Do not move the assemblies near to data view devices, monitors or television units. Keep a min-
imum distance of > 10 cm to monitors.
2.9.4 Measurements and modifications to ESD modules
Do not take measurements on the modules unless the following conditions are fulfilled:
– the measuring device is earthed (e.g. via PE conductors) or
– you discharge the measuring head just before taking measurements with a potential-free
measuring device (e.g. by touching an unpainted metal part of the controller casing).
Always use an earthed soldering iron if you carry out any soldering work.
2.9.5 Dispatching ESD modules
Always store modules and components in conductive packaging (e.g. metallized plastic bags
or metal sleeves) and dispatch them in conductive packaging.
If the packaging is not conductive, place the modules in a conductive envelope before pack-
aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for ex-
ample. NEVER use plastic bags or film. 2
If the module has integral batteries, ensure that the conductive packaging does not touch or
short-circuit the battery terminals and, if necessary, first cover the terminals with insulating
tape or material.
User manual SIPLACE TX-Series 3 Technical data and assemblies
From software version 713.0 Edition 01/2020 3.1 Performance data
105
3 Technical data and assemblies
3.1 Performance data
3.1.1 Definition of placement performance
The placement performance is influenced by the different head combinations and head positions,
plus the conveyor configurations. Individual options and customized applications also influence
the placement performance. On request, SIPLACE can calculate the actual performance of your
product on your machine configuration.
IPC value [components/h]
Performed with 0402 components in accordance with the layout of the IPC 9850 standard from
the Association of Connecting Electronics Industries.
SIPLACE benchmark value [components/h]
The SIPLACE benchmark value is measured during the machine acceptance tests. It corresponds
to the conditions set out in the SIPLACE scope of service and supply.
3 Technical data and assemblies User manual SIPLACE TX-Series
3.1 Performance data From software version 713.0 Edition 01/2020
106
3.1.2 SIPLACE TX machine performance
3
Placement head types SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
For a definition of placement performance values, see section 3.1.1 on page 105.
SIPLACE TX2i placement
machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 67.000 78.000
CPP_L / C&P20 P
*a
55.000 63.000
CPP_L/CPP_L 43.600 48.000
CPP_H / CPP_H 41.000 45.000
SIPLACE TX2i W place-
ment machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 67.000 78.000
CPP_L / C&P20 P
*b
55.000 63.000
CPP_L/CPP_L 43.600 48.000
CPP_L / CPP_H 41.000 45.000
SIPLACE TX2 placement
machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 65.000 75.500
CPP_L/CPP_L 42.600 46.500
CPP_H / CPP_H 40.000 44.000
TH / CPP_H 25.000 28.500
SIPLACE TX1 placement
machine
Placement area IPC value Benchmark value
C&P20 P 32.500 37.500
CPP_H 20.000 22.000
TH 5.050 5.500
*)a Only from software version 710.1
*)b Only from software version 711.1
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
