4 1 1 0 3 2 5 6 7 8 9

NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK

1 J3212022A PHOTO󰚟SENSOR

3

EE-SX674

2 J7054139A SENSOR󰚟PLATE󰚟2

1

J7054139A

3 J7054137A SENSOR󰚟PLATE󰚟4

1

J7054137A

4 J6607083A LM󰚟GUIDE

2

SBG20-SL-1-575-N

5 J7054251A Y󰚟SENSOR󰚟DOG

1

J7054251A

6 J7154256A END󰚟BRACKET-X

1

J7154256A

7 J7154261B GUIDE󰚟CABLE󰚟CHAIN-X

1

J7154261B

8 J7354023A CABLE󰚟CUSHION󰚟X

4

J7354023A

9 J7054255A CUSHION󰚟BRACKET󰚟X

4

J7054255A

10 J7254016D INNER󰚟GUIDE-MAT

2

J7254016D

11 J7154095A END󰚟PLATE-X

1

J7154095A

12 J7054247A BRACKET󰚟CABLE󰚟CHAIN-Y

1

J7054247A

13 J7054256A CUSHION󰚟BRACKET󰚟Y

1

J7054256A

14 J7354024A CABLE󰚟CUSHION󰚟Y

1

J7354024A

15 J7154259A BRACKET󰚟CUSHION󰚟-X

1

J7154259A

16 J7354021A CUSHION-X

1

J7354021A

17 J7054246B SENSOR󰚟DOG-X

2

J7054246B

18 J7054295A CONNECTOR󰚟PANEL

1

J7054295A

19 J71540266C CABLEVEYOR󰚟BRACKET

1

J71540266C

20 J7054260A CABLE󰚟FIXER

1

J7054260A

21 J7054259A CABLE󰚟SPACER

1

J7054259A

22

23

24

25

26

27

4

1

10

3

2

5

6

7

8

9

NO. PART󰚟NO. PART󰚟NAME Q'TY TYPE REMARK

1 J3108063A SERVO󰚟MOTOR

1

MSMA082P1A01

2 J6612035A COUPLING

1

SFC󰚟040DA󰚟10B-19B󰚟(TYPE󰚟B)

3 J6601138A SUPPORT󰚟UNIT

1

FK12󰚟MP5

4 J7154257A BEARING󰚟BRACKET-X

1

J7154257A

5 J7354022A CUSHION-X󰚟1

1

J7354022A

6 J66060037B BALL󰚟SCREW

1

HG1632QS-HEZR-0922X0812-C5F

7 J6601008A BALL󰚟BEARING

3

6000ZZ

8 J7054245A X󰚟BEARING󰚟SPACER

1

J7054245A

9 J6619036A LOCK󰚟NUT

1

RN-10

10 J7154258A BRG󰚟SUPPORT2-X

1

J7154258A

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27
