FOREIGN MACHINE INTERFACE MULTI-INTERFACE UNIT 28.28 Technical Reference Manu al Chapter Issue 3 Jan 08 SMEMA Logical T iming Diagram NOTES A board transfer occurs when a board is available (contact closed) and the machi…
FOREIGN MACHINE INTERFACE
MULTI-INTERFACE UNIT
Chapter Issue 3 Jan 08 Technical Reference Manual 28.27
SMEMA Interface
SMEMA Schematic
AMP
Connector
206044-1
AMP
Connector
206044-1
8
Shield
SMEMA
Downline
0V
15
25
+24V(A)
Upline
50 Way
D-type
M1SK1
Downline
50 Way
D-type
M1SK2
DEK
Multi-Interface Unit
Board Direction
SMEMA FMI Connection - Upline (SW2) and Downline (SW3) To Position 2.
Out
(24V) Link
In
2
17
Machine Ready (L)
3
1
Board Available (L)
4
2
Board Available (H)
1
9
Machine Ready (H)
Shield
4
8
Board Available (L)
0V
Machine Ready (H)
1
1
2
Machine Ready (L)
2
Out
In
(24V) Link
+24V(A)
25
15
3
Board Available (H)
26
17
SMEMA
Upline
FOREIGN MACHINE INTERFACE
MULTI-INTERFACE UNIT
28.28 Technical Reference Manual Chapter Issue 3 Jan 08
SMEMA Logical Timing Diagram
NOTES
A board transfer occurs when a board is available (contact closed) and the machine is ready (contact closed).
The Board Available signal and Machine Ready signal can occur at anytime, but board transfer does not occur
until both contacts are closed.
The Board Available signal remains closed until the board has left the machine.
The Machine Ready signal remains closed until the board has arrived at the next machine.
- Board Trailing Edge at Sensor
- Board Leading Edge at Sensor
A
B
SMEMA Downline Logical Timing Diagram
Downline M/C
(I/P to DEK M/C)
Board Not Available
Board Available
DEK M/C Belts Running
DEK M/C Output Sensor
DEK M/C
(O/P from DEK M/c)
Machine Ready
Machine Not Ready
A
B
SMEMA Upline Logical Timing Diagram
DEK M/C Input Sensor
Upline M/C
(I/P to DEK M/C)
Board Not Available
Board Available
DEK M/C
(O/P from DEK M/C)
Machine Ready
Machine Not Ready
DEK M/C Board At Stop Sensor
Board At Stop
Transfer Complete
< Transfer Period
< Transfer Period
< Transfer Period
< Transfer Period
Belt Overrun
DEK M/C Belts Running
A
B
DEK M/C Ready
FOREIGN MACHINE INTERFACE
MULTI-INTERFACE UNIT
Chapter Issue 3 Jan 08 Technical Reference Manual 28.29
SMEMA Upline Interface Cable
View on Arrow B
1
2
3
Pin 1 - Machine Ready (H)
Pin 4 - Board Available (L)
PIN 8 - Shield
4
8
B
PLB
A
PLA
DEK Machine
50 Way D-type
Pin 2 - Machine Ready (L)
Pin 17- Board Available (L)
(24V) Link
Pin 15 (IN) to Pin 25 (Out)
Pin 1 - Machine Ready (H)
View on Arrow A
Pin 26 - Board Available (H)
33
50
1
18
34
17
Pin 2 - Machine Ready (L)
Pin 3 - Board Available (H)
SMEMA Upline Plug
AMP 206044-1
