3 Technical data and assemblies User manual SIPLACE TX-Series
3.1 Performance data From software version 713.0 Edition 01/2020
106
3.1.2 SIPLACE TX machine performance
3
Placement head types SIPLACE SpeedStar (C&P20 P)
SIPLACE MultiStar (CPP)
SIPLACE TwinStar (TH)
Placement performance
For a definition of placement performance values, see section 3.1.1 on page 105.
SIPLACE TX2i placement
machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 67.000 78.000
CPP_L / C&P20 P
*a
55.000 63.000
CPP_L/CPP_L 43.600 48.000
CPP_H / CPP_H 41.000 45.000
SIPLACE TX2i W place-
ment machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 67.000 78.000
CPP_L / C&P20 P
*b
55.000 63.000
CPP_L/CPP_L 43.600 48.000
CPP_L / CPP_H 41.000 45.000
SIPLACE TX2 placement
machine
Placement area IPC value Benchmark value
C&P20 P / C&P20 P 65.000 75.500
CPP_L/CPP_L 42.600 46.500
CPP_H / CPP_H 40.000 44.000
TH / CPP_H 25.000 28.500
SIPLACE TX1 placement
machine
Placement area IPC value Benchmark value
C&P20 P 32.500 37.500
CPP_H 20.000 22.000
TH 5.050 5.500
*)a Only from software version 710.1
*)b Only from software version 711.1
CPP_H = Multistar CPP in high assembly position
CPP_L = Multistar CPP in low assembly position
User manual SIPLACE TX-Series 3 Technical data and assemblies
From software version 713.0 Edition 01/2020 3.1 Performance data
107
3.1.3 SIPLACE TX micron machine performance
3
Placement head types SIPLACE SpeedStar (C&P20 M2)
SIPLACE MultiStar (CPP M)
Placement performance
For a definition of placement performance values, see section 3.1.1 on page 105.
SIPLACE TX2i micron placement
machine
Placement area IPC value Benchmark value
Placement accuracy 25 µm (3σ) C&P20 M2 / C&P20 M2 62.500 78.000
CPP M_L / CPP M_L 43.000 48.000
C&P20 M2 / CPP M_L 52.500 62.500
Placement accuracy 20 µm (3σ) C&P20 M2 / C&P20 M2 56.000 71.000
CPP M_L / CPP M_L 39.500 47.000
C&P20 M2 / CPP M_L 47.500 59.000
Placement accuracy 15 µm (3σ) C&P20 M2 / C&P20 M2 -- 64.000
SIPLACE TX2 micron placement
machine
Placement area IPC value Benchmark value
Placement accuracy 25 µm (3σ) C&P20 M2 / C&P20 M2 61.000 75.000
CPP M_L / CPP M_L 40.000 46.500
CPP M_H / CPP M_H 38.000 44.500
C&P20 M2 / CPP M_L 50.000 60.500
C&P20 M2 / CPP M_H 49.000 59.500
Placement accuracy 20 µm (3σ) C&P20 M2 / C&P20 M2 54.500 68.500
CPP M_L / CPP M_L 36.500 44.000
CPP M_H / CPP M_H 35.000 42.000
C&P20 M2 / CPP M_L 45.500 56.000
C&P20 M2 / CPP M_H 44.500 55.000
Placement accuracy 15 µm (3σ) C&P20 M2 / C&P20 M2 -- 61.500
CPP M_H = Multistar CPP in high assembly position
CPP M_L = Multistar CPP in low assembly position
3 Technical data and assemblies User manual SIPLACE TX-Series
3.1 Performance data From software version 713.0 Edition 01/2020
108
3.1.4 PCB conveyor data for SIPLACE TX1/TX2/TX2i
3
Flexible dual conveyor Dual conveyor in "single
conveyor" (optional) mode
Board dimensions
(length x width
*a
)
50 mm x 45 mm to
375 mm x 260 mm
45 mm x 45 mm to
375 mm x 460 mm
Stationary conveyor side Outside
Right / right
Left / left
Outside
Automatic electrical width adjustment Standard
PCB thickness
Standard 0.3 mm to 4.5 mm
PCB warpage See page 151
PCB weight
*b
Standard Max. 2.0 kg Max. 2.0 kg
Clearance on PCB underside 25 mm
PCB conveyor height
Option
Standard
Option SMEMA
900 mm
930 mm
950 mm
Type of interface SMEMA or IPC-HERMES-9852
Component-free PCB handling edge 3 mm
PCB changeover time
Dual conveyor 1,3 seconds
*c
0 seconds
*d
*)a When using board widths > 375 mm, make sure that the peripheral modules can also process these board widths.
*)b The board weight value refers to the weight of the board plus the weight of the components.
*)c With the "Convoy Mode" option. Without this option 1.8 seconds.
*)d 0 seconds in synchronous mode
Important notes
When setting up a machine (S; F, HS, HF, X or D-Series) next to a SIPLACE TX-Series, be aware that there is limited room between the
two placement machines. In these cases, use suitable conveyor extensions to create room of 0.5m for the operator between the two
machines.
To achieve top placement performance, fit the first machine in a SIPLACE TX-Series line with an input conveyor extension and the last
machine in the line with an output conveyor extension.
