5 Materials
5-2
Standard Accessories
Part Name Part No. Qty. Remarks
PIN(O RING) LC1-M8911-10X 1 For inserting nozzle’s O-ring
ID SEAL TOOL, ASSY. LC1-M8903-00X 1 For affixing nozzle ID sticker
Signal Cable (Std.)
HNS. PRE-PROCESS
LG0-M56K0-10X
(1)
Signal Cable (Std.)
HNS. POST-PROCESS
LG0-M56K0-20X (1)
Signal Cable (SMEMA)
HNS.SMEMA - SMEMA
LG0-M56K0-00X (2)
Select the standard or SMEMA
spec.
WRENCH SET LG0-M89A3-00X 0 Hex. Wrench Set
SCREW DRIVER(-) LG0-M89A2-00X 0 Fine Blade Screwdriver
HANDLE LG0-M90B9-00X 1 Conveyor Handle
LENS CLEANER SET LG0-M89A4-00X 1
GREASE SILICON LG0-M89AB-00X 1 Silicone Grease
LCD MONITOR KGT-M5106-01X 1 CRT Display
KEYBOARD ASSY.(ENG) KW3-M5150-60X 1 Mini Keyboard (English)
PLATE,KEY BOARD LG0-M110G-01X 1
MOUSE KW3-M5169-04X 1
PAD,MOUSE LG0-M110P-00X 1
SEPARATOR,ASSY. LG0-M3418-01X 24
NEEDLE KV8-M8887-00X 1 For nozzle cleaning
SHEET,RUBBER LG0-M1102-20X 6
MANOMETER ASSY. LC1-M89A5-00X 1 Vacuum Gauge Set
PARAMETER FD 1
DATA FD 1
Support Pin（Matrix type）
PIN,PUSHUP (05)
LG0-M9901-00X
※
PIN,PUSHUP (08) LG0-M9902-00X
※
PIN,PUSHUP (10) LG0-M9903-00X
※
PIN,PUSHUP (12) LG0-M9904-00X
※
PIN,PUSHUP (16) LG0-M9905-00X
※
PIN,PUSHUP (20) LG0-M9906-00X
※
When the matrix clamp function
is provided, 8 pins of each type
(six types in total) or an arbitrary
48 pins are supplied as standard
accessory.
Support Pin (Magnet type)
PIN,MAGNET ASSY.
LG0-M9820-00X
※
When the magnet clamp
function is provided, 9 pins are
supplied as standard accessory.
5 Materials
5-3
Nozzle, Locate Pin, Pushup Pin, etc
Part Name Part No. Qty. Remarks
NOZ.N001 ASSY. LC1-M7701-00X
※
NOZ.N002 ASSY. LC1-M7703-00X
※
NOZ.N003 ASSY. LC1-M7705-00X
※
NOZ.N004 ASSY. LC1-M7707-00X
※
NOZ.N005 ASSY. LC1-M7709-00X
※
NOZ.N006 ASSY. LC1-M770B-00X
※
NOZ.N012 ASSY. LC1-M770D-00X
※
NOZ.N013 ASSY. LC1-M770F-00X
※
NOZ.N017 ASSY. LC1-M770H-00X
※
NOZ.N018 ASSY. LC1-M770K-00X
※
NOZ.N019 ASSY. LC1-M770M-00X
※
NOZ.N020 ASSY. LC1-M770P-00X
※
NOZ.N021 ASSY. LC1-M770S-00X
※
NOZ.N022 ASSY. LC1-M770U-00X
※
①Six arbitrary nozzle
assemblies are supplied as
standard accessory.
②One ID sticker and one
O-ring are supplied as spares for
each nozzle.
ID SEAL N001 LC1-M77D1-00X
ID SEAL N002 LC1-M77D2-00X
ID SEAL N003 LC1-M77D3-00X
ID SEAL N004 LC1-M77D4-00X
ID SEAL N005 LC1-M77D5-00X
ID SEAL N006 LC1-M77D6-00X
ID SEAL N012 LC1-M77D7-00X
ID SEAL N013 LC1-M77D8-00X
ID SEAL N017 LC1-M77D9-00X
ID SEAL N018 LC1-M77DA-00X
ID SEAL N019 LC1-M77DB-00X
ID SEAL N020 LC1-M77DC-00X
ID SEAL N021 LC1-M77DD-00X
ID SEAL N022 LC1-M77DE-00X
O RING LC1-M77A5-90X O-ring for nozzle
5 Materials
5-4
Part Name Part No. Qty. Remarks
Fixed Locating Pin
PIN,LOCATE(C30)
LG0-M990A-00X
PIN,LOCATE(D30) LG0-M990B-00X
PIN,LOCATE(C35) LG0-M990C-00X
PIN,LOCATE(D35) LG0-M990D-00X
PIN,LOCATE(C40) LG0-M990E-00X
PIN,LOCATE(D40) LG0-M990F-00X
Selection
Adjustable Locating Pin
PIN,SLIDE ASSY.(RC30)
LG0-M9910-00X
PIN,SLIDE ASSY.(RD30) LG0-M9911-00X
PIN,SLIDE ASSY.(LC30) LG0-M9916-00X
PIN,SLIDE ASSY.(LD30) LG0-M9917-00X
PIN,SLIDE ASSY.(RC35) LG0-M9912-00X
PIN,SLIDE ASSY.(RD35) LG0-M9913-00X
PIN,SLIDE ASSY.(LC35) LG0-M9918-00X
PIN,SLIDE ASSY.(LD35) LG0-M9919-00X
PIN,SLIDE ASSY.(RC40) LG0-M9914-00X
PIN,SLIDE ASSY.(RD40) LG0-M9915-00X
PIN,SLIDE ASSY.(LC40) LG0-M991A-00X
PIN,SLIDE ASSY.(LD40) LG0-M991B-00X
Selection
Support Pin (Magnet type)
PIN,MAGNET ASSY.
LG0-M9820-00X
See “Standard accessories”
List
PUSH UP-PIN,A (SPRING) LG0-M9900-30X Spring type
PUSH UP-PIN (MAGNET) LG0-M9900-60X Fixed type (slim)
PUSH UP-PIN (M-SPRING) LG0-M9900-70X Spring type (slim)
Support Pin（Matrix type）
PIN,PUSHUP (05)
LG0-M9901-00X
PIN,PUSHUP (08) LG0-M9902-00X
PIN,PUSHUP (10) LG0-M9903-00X
PIN,PUSHUP (12) LG0-M9904-00X
PIN,PUSHUP (16) LG0-M9905-00X
PIN,PUSHUP (20) LG0-M9906-00X
See “Standard accessories”
List
PCJ-1 LG0-M5C00-00X Set Master
FPS-1 LG0-M5D00-00X PF Presetter
