INSTRUCTION MANUAL
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
DT100
Box with Accessories for DT530
2
Packing List
The following items are included:
This manual corresponds to the following reference:
DT100
Manual ..................................................... 1 unit
Ref. 0033506
Glass Solder-Collector* .................. 2 units
*available as ref. DT20
(ref. contains 2 collectors)
Metal Box with Accessories* ............ 1 unit
Ref. DT100 - incl. the listed accessories:
*Also available:
JBC Metal Box for Accessories
Ref. BX20 - without accessories
Heat-Resistant Gripper ..................... 1 unit
Ref. DT60
Metal Solder-Collector* .................. 2 units
*available as ref. DT25
(ref. contains 2 collectors)
3
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Metal-Sheet
Prefilter* ....................... 2 units
*available as ref. DT12
(ref. contains 10 prefilters)
Paper Prefilter* ......... 10 units
*available as ref. DT13
(ref. contains 10 prefilters)
Tip Cleaning Rods ....... 1 unit
Ref. CL5970
Spanner .......................... 1 unit
Ref. DT50
Helical
Tip-Cleaning Rods ........ 1 unit
Ref. CL5760
Metal Brush* ................ 1 unit
Ref. CL6217
Wool Filter* ................ 10 units
*available as ref. DT10
(ref. contains 10 wool filters)
Brass-Wool
Prefilter* .................... 10 units
*available as ref. DT11
(ref. contains 10 prefilters)
Cleaning Brush ............. 1 unit
Ref. CL8297
Precision Allen
Screwdriver 2.5 ............ 1 unit
Re f. 0 03 3474
Frontal Gasket* .......... 5 units
*available as ref. DT30
(ref. contains 10 gaskets)
Rearward Gasket* ..... 5 units
*available as ref. DT35
(ref. contains 10 gaskets)
