1.1 Important notes on the instruction manual From software version 713.0 Edition 01/2020
16
1.1 Important notes on the instruction manual
1.1.1 Contents and filing of the user manual
This instruction manual contains basic information that must be observed when setting up, oper-
ating and maintaining the placement machine. The service engineers, qualified staff, operators
and users plus system owner must therefore read it before commencing installation and commis-
sioning. The instructions must be kept permanently accessible where the placement machine is
used.
In addition, the user must ensure that the employees have fully understood the contents of the
user manual.
1.1.2 Danger notes
1
1.1.3 Manufacturer's/supplier's liability
– We hereby confirm that the contents of this user manual are of a descriptive and explanatory
nature only and do not contain any contractual conditions or guaranties. The liability and ob-
ligations assumed by ASM Assembly Systems GmbH&Co.KG can be found exclusively in
the relevant contract agreement concerning the supply of the placement machine described
in this manual. This applies in particular to all statements regarding performance or service
life and the agreed liability for faults or defects. The provisions of the contract regarding the
liability for faults or defect are neither extended nor restricted by any statements in this user
manual.
WARNING
Read the user manual!
Tasks may only be performed by qualified staff who have completed the relevant
training.
– Only perform tasks on the placement machine if you have precise knowledge of the
relevant section in the instruction manual.
Observe all warnings, caution notes and hazard notes.
Please also read chapter 2 of this instruction manual through carefully.
User manual SIPLACE TX-Series 1 Introduction
From software version 713.0 Edition 01/2020 1.1 Important notes on the instruction manual
17
1.1.4 Revision table
1
Edition Amendments
11/2015 – First edition
05/2016 – Station software SC 709.01
– Laser class 2 and warning labels
– Revision - transporting the placement machine
– Formal adjustments, minor corrections and supplements
03/2017 – Station software SC 710.0
– SIPLACE Power Connector X
– SIPLACE Shuttle Extension
– SIPLACE TX2 micron / SIPLACE TX2i micron
– SIPLACE TX2i micron 15µm
– SIPLACE MultiStar CPP M
– SIPLACE SmartFeeder 104 mm X
– Formal adjustments
– Correction of errors and supplements
06/2017 – Station software SC 710.1
– Formal adjustments
– Correction of errors and supplements
05/2019 – Stations software from SC.712.1
– Formal adjustments
– SIPLACE TX2i W
– Correction of errors and supplements
01/2020 – Stations software from SC.713.0
– Formal adjustments, minor corrections and supplements
– New warning labels and signs for China
– Mains connections on the placement machine
– EC Declaration of Conformity for individual machine variants
1 Introduction User manual SIPLACE TX-Series
1.1 Important notes on the instruction manual From software version 713.0 Edition 01/2020
18
1.1.5 Further information about and contents of the documentation package
1.1.5.1 How to get information
If you have any further questions concerning this manual or if you would like additional information
on a particular topic, please get in touch with your local SIPLACE dealer or contact us directly at:
ASM Assembly Systems GmbH&Co.KG
Rupert-Mayer-Str. 44
81379 Munich 1
1.1.5.2 SIPLACE on the World Wide Web (WWW)
We also have our own site on the Internet. Why not log into our homepage at http://www.asm-smt-
solutions.com.
All the menus and other information are available in two languages: You can choose between the
German and English versions.
The various headings contain information on
– Our products
– Services
– Contacts, etc.
Registered customers can also access the SIPLACE User Group. There you can call up special
information on our placement machines, such as
– Technical documentation
– Technical information
– Spare parts catalogs etc.
Registering for access to the User Group is easy:
Click on ’Register now’.
Complete the registration form and just send it off.
You will then quickly receive access authorization with USER ID and a password.
