18-C 全体カバー:NPM-W2 W hole Cover:NPM-W2 パーツレイアウト Kit No. キット 品番 Kit Name キット名称 N610154523AA セクションNo. PARTS LAYOUT Section No. - - S59 ( KN610154523AA-19-3 )
Ref
No.
Remarks R
1
Q'ty
18-B
全体カバー:NPM-W2
Whole Cover:NPM-W2
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610154523AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
BRACKET
1
1 MTPB001223AB
COVER
1
2 N610168335AC
COVER
1
3 MTKP000662AC
DUCT-KIT
2
4 MTKA014980AA
COVER
1
5 N610154518AD
COVER
1
6 N610154519AD
COVER
1
7 N610154520AC
COVER
1
8 N610166194AC
COVER
1
9 MTKP000665AB
COVER
1
10 N610166196AB
SPACER
8
11 N510029535AA CF-425E
FAN-GUARD
4
12 KXF077MAA00 109-019E
SCREW
8
13 N510018271AA
Cross recessed Truss head machine screw M4X40-4.8 A2J(Trivalent)
SCREW
42
14 N510018304AA
Cross recessed Truss head machine screw M6X10-4.8 A2J (Trivalent)
SCREW
8
15 N510018313AA
Cross recessed Truss head machine screw M6X6-4.8 A2J (Trivalent)
FAN
1
16 N610127903AA
S
S58
--
( KN610154523AA-19-2 )
18-C
全体カバー:NPM-W2
Whole Cover:NPM-W2
パーツレイアウト
Kit No.
キット品番
Kit Name
キット名称
N610154523AA
セクションNo.
PARTS LAYOUT
Section No.
--
S59
( KN610154523AA-19-3 )
Ref
No.
Remarks R
1
Q'ty
18-C
全体カバー:NPM-W2
Whole Cover:NPM-W2
ｲﾗｽﾄ
No.
Part No.
品 名品 番 数量
R
2
パーツリスト
Kit No.
キット品番
Kit Name
キット名称
N610154523AA
Part Name
備 考
セクションNo.
PARTS LIST
Section No.
R
3
COVER
2
1 N210149683AB
WASHER
4
2 MTPA004915AA
FRAME
2
3 MTPA016975AB
COVER
2
4 N210143036AA
BRACKET
2
5 N210143037AC
NUT-PLATE
2
6 N210186760AA
COVER
2
7 N210147088AB
PLATE
4
8 N210164816AA
NUT-PLATE
4
9 N210186756AA
COVER
2
10 MTKP000693AA
COVER
2
11 N610168763AC
COVER
2
12 MTKP000694AA
COVER
2
13 MTKP000695AA
NUT
72
14 KXF0ATGAA00 SFB-002
CAP
104
15 KXF0ATFAA00 SFA-906
GAS-SPRING
4
16 KXF0E381A00
S
KMF70-40M
SPACER
4
17 N510017106AA CF-418E
PULL
2
18 KXF0DX62A00 AP-829-2
SCREW
60
19 MTNK002299AA
Cross recessed Truss head machine screw M4X10-4.8 A2J (Trivalent) (PA-
BOLT
8
21 N510020762AA MMSB10-10
WASHER
16
22 N510018506AA
Round finish plain washer (JIS B 1256:1978) 10 10H A2J (Trivalent)
SPACER
8
23 N510068123AA CF-502.5ZE
SCREW
8
24 N510068146AA
Cross recessed Truss head machine screw M4X10-4.8 A2S (Trivalent)(UG-
WASHER
8
25 N510018763AA
Toothed lock washer 4 External toothed Steel Unichrome white (Trivalent)
HINGE
4
26 N610124459AA
S60
--
( KN610154523AA-19-3 )
