User manual SIPLACE TX-Series 2 Operational safety From software version 713.0 Edition 01/2020 2.2 Warning labels 63 2.2.8 W arning label W 205 on tape cutter 2 Fig. 2.2 - 1 1 Warning label on the top of tape cutter Item…
2 Operational safety User manual SIPLACE TX-Series
2.2 Warning labels From software version 713.0 Edition 01/2020
62
2.2.7.1 High Temperatures on the SIPLACE CPP / CPP M
1 in fig. 2.2 - 10
, page 61 (quantity per SIPLACE CPP / CPP M: 1)
2.2.7.2 Laser class 2 on the component sensor
2
W laser class 2 in fig. 2.2 - 10, page 61, item no. 03134118-01 (quantity per CPP / CPP M: 1)
2
2
2
High temperatures on the SIPLACE CPP / CPP M during continu-
ous operation
Risk of burns due to high temperatures!
The Z drive (linear motor) can develop high surface temperatures
during continuous operation, if the ambient temperature is greater
than 22°C.
Be careful when touching the parts.
2
LASER RADIATION
Laser class 2
Acc. to IEC 60825-1:2014
Do not look into beam!
User manual SIPLACE TX-Series 2 Operational safety
From software version 713.0 Edition 01/2020 2.2 Warning labels
63
2.2.8 Warning label W 205 on tape cutter
2
Fig. 2.2 - 11 Warning label on the top of tape cutter
Item W 205, item no. 03009344-01
2
2
2
WARNING
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Wear robust protective gloves when working on the tape cutter.
WARNING
Risk of injuries
Risk of injuries from pressurized compressed-air lines when working on the tape cutter.
Disconnect the placement machine from the mains supply and the compressed air
supply, before you start work on the tape cutter.
Wait until the operating pressure has dropped to 0 MPa.
W 205
2 Operational safety User manual SIPLACE TX-Series
2.2 Warning labels From software version 713.0 Edition 01/2020
64
2.2.8.1 Warn label W 205 on the used tape chute
2
Fig. 2.2 - 12 Warning label on the used tape chute
Item W 205, item no. 03009344-01
(1) Warning strips
2.2.8.2 Warning label W 205
Warning labels on tape cutter and used tape chute
2
W 205 in fig. 2.2 - 11, page 63 and 2.2 - 12, page 64, item no. 03009344-01 (quantity per place-
ment machine: 4)
W 205
1
2
2
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Observe the safety instructions in section 2.2.8, page 63).
