Page
SAMSUNG TECHWIN
52
SM421
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
107 J66021024A TIMING_BELT 232-2GT-4 3 SM421F Q'TY : 2EA
108 J6107044A SPRING[AWY 6-50] 2
109 J6049000250 WASHER WAVY 0.62OD*0.48ID*0.095HGT[SSR-0 6 SM421F Q'TY : 4EA
110 J71541085A HARNESS_PLATE J71541085A 1
111 J71541019A HEAD_BOARD_BRACKET J71541019A 1
112 J71541018B CABLEVEYOR_BRACKET 1
113 J71541016B HARNESS_SUPPORT 2
114 J70541125A HEAD_COVER_SUPPORT J70541125A 2
115 J70541124A CABLE_SPACER J70541124A 1
116 J70541015A CONNECTOR_PANNEL 1
117 J7054255A CUSHION BRACKET X[J7054255A] 1
118 J7054260A CABLE FIXER[J7054260A] 1
119 J7354023A CABLE CUSHION X[J7354023A] 1
120 J6119056A HANDLE BG-10 1
121 J6103003A HEX SUPPORT 4
122 J91741083C SM321_HEAD_IO_BOARD 1 J91741083B
123 J91741084B SM321_HEAD_ILL_BOARD 1 J91741084A
124 J91741085A SM321_HEAD_VACUUM_SENSOR_BOARD 1
125 J3204002A AIR PRESSURE SENSOR [MPX5100AP] 6 SM421F Q'TY : 4EA
126 J90550246F AIR MODULE 1 J90550246E
127 J71551001B MANIFOLD J71551001B 1
128 J7155544A FOOT BRACKET-L[J7155544A] 1
129 J7155545A FOOT BRACKET-R[J7155545A] 1
130 J7155546A INSERT[J7155546A] 6 SM421F Q'TY : 4EA
131 J67020048B SOLENOID VALVE VA01PEP34A-1U-F 6 J6702048A
Consumables (Replacement: 2 years)
132 J67081010A ATMOSPHERIC_FILTER LF-M3-Z07-021 6 SM421F Q'TY : 4EA
133 J6702049A SOLENOID VALVE[RCS242-M3-D24NP] 1
Consumables (Replacement: 2 years)
Page
SAMSUNG TECHWIN
53
SM421
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
134 J6703039A SPEED CONTROLLER[SPR-Z-M3N] 2
135 J6711262A MINI FITTING[BC-03-M5] 6 SM421F Q'TY : 4EA
136 J6711263A MINI FITTING[BE-04-M3] 2
137 J6711260A ONE TOUCH FITTING[FSE04-M5C] 2
138 J6711261A ONE TOUCH FITTING[FSC04-M5C] 6 SM421F Q'TY : 4EA
139 J6705009A SILENCER[AS-5] 1
140 J6712016A PLUG[N220 1900J] 1
141 J9058090A FILTER ASSY[J9058090A] 6 SM421F Q'TY : 4EA
142 J7458002A FILTER ELEMENT[LF-M5-60-Z-ELEMENT] 1
Consumables (Replacement: 6 months)
143 J7055662A VACUUM SENSOR BRACKET[J7055662A] 2
144 J1201033 HEX SUPPORT [M3*15 (BOLT-NUT)] 4
145 J90831395A Z6_MOTOR_ASSY 1 [29] at 116 page
146 J90831394A Z5_MOTOR_ASSY 1 [30] at 116 page
147 J90831393B Z4_MOTOR_ASSY 1 J90831393A [31] at 116 page
148 J90831392B Z3_MOTOR_ASSY 1 J90831392A [32] at 115 page
149 J90831391A Z2_MOTOR_ASSY 1 [33] at 115 page
150 J90831390A Z1_MOTOR_ASSY 1 [34] at 115 page
151 J90831010B R56_MOTOR_CABLE_ASSY 1 [35] at 118 page
152 J90831009B R34_MOTOR_CABLE_ASSY 1 [36] at 118 page
153 J90830190B R12_MOTOR_CABLE_ASSY 1 [37] at 114, 118 page
154 J9060404A HEAD SIDE LED ASSY[SM21-HEAD-SIDE] 1 [38] at 108 page
155 J90831437C R_STEP_MOTOR_PWR_CABLE_ASSY SM41-MD011 1 [39] at 118 page
156 J9083185A SW HOME SENSOR CABLE ASSY[SM21-HD014] 1 [40] at 109 page
157 J9083184A R HOME SENSOR CABLE ASSY[SM21-HD013] 1 [41] at 109 page
J90611788A R_HOME_SENSOR_CABLE_ASSY SM421F-HD013 1 [41] at 109 page
158 J9083180A Z HOME SENSOR CABLE ASSY[SM21-HD008] 1 [42] at 109 page
J90611787A Z_HOME_SENSOR_CABLE_ASSY SM421F-HD008 1 [42] at 109 page
Page
SAMSUNG TECHWIN
54
SM421
Head Ass’y
NO. LEVEL PART NO. PART NAME Q'TY TYPE Old No. Stock Apply Reference
159 J9083179A SIDE ILL U/D SENSOR CABLE ASSY[SM21-HD00 1 [43] at 109, 110 page
160 J90831307A R-AUX-SENSOR-CABLE-ASSY SM41-HD005 1 [44] at 109 page
J90611790A R_AUX_SENSOR_CABLE_ASSY SM421F-HD005 1 [44] at 109 page
161 J90600403C FIDUCIAL OUTER LED ASSY SM21-FIDU-OUTER 1 J90600403B [45] at 108 page
162 J90600402B FIDUCIAL INNER LED ASSY 1 J9060402A [46] at 108 page
163 J90830177B SIDE ILL UP/DN SOL CABLE ASSY SM21-HD002 1 [47] at 109 page
164 J90831378F FLY_CAM_SIG_EXT_CABLE_ASSY 1 [136] at 120 page
165 J90831376B FLY_CAM_PW_SYNC_EXT_CABLE_ASSY 1 [161] at 120 page
166 J90831375A FLAT_FIDUCIAL_CAM_CABLE_ASSY SM41-VIS005 1 [162] at 120 page
167 J90830173B HEAD SIDE/OUTER ILL CABEL ASSY 1 [48] at 108 page
168 J90830183C HEAD BLOW SOL CABLE ASSY 1 [49] at 110 page
169 J90830182C HEAD VAC SENSOR CABLE ASSY 1 [50] at 110 page
170 J90831308B HEAD VAC SENSOR CABLE ASSY 1 [43] at 109, 110 page
171 J90831033C HEAD_IO-ILL_POWER_CABLE_ASSY 1 [48] at 108 page
172 J90831031C HDIO-HILL_CAN_CABLE_ASSY 1 [51] at 108, 109 page
173 J90611788A R_HOME_SENSOR_CABLE_ASSY SM421F-HD013 1 SM421F
174 J90611787A Z_HOME_SENSOR_CABLE_ASSY SM421F-HD008 1 SM421F
175 J90611790A R_AUX_SENSOR_CABLE_ASSY SM421F-HD005 1 SM421F
