三星贴片机SM321机械电气图 - 第14页
U2-4-4*2.5(BLUE) U2-4-6*4(YELLOW) U2-4-4*2.5(YELLOW) U2-4-8*5 U2-4-6*4 ANCASSY BUTASSY CONVEYORASSY J9053341AEDGEFIXERASSY U2-4-4*2.5 U2-4-4*2.5 U2-4-4*2.5 U2-4-4*2.5 U2-4-6*4 2-J1300067 AN101-01 J6704006AS…
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1 J6711119A
UNIONYFITTING 1 KQ2U04-06
2 J1301188
FITTING 2 KQ2L04-M5/PL4-M5M/SQL04-M5
3 J1300276
FITTING 5 KQ2L06-01/PL6-01
4 J6712008A
PLUG 3 PT1/8
5 J9080796C
FRONTDOCKINGCARTSOLCABLEASS'Y 1 SM-CV028
6 J1300284
FITTING 5 KQ2U06-00/PY6M
7 J6703037A
CHECKVALVE 1 AKH06-00
8 J6711119A
UNIONYFITTING 1 KQ2U04-06
9 J6705004A
SILENCER 2 AN101-01
10 J9080797B
REARDOCKINGCARTSOLCABLEASS'Y 1 SM-CV029
11 J6703033A
SPEEDCON 2 AS2201F-01-06S
12 J6703034A
SPEEDCON 2 ASP330F-01-06S
13 J6711009A
ELBOWFITTING 2 KQ2L06-M5
14
J6711247A ELBOWFITTING 4 PT18EF
15
J6711256A COUPLER 2 KD-M5-SA34697KR
16
J6711257A PLUG 2 KS-4-M5-SA34698KR
17
18
19
20
21
22
23
24
25
26
27
U2-4-4*2.5(BLUE)
U2-4-6*4(YELLOW)
U2-4-4*2.5(YELLOW)
U2-4-8*5U2-4-6*4
ANCASSY
BUTASSY
CONVEYORASSY
J9053341AEDGEFIXERASSY
U2-4-4*2.5U2-4-4*2.5 U2-4-4*2.5 U2-4-4*2.5 U2-4-6*4
2-J1300067
AN101-01
J6704006ASY3120-20-KRW0098
SY3120-20-KRW0098
J6702050ASOLVALVEMODULE
2
4
3
1-I
1-E
1-E
1-C
4
5
7
6 6
9
8
4
11
10 10
1
1-D
1-B1-B1-B
1-F 1-F
1-F
1-A
1-G
1-F
1-C
U2-4-6*4(YELLOW)
AS1211F-M5-04
U2-4-4*2.5(BLUE)
U2-4-4*2.5(YELLOW)
SY3120-20-KRW0098
U2-4-8*5
U2-4-6*4
ANCASSY
BUTASSY
J6702050ASOLVALVEMODULE(4연)
AS1211F-M5-04
KPT18
CONVEYORASSY
J6701088A
CM2C32-50
2-J6711028A
KQ2L04-01
J9080778B(J6701064A)
BDAS10X5-1A-ZC153A2
J6701018B
WTS10X30-RS2
2-J6703028A
SS4-M5MA
J9053341AEDGEFIXERASSY
J6701037B
CQ2B12-KRC0137-2D
J1301188
KQ2L04-M5
J1301188
KQ2L04-M5
J1300277
KQ2L06-M5
J6709018A
AR10-M5BG
U2-4-4*2.5
U2-4-4*2.5
J1301354
AS1201F-M5-04-X214
U2-4-4*2.5
U2-4-4*2.5
U2-4-6*4
J1301188
KQ2L04-M5
J6704006ASY3120-20-KRW0098
4-J6702036A
SY3120-5LZ-M5
J6702035A
VQ110U-5M
6-J1300279
KQ2S04-M5
J6711157A
KQ2L08-01S
2-J1300067
AN101-01
J6703031A
J6703031A
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1 J6702050A
SOLVALVE 1
J6702050A
1-A J6704006A
MANIIFOLDBLOCK 1 SY3120-20-KRW0098
1-B J6702036A
SOLVALVE 3 SY3120-5LZ-M5
1-C J1300067
SILENCER 2 AN101-01
1-D J6711157A
FITTING 1 KQ2L08-01S
1-E J6703031A
SPEEDCONTROLLER 2 AS1211F-M5-04
1-F J1300279
FITTING 6 KQ2S04-M5
1-G J1301188
ELBOWFITTING 1 KQ2L04-M5
2 J6711009A
FITTING 1 KQ2L06-M5
3 J6709018A
REGULATOR 1 AR10-M5BG
4
J1301188 FITTING 2 KQ2L04-M5/PL4-M5M/SQL04-M5
5
J6701087A EDGECYLINDER 1 CQ2B6-CJJC2948
6
J6703028A SPEEDCONTROLLER 2 SS4-M5MA
7
J9080778B ANCSENSORCABLEASSY 1 SM-CV010
8
J6703031A SPEEDCONTROLLER 1 AS1211F-M5-04
9
J6701018B STOPPERCYLINDER1 1 WTS10*30-RS2
10
J6711028A ELBOWFITTING 2 KQ2L04-01
11
J6701088A CYLINDER 1 CM2C32-50
12
13
14
15
16
17
18
19
20
