Warning The machine should be moved wrapped in durable packing
materials and with covers for electrical protection.
The operator could be injured or the equipment could be
damaged if proper safety measures are not taken or the
equipment is operated at an improper location.
If the door switch was removed artificially, since the equipment
does not stop even though the door opens during operation, the
user may get injured. Do not remove the door switch artificially.
Never attempt to modify the equipment without prior consent of
Samsung Techwin Co., Ltd. or repairs it in a manner not stated in
this manual. Samsung Techwin Co., Ltd. is not responsible for
problems caused by machine repairs performed in a manner not
mentioned in this manual, or any modifications carried out without
prior approval
Be sure to turn off the power switch and then close the air-valve
before maintenance or repair. If it is not followed, personal
injuries could occur.
Checking the sensor or correcting an error while the equipment
status is 'READY' could result in personal injury.
Press the 'EMG' switch to release the 'READY' and perform
sensor adjustment and take measures against the error after
pressing the 'STOP' button.
The system infected by a virus could make the machine
malfunction and the damage by malfunction could occur.
We do not take responsibility for any damage to the data due to
infection by a virus. Therefore, perform a virus check periodically
to prevent the data from being infected by a virus.
Observe the cautions when using the USB memory. (Refer to "2.3
PC Specification" of the Introduction Manual)
Page
SAMSUNG TECHWIN
1
SM421
Contents
Mechanical Part
Fix Camera Ass’y ......................................................................... 3
Feeder Base Ass’y - ST................................................................ 5
Feeder Base Ass’y - DC ............................................................... 9
Conveyor Ass’y........................................................................... 15
Backup Table Ass’y .................................................................... 27
Base Frame Ass’y ...................................................................... 30
Fly Camera Ass’y ....................................................................... 32
Operation Ass’y .......................................................................... 35
Head Ass’y ................................................................................. 38
Air Ass’y...................................................................................... 55
X-Y Frame Ass’y......................................................................... 63
Fixed ANC Ass’y......................................................................... 70
Window Ass’y ............................................................................. 72
Cover Ass’y ................................................................................ 74
Control Rack Ass’y ..................................................................... 80
Electric Panel Ass’y .................................................................... 82
Electric Device Ass’y .................................................................. 87
Cable Ass’y................................................................................. 93
Electric Control Part
SM421 Wiring Diagram .............................................................. 98
SM421F Wiring Diagram ............................................................ 99
VME I/O Interface..................................................................... 100
Feeder Board Interface (Front, Rear )...................................... 101
Conveyor Board Interface ........................................................ 103
Head Illumination Board Interface ............................................ 108
Head I/O Board Interface ......................................................... 109
Axis Sensor Board Interface..................................................... 111
Servo Interface ........................................................................ 113
Step Motor Interface................................................................. 119
Vision BoardInterface ............................................................... 120
KVMS Board Interface.............................................................. 121
Safety Control Board Interface ................................................. 122
Electric Circuit Diagram............................................................ 125
Articles of Consumption
Articles of Consumption ........................................................... 138
