Cautions about overall electrical items
Once rats enter indoors or buildings, they easily get into machines. They may tear wirings and leave
excrement that can cause serious damage to machines.
If rats tear wirings, it may cause short circuits. And it could cause a serious problem to machines.
If rats leave excrement over printed circuits boards or bared cables, it will be carbonized and may cause
fire.
REFERENCE:
Below is an example we had fire from a board. (See the pictures below.)
You can see blue-green attached material on the burnt location.
When copper burns, Cuo (copper oxide II) is black and Cu2O (copper oxide I) is red. According to the
blue-green color, the attached material can be considered Copper hydroxide. By this fact, we suppose water
existed on the burnt location.
Blue-green
attachments
COUNTERMEASURE:
1．Keep the room clean, neat and organized.
2．Lock up the room with no openings.
If once rats came in;
3．Sprinkle rat repellent.
4．Catch rats with adhesive sheets. (Emergency countermeasure)
5．Hire an rat exterminator.
To prevent damage caused by rats, it is important to keep rats-free environment.
If already rats are in your space, exterminate them by using rat repellent or other ways as mentioned above.
5 Materials
5-1
5
Materials
Standard Accessories
Nozzle, Locate Pin, Pushup Pin, etc.
Replacement Parts
5 Materials
5-2
Standard Accessories
Part Name Part No. Qty. Remarks
PIN(O RING) LC1-M8911-10X 1 For inserting nozzle’s O-ring
ID SEAL TOOL, ASSY. LC1-M8903-00X 1 For affixing nozzle ID sticker
Signal Cable (Std.)
HNS. PRE-PROCESS
LG0-M56K0-10X
(1)
Signal Cable (Std.)
HNS. POST-PROCESS
LG0-M56K0-20X (1)
Signal Cable (SMEMA)
HNS.SMEMA - SMEMA
LG0-M56K0-00X (2)
Select the standard or SMEMA
spec.
WRENCH SET LG0-M89A3-00X 0 Hex. Wrench Set
SCREW DRIVER(-) LG0-M89A2-00X 0 Fine Blade Screwdriver
HANDLE LG0-M90B9-00X 1 Conveyor Handle
LENS CLEANER SET LG0-M89A4-00X 1
GREASE SILICON LG0-M89AB-00X 1 Silicone Grease
LCD MONITOR KGT-M5106-01X 1 CRT Display
KEYBOARD ASSY.(ENG) KW3-M5150-60X 1 Mini Keyboard (English)
PLATE,KEY BOARD LG0-M110G-01X 1
MOUSE KW3-M5169-04X 1
PAD,MOUSE LG0-M110P-00X 1
SEPARATOR,ASSY. LG0-M3418-01X 24
NEEDLE KV8-M8887-00X 1 For nozzle cleaning
SHEET,RUBBER LG0-M1102-20X 6
MANOMETER ASSY. LC1-M89A5-00X 1 Vacuum Gauge Set
PARAMETER FD 1
DATA FD 1
Support Pin（Matrix type）
PIN,PUSHUP (05)
LG0-M9901-00X
※
PIN,PUSHUP (08) LG0-M9902-00X
※
PIN,PUSHUP (10) LG0-M9903-00X
※
PIN,PUSHUP (12) LG0-M9904-00X
※
PIN,PUSHUP (16) LG0-M9905-00X
※
PIN,PUSHUP (20) LG0-M9906-00X
※
When the matrix clamp function
is provided, 8 pins of each type
(six types in total) or an arbitrary
48 pins are supplied as standard
accessory.
Support Pin (Magnet type)
PIN,MAGNET ASSY.
LG0-M9820-00X
※
When the magnet clamp
function is provided, 9 pins are
supplied as standard accessory.
