Contents
KV8-0807
1 Base Section
Base ................................................................1-1
2 Cover Section
Top Cover ........................................................2-1
Base Cover ......................................................2-2
3 Feeder Section
Feeder Holder E...............................................3-1
Feeder Holder H..............................................3-2
Feeder Holder B ..............................................3-3
Feeder Floating Detection(20)..........................3-4
4 Moving-axis Section
X-axis ..............................................................4-1
Y-axis ..............................................................4-2
5 Head Section
Head (ST) ........................................................5-1
Head (FNC) .....................................................5-2
Head Combination ..........................................5-3
6 Nozzle Section
Nozzle Changer .............................................6-1
Nozzle (ST) ....................................................6-2
Nozzle (FNC) .................................................6-3
7 Conveyor Unit Section
Push-In ............................................................7-1
Push-Up ..........................................................7-2
Locate-Pin .......................................................7-3
Main stopper / Sub stopper ..............................7-4
Clamp board Positioning .................................7-5
Edge Clamp .....................................................7-6
Main Conveyor ...............................................7-7
8 Light Section
Front Light .......................................................8-1
Front Light (Option) .........................................8-2
9 Control Section
Main Box ........................................................9-1
Main Box (YTF.ATS) .........................................9-2
10 Exterior,etc. Section
Monitor, etc ...................................................10-1
1
1
Base
Base
KV8-1109
61
61
52
53
16
7
25
29
5
45
3
7
33
37
34
30
49
51
50
10
11
9
14
26
6
46
28
41
48
33
34
37
24
44
19
8
21
21
1
22
20
4
31
36
15
17
32
2
24
13
12
40
42
38
39
25
23
35
18
60
46
44
OLD
OLD
47
No. Part No. Part Name Q'ty Remarks Date of change Revised No. Compati.
1 KV7-M1101-00X BASE 1
1-1 KV7-M1101-01X BASE 1 (1999/11/30) M9X0107 OK
1-2 KV7-M1101-02X BASE 1 (2000/1/19) M010047 OK
1-3 KV7-M1101-03X BASE 1 (2000/2/17) M020073 OK
1-4 KV7-M1101-04X BASE 1 (2000/5/9) M040198 OK
2 KV7-M1120-00X PLATE 10 1 CONNECTOR
2-1 KV7-M1120-01X PLATE 10 1 CONNECTOR (1999/11/30) M9X0107 OK
3 KV7-M1112-00X PLATE 2 1
3-1 KV7-M1112-01X PLATE 2 1 (2007/12/3) MDX0013 OK
4 KV7-M1113-00X PLATE 3 1 VALVE
4-1 KGA-M1113-00X PLATE 3 1 VALVE (2003/5/10) M350060 OK
5 KV7-M1114-00X PLATE 4 1 I/O
5-1 KV7-M1114-01X PLATE 4 1 I/O (2007/12/3) MDX0013 OK
6 KV7-M1115-00X PLATE 5 1 AIR
6-1 Delete (2001/5/28) M150099
7 KM0-M1141-00X MANUFOLD 2
8 KG7-M1342-01X BRACKET,F/D 1
9 KG7-M8501-00X AIR FILTER 1
10 KV8-M8502-00X MIST FILTER 1
11 KV8-M8503-00X MODULE ADAPTER 1
12 KG7-M8504-00X REGULATOR 1 R300-03
13 KG7-M8512-00X JOINT 1
13-1 90990-42J007 JOINT 1 (2008/6/17) ME30112 OK
14 KG7-M8513-00X JOINT 1
14-1 90990-42J008 JOINT 1 (2008/6/17) ME30112 OK
15 KM0-M8582-00X VALVE 1 040M12AJ1-7
16 KG7-M8596-00X PRESSURE GAUGE 1
17 KV7-M1118-00X PLATE 8 1
18 KV7-M1125-00X PLATE CLAMP 1
19 KG2-M1128-00X BRACKET SPEED CONT. 1
20 KM0-M1142-00X CASTER 6
20-1 Delete (Option) (2001/9/28) M190104
21 KM0-M1151-01X PLATE SIDE 1 1
21-1 KM0-M1151-02X PLATE,SIDE 1 1 (2007/6/6) MD50118 Set
22 KM0-M1152-01X PLATE SIDE 2 1
23 KM0-M1153-01X PLATE SIDE 3 1
24 KM0-M1154-01X PLATE BOTOM 1 2
25 $SL12-03 JOINT 3
26 $SLY10-03 JOINT 1
27 $TSH4-M5 JOINT 1
27-1 Delete (2006/8/8) MC80027
28 $TL4-02 JOINT 1
29 $UEDW10-8 JOINT 1
30 $USD10-8 JOINT 1
31 $SL8-01 JOINT 1
31-1 $TL8-01 JOINT 1 (2007/12/10) MDX0108 OK
32 $KM-11 MUFFLER 1
33 $TSS4-01 JOINT 12
34 $TSH8-01 JOINT 2
35 KM5-M4184-00X COVER,NOISE FILTER 1
35-1 Delete (2001/2/7) M120037
36
KU0-M1180-00X LEVELING BOLT ASSY. 6
36-1 KV7-M1180-00X LEVELING BOLT ASSY. 6 (1999/4/28) M940123 OK
36-2 KV7-M1180-01X LEVELING BOLT ASSY 6 (2000/2/4) M020021 OK
37 K40-M8598-00X PLUG 1 2
38 91C00-03210 SPACER 28 M3X10L
38-1 90563-03J100 SPACER BOLT 28 (2001/9/1) M180147 OK
39 KH5-M8501-00X EXHAUST VALVE 1
40 KH5-M8531-00X FITTING 1 1
40-1 Delete (2000/5/11) M050024
41 $KM-23 MUFFLER 1
42 91C00-03220 SPACER 4 M3X20L
42-1 90563-03J200 SPACER BOLT 4 (2001/9/4) M180149 OK
43
44 KV7-M1116-00X PLATE 6 1
44-1 KV7-M1116-01X PLATE 6 1 1999/5/21 M930044 NG
45 KV7-M1161-00X PLATE 11 1 TRANS
46 KV7-M1113-10X PLATE 3-1 1 REG
46-1 KV7-M1113-11X PLATE 3-1 1 REG 2001/1/25 M050024 NG
47 KV7-M1153-00X PLATE,SIDE 3 1
47-1 KGS-M1153-50X PLATE,SIDE 3 1 (2005/11/17) MBX0075 OK
48 KV7-M111A-00X BRACKET,GAUGE 1
49 $UED8-4 JOINT 1
50 $UP8 JOINT 1
51 $UP4 JOINT 3
52 KV8-M8502-40X MIST FILTER ELEMENT 1 SPARE
53 KG7-M8501-40X AIR FILTER ELEMENT 1 SPARE
54
55
56
57
58 $SL10-03 JOINT 1
59 $UC4 JOINT 1
60 KG2-M8582-40X VALVE 1 SPARE
61
KV7-M1325-01X BRACKET 5 1 (2002/4/2) M230160
