三星贴片机SM321机械电气图 - 第49页
1 1 9 1 4 8 4 1 2 -A 1 2 -D 1 2 -I 1 2 -B 8 7 6 5 3 2 1 1 0 1 0 1 2 1 2 -C 1 2 -F 1 2 -D 1 2 -G 1 2 -K 1 2 -M 1 2 -M 1 2 -L 1 2 -L 1 3 1 2 -H 1 2 -J 1 2 -O 1 2 -E 1 2 -N
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
28
J7055556B MIRRORSENSORBRACKET 1
J7055556B
29
J3212027A MICROPHOTOSENSOR 3 PM-L24
30
J7155530A MIRRORSUPPORT 1
J7155530A
31
J6755002A FOLDINGMIRROR 1
J6755002A
32
J7155197A MIRRORFIXPLATE 2
J7155197A
33
J7155515A LOWERCOVER2 1
J7155515A
34
J71550570B SIDEILLUMBODY 1
J71550570B
35
J9060415A SM321SIDELEDBOARD 1 J9060415A
36
J90551011A SIDEILLUMGUIDEASS'Y 2
J90551011A
37 J9083179A
SIDEILLU/DSENSORCABLEASS'Y 1 SM-HD006
37-A
J6711132A FITTING 1 M-5HL-4
37-B J6711156A HOSENIPPLE(D/C용)
1
M-5H-4
38 J7255085A SIDEILLUMISOLATOR 1 J7255085A
39 J72550084B SIDEREFLECTOR 6 J72550084B
40
41
42
43
44
45
46
47
48
49
50
51
52
11
9
14
8
4
12-A
12-D
12-I
12-B
8
7
6
5
3
2
1
10
10
12
12-C
12-F
12-D
12-G
12-K
12-M
12-M
12-L
12-L
13
12-H
12-J
12-O
12-E
12-N
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1
J7154099B RIGHTSIDEPLATE 1
HARNESS-HEAD002
2
J7154100B LEFTSIDEPLATE 1
J7154100B
3 J7154267A
HARNESSPLATE 1
J7154267A
4
J7154105A SIDECABLETIE 2
HARNESS-HEAD013
5
J6103023A HEXSUPPORT20 4 M3X20(BOLT-NUT)
6
J6103011A HEXSUPPORT30 4 M3X30(BOLT-NUT)
7
J7055660A HEADCOVERSUPPORT-R 4
J7055660A
8 J7055661A
HEADCOVERSUPPORT-F 1
J7055661A
9 J7155569A
HEADTOPCOVER 1
J7155569A
10 J7055662A
VACUUMSENSORBRACKET 2
J7055662A
11
J9060412A HEADVACUUMSENSORSUBBOARD 1 REV1.1
12 J9055246D
AIRMODULE 1
J9055246D
12-A J71551001A MANIFOLD
1
J71551001A
12-B
J7155544A
FOOTBRACKET-L
1
J7155544A
12-C
J7155545A FOOTBRACKET-R 1
J7155545A
12-D
J7155546A INSERT 6
J7155546A
12-E
J6711260A ONETOUCHFITTING 2 FSE04-M5C
12-F
J6711261A ONETOUCHFITTING 6 FSC04-M5C
12-G
J6702048A SOLENOIDVALVE 6 VA01PEP34-1U-F
12-H
J6702049A SOLENOIDVALVE 1 RCS242-M3-D24NP
12-I J9058090A FILTERASSY
6
J9058090A
12-J
J7458002A FILTERELEMENT 6 LF-M5-60-Z-ELEMENT
12-K
J6711262A MINIFITTING 6 BC-03-M5
12-L
J6703039A SPEEDCONTROLLER 2 SPR-Z-M3N
12-M
J6711263A MINIFITTING 2 BE-04-M3
12-N
J6705009A SILENCER 1 AS-5
12-O J6712016A PLUG
1
N2201900J
