toreturntothemainscreenpress

theCONFIGbuttonagain.Thedifferentconfigurationoptionsarediscussedbelow.Allof

thesesettingsaremaintainedwhenusingthe“Load/SaveSettings”option.Thisprovides

maximumflexibilityand easeofuse.Thelastsettingsusedarealsoretainedoverapowercycle

foryourconvenience.



3.3.1 PicturesperStep

StackShotdefaultstoone pictureperstep.Youmay,however,increasethenumberof

pictures(“#pics”)takenateachstep.Thisgivesyoutheoptionofdoingexposure

bracketing,mirrorlockup,orothercameraeffects.Validvaluesarefrom1–1000.Thisis

notthetotalnumberofpicturestaken–justhowmanyateachstep.



== Global Config ==

> # pics: 1

Tsettle: 500.0 ms

Toff: 500.0 ms ->



SeeFigure2belowforatimingdiagramwith“#pics”setatthree.



Figure2‐PicturesperStep



3.3.2 SettleTime

AfterStackShotfinishesmoving,itmaybedesirabletohaveitwaitforthemotor

assembly/camera/tripodtostopmovingpriortotakingapicture.Youmayadjustthis

settlingtime(“Tsettle”)toforcethedesireddelay.



== Global Config ==

# pics: 1

Tsettle: 500.0 ms

Toff: 500.0 ms ->



9



Figure3belowshowswherethesettlingtimetakesplace.



Figure3‐SettleTime



3.3.3 TimeOffBetweenPictures



Timeoff(“Toff”)isthetimebetweenmultiplepictures.Thisonlyapplieswhenthenumber

ofpictures(“#pics”)isgreaterthanoneunlesstheoperatingmodeissetto“Continuous”.

In“Continuous”mode,“Toff”isthetimebetweenpictures.



== Global Config ==

# pics: 3

Tsettle: 500.0 ms

Toff: 500.0 ms ->



Seebelowtodemonstratewhere“Tsettle”,“ Toff”,and“Tpulse”allcomeintoplaywhen

takingmultiplepictures.



Figure4‐TotalTimingDiagram
