Page SAMSUNG TECHWIN 96 SM421 C able Ass’y NO. LEVEL P ART NO. P ART NAME Q'TY TYPE Old No. Stock Apply Reference 27 J9083136 7C FIX1 _ILL_IF_CABLE _ASSY 1 [1 16] at 100 page 28 J9083136 8B FIX2_IL L_IF_CABLE_A SSY …

100%1 / 148
Page
SAMSUNG TECHWIN
95
SM421
Cable Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
A-1 J91671154A SM421_HARNESS_ASSY J91671154A 1
1 J67020050C SOL VALVE MODULE 1
2 J70521025B SM330_LOWER_OP_PANEL 1
3 J32110015B Photoelectric Switch 2
4 J70540267B FRONT SENSOR BKT2 J70540267B 2
5 J70540266C FRONT SENSOR BKT1 J70540266B 2 J70540266B
6 J90831325B FFDR_RFDR_CAN_CABLE_ASSY 1 [103] at 101, 102 page
7 J90831049B FRONT_OP_SW_CABLE_ASSY 1 [150] at 121 page
8 J90831415C CONV_IF_KVMS_TBOX_CABLE_ASSY 1 [104] at 107 page
9 J90831321C KVMS-CONV-IF-CABLE-ASSY 1 [148] at 121 page
10 J90831050B REAR_OP_SW_CABLE_ASSY 1 [149] at 121 page
11 J90831314C AIR_INDICATOR_EXT_CABLE_ASSY 1 [105] at 104 page
12 J90831327B CVIF_FLAT_CAN_CABLE_ASSY 1 [106] at 103 page
13 J90831315C CONV_SOL_CABLE_ASSY 1 [107] at 103 page
14 J90831132C TOWER_LAMP_EXT_CABLE_ASSY 1 [108] at 104 page
15 J90831403C ANC_SENSOR_EXT_CABLE_ASSY 1 [109] at 105 page
16 J90831420C 1HEAD_AIR_SOL_PWR_CABLE_ASSY 1 [110] at 104, 107 page
17 J90831245D KVMS_MONITOR_FRONT_CABLE_ASSY 1 J90831245B [151] at 121 page
18 J91672891A FLAT-CABLE-ASSY SM41-FL001 1
19
20 J90831319B KVMS_FRONT-OP-IF-CABLE-ASSY 1 [154] at 121 page
21 J90831372C FRONT_TBOX_CABLE_ASSY 1 [111] at 121 page
22 J90831389B LAN_CABLE_ASSY SM41-VM011 1 [112] at 101 page
23 J90831144A SERIAL_COMM_CABLE_ASSY SM33-CV021 1 [113] at 107 page
24 J90831427C AXIS_VME_IF_CABLE_ASSY 1 [114] at 100, 112 page
25 J90831318C MASTER_FFDR_CAN_CABLE_ASSY 1 [115] at 101 page
26 J90831244B KVMS_MONITOR_MAIN_CABLE_ASSY 1 [155] at 121 page
Page
SAMSUNG TECHWIN
96
SM421
Cable Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
27 J90831367C FIX1_ILL_IF_CABLE_ASSY 1 [116] at 100 page
28 J90831368B FIX2_ILL_IF_CABLE_ASSY SM41-VI003 1 [117] at 100 page
29 J90831369B HEAD_VAC-BLOW_CONTROL_CABLE_ASSY SM41-VI 1 [118] at 100 page
30 J90831370C FIDUCIAL_CAMERA_CABLE_ASSY SM41-VIS001 1 J90831370B [156] at 120 page
31 J90831371B FIX1-2_CAMERA_CABLE_ASSY SM41-VIS002 1 J90831371A [157] at 120 page
32 J90831377C FLY_CAM_PWR_SYNC_CABLE_ASSY SM41-VIS007 1 [158] at 120 page
33 J90831379D FLY_CAM_SIG_CABLE_ASSY 1 [159] at 120 page
34 J90831387C HEAD_NETWORK_SERIAL_CABLE_ASSY 1 [119] at 115, 116 page
35 J90831246D KVMS_MONITOR_REAR_CABLE_ASSY 1 J90831246B [151] at 121 page
36
37 J90831320B KVMS_REAR-OP-IF-CABLE-ASSY 1 [160] at 121 page
38 J90831373C REAR_TBOX_CABLE_ASSY 1 J90831373B [120] at 121 page
39 J91841004A TBOX_IF_CABLE_ASSY-2 SM41-CV043 1 [121] at 121 page
40 J90831326B RFDR_CVIF_CAN_CABLE_ASSY 1 [122] at 102, 103 page
41 J90831343A MAIN-POWER-CABLE-ASSY SM41-PW001 1 [123] at 127 page
42 J90831353B COVER_FAN_CABLE_ASSY 1 [124] at 129 page
43 J90831316B CONV_SW_OUTPUT_CABLE_ASSY 1 [125] at 103 page
44 J90831136B CONV_SW_INPUT1_CABLE_ASSY 1 [126] at 106 page
45 J90831137B CONV_SW_INPUT2_CABLE_ASSY 1 [127] at 106 page
46 J90831146B SMEMA_CABLE_ASSY 1 [128] at 104, 107 page
47 J90831419B HEAD_AIR_SOL_CABLE_ASSY 1 [129] at 104 page
48 J90831428C CONVEYOR_SENSOR_IF_CABLE_ASSY 1 [130] at 111 page
49 J90831425D Y_AXIS_SENSOR_CABLE_ASSY 1 [131] at 111 page
50 J90831397B FEEDER_UNLOCK_LEFT_CABLE_ASSY 1 [132] at 112 page
51 J90831398C FEEDER_UNLOCK_RIGHT_CABLE_ASSY 1 [133] at 112 page
52 J90831399E FEEDER_UNLOCK_SENSOR_CABLE_ASSY 1 [134] at 112 page
53 J6702021A SOLENOID VALVE [K180-4E1-21-DC24V] 2 Only Indication
Page
SAMSUNG TECHWIN
97
SM421
Electric Control Part
