2 Operational safety User manual SIPLACE TX-Series 2.2 Warning labels From software version 713.0 Edition 01/2020 64 2.2.8.1 W arn label W 205 on the used t ape chute 2 Fig. 2.2 - 12 Warning label on the used t ape chute…

100%1 / 346
User manual SIPLACE TX-Series 2 Operational safety
From software version 713.0 Edition 01/2020 2.2 Warning labels
63
2.2.8 Warning label W 205 on tape cutter
2
Fig. 2.2 - 11 Warning label on the top of tape cutter
Item W 205, item no. 03009344-01
2
2
2
WARNING
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Wear robust protective gloves when working on the tape cutter.
WARNING
Risk of injuries
Risk of injuries from pressurized compressed-air lines when working on the tape cutter.
Disconnect the placement machine from the mains supply and the compressed air
supply, before you start work on the tape cutter.
Wait until the operating pressure has dropped to 0 MPa.
W 205
2 Operational safety User manual SIPLACE TX-Series
2.2 Warning labels From software version 713.0 Edition 01/2020
64
2.2.8.1 Warn label W 205 on the used tape chute
2
Fig. 2.2 - 12 Warning label on the used tape chute
Item W 205, item no. 03009344-01
(1) Warning strips
2.2.8.2 Warning label W 205
Warning labels on tape cutter and used tape chute
2
W 205 in fig. 2.2 - 11, page 63 and 2.2 - 12, page 64, item no. 03009344-01 (quantity per place-
ment machine: 4)
W 205
1
2
2
Risk of cuts
Risk of cuts from sharp blades when working on the tape cutter!
Observe the safety instructions in section 2.2.8, page 63).
User manual SIPLACE TX-Series 2 Operational safety
From software version 713.0 Edition 01/2020 2.2 Warning labels
65
2.2.8.3 Warning strips on the used tape chute
2
A black-yellow warning strip is attached to the used tape chute. Item 1 in the fig. 2.2 - 12, page 64
(quantity per placement machine: 1)
2.2.9 Warning labels on the power supply unit
The power supply unit is located under the cover at location 2 (see item 3 in fig. 4.4 - 3, page 190 ).
Fig. 2.2 - 13 Warning labels on the power supply unit (view from front)
– W 220, on the cover of the safety cut-out (CSB) and on the capacitor battery PCS417
– Item W 206, on the Gantry Control Unit (MGCU 1 and MGCU 2)
– Item W 206, on the service socket (if present)
(1) Temperature caution label on the Gantry Control Unit (MGCU 1 and MGCU 2)
2
2
2
Risk of hand injuries (cuts) over an extensive area
Reaching in here can lead to injuries to the arms and hands.
W 220
W 206
(1)
W 206
