Osai Automation Systems
TEST HANDLER SOLUTION FOR SENSORS
Up to 20.000 UPH
OSAI A.S. S.p.A. SB
Via Cartiera, 4 - 10010 Parella (TO) - ITALY
Tel: +39 0125 66.83.11
sales@osai-as.com - www.osai-as.com
Osai Automation Systems
TEST HANDLER SOLUTION FOR SENSORS
Up to 20.000 UPH
OSAI A.S. S.p.A. SB
Via Cartiera, 4 - 10010 Parella (TO) - ITALY
Tel: +39 0125 66.83.11
sales@osai-as.com - www.osai-as.com
Osai Automation Systems
TEST HANDLER SOLUTION FOR SENSORS
Up to 20.000 UPH
OSAI A.S. S.p.A. SB
Via Cartiera, 4 - 10010 Parella (TO) - ITALY
Tel: +39 0125 66.83.11
sales@osai-as.com - www.osai-as.com
CONFIGURE YOUR HANDLER WITH YOUR STIMULI
ACCELEROMETERS & GYROSCOPESENVIRONMENTAL
Input/output media
Jedec trays, Tape and reel, direct die feeding
Bin Formats
Bin boxes, 4” waffle trays
Test Handler capability:
• Up to 280 indipendent sites (ping pong
configuration)
• Active vacuum pressure control from
1 to 0 bar (g)
• Per picker Handling technology
• ≤ 1/10K jam rate
• Compact footprint
• Low index time, High throughput
Temperature stimuli:
• Standard and automotive temperature range
• High precision dynamic soak technology,
up to 4°C/sec
Pressure stimuli:
• Pressure range: from 0 up to 2 bar (a)
• Fast settling time (up to 3 pre-pressurized
tanks available as option)
• Configurable controller according to the
accuracy required
GAS stimuli:
• Up to 4 GAS lines inlets
• Supported Gases: CO
2
, Isobutilene,
Hetanol, Methane
• Automatic flushing procedure for Gas
change
• 2 Programmable working mode: Constant
GAS Atmosphere, Pressurized GAS
Atmosphere
Humidity stimuli:
• Range: 0...95% RH
• Accuracy: ±4% RH , ±1% Flow
• flow rate up to 10l/min
• 2 Programmable working mode: Constant
Humidity flow, Pressurized humid
Atmosphere
Production traceability feature available
MICROPHONES & SPEAKERS
KEYPOINTS
Suitable for:
Mems microphones, Mems speaker, voice coil micro-speakers,
dual armature speakers, optical microphones
MAGNETIC
CONFIGURE YOUR HANDLER WITH YOUR STIMULI
KEYPOINTS
Suitable for:
Pressure senors, temperature sensors, GAS sensors, humidity sensors, waterproof pressure
sensors, differential pressure sensors
Input/output media
Jedec trays, Tape and reel
Bin Formats
Bin boxes, 4’’ waffle trays
Test Handler capability:
• Up to 280 indipendent sites (ping pong configuration)
• Per picker Handling technology
• ≤ 1/10K jam rate
• Compact footprint
• Low index time, High throughput
• Amagnetic pick-up and contacting units
Stimuli unit
Integrated on handler working area (ATE Head hard docking)
Production traceability feature available
KEYPOINTS
Suitable for:
Geomagnetic sensors, angular sensors, hall effect sensors,
speed sensors
Input/output media
Jedec trays, Tape and reel
Bin Formats
Bin boxes, 4” waffle trays
Test Handler capability:
• Up to 280 indipendent sites (ping pong configuration)
• Per picker Handling technology
• ≤ 1/10K jam rate
• Compact footprint
• Low index time, High throughput
Stimuli:
• Section acceleration / directions X, Y, Z in combination
• Acceleration range ± 1 g
• Time to reach max acc. 0° ÷ 90° : <400 ms
• Position accuracy of DUT acceleration: 0,04° in gravity field or 0,75 mg
• Position stability: < 0,05°
• Max speed: 360°/s
• Speed stability: ± 1°/s
• Floor noise damping(0 - 1000 Hz, XYZ direction, RMS): –30 dB
Production traceability feature available
KEYPOINTS
Suitable for:
Low g accelerometers, gyroscopes, high g sensors
Input/output media
Jedec trays, Tape and reel, direct die feeding
Bin Formats
Bin boxes, 4” waffle trays
Test Handler capability
Up to 35 indipendent sites
Per picker handling technology
≤ 1/10K jam rate
Compact footprint
Low index time, High throughput
Acoustic stimuli:
• Per site Individual stimuli unit
• Modular test socket architecture
• High SNR test capability (up to 80dB)
Production traceability feature available
