21
Component Feeding
Component Changeover Table
Technical Data
Length
Length with handles folded up
715 mm
881 mm
Width 570 mm
Height of bottom edge of table bed 680 mm for 830 mm PCB transport height
750 mm for 900 mm PCB transport height
780 mm for 930 mm PCB transport height
800 mm for 950 mm PCB transport height
Weight
without feeder modules
with feeder modules at all
locations
77.5 kg
132.0 kg
Reel diameter
standard
maximum
up to 432 mm (17")
483 mm (19")
Locations for feeder modules max. 15 (3 x 8 mm S)
Changeover time < 1 minute
Component Feeding 2 CO changeover tables with tape reel holders and
integral waste containers,
15 slots, 30 mm wide per changeover table or
1 waffle-pack changer in place of one component
changeover table (location 1), 5 additional locations for
30 mm wide feeder modules
Feeder module types Component tapes, bulk cases, stick magazines, dip
module, waffle-pack trays, OEM feeder modules (surf
tape, component disposal module, waffle-pack trays,
Jedec trays, label feeder modules, inline programming
feeder modules)
Component feeder table
Waste container
for remaining empty tape
Tape container
Communication-
unit
22
Component Feeding
S Tape Feeder Modules
Packaging Feeder module Width Loca-
tions
Transport
distance
Max.
CO height
Paper and
blister tapes
2 x 8 mm S
a
3 x 8 mm S
a
3 x 8 mm S 01005
b
3 x 8 mm S 0201
c
3 x 8 mm SL
d
1 x 12/16 mm S
a) Fiducial for feeder module position recognition
b) for 01005, 0201 and 0402 in paper tapes
c) For 0201 and 0402 in paper tapes
d) SL = Shutterless, from 0201 in paper or blister tapes
30.6 mm
30.6 mm
30.6 mm
30.6 mm
30.6 mm
30.3 mm
1
1
1
1
1
1
2/4 mm
2/4/8 mm
2/4 mm
2/4 mm
2/4/8 mm
4/24 mm
e
e) Variable in 4 mm increments
2.5 mm
f
2.5 mm
0.7 mm
0.7 mm
2.5 mm
14 mm
f
f) PSA Kit available as an option
Blister tapes 1 x 24/32 mm S
1 x 24/32 mm SDP
g
1 x 44 mm S
1 x 44 mm SDP
g
1 x 56 mm
1 x 56 mm SDP
g
1 x 72 mm S
1 x 88 mm S
g) DP = Deep Pocket
42.4 mm
42.4 mm
54.6 mm
54.6 mm
66.6 mm
66.6 mm
82.6 mm
98.6 mm
1.5
1.5
2
2
2.5
2.5
3
3.5
4/40 mm
e
4/40 mm
e
4/52 mm
e
4/52 mm
e
4/68 mm
e
4/68 mm
e
4/80 mm
e
4/96 mm
e
14 mm
24 mm
14 mm
24 mm
14 mm
24 mm
14 mm
14 mm
Tape reels 178 - 483 mm diameter (7" - 19")
Cycle S feeder modules up to 20 mm transport distance < 150 ms
Changeover
time
15 s
23
Component Feeding
Alternative SIPLACE Feeder Modules
Technical data
Bulk case feeder modules
a
packaging form
feeding rails
Location
Bulk case
Chip 0402 component height:
0.5 mm
Chip 0603 component height:
0.8 mm
1
Linear vibratory feeder, type 3
Packaging form
Number of tracks and width
Location
Stick steel magazines
3 x 9.5 mm
2 x 15 mm
1 x 30 mm
1
Dip module takes up 3 locations of a
3 x 8 mm S feeder module
a) Fiducial for feeder module position recognition
Description
The SIPLACE bulk case
feeder module processes
bulk cases on two tracks. It
feeds rectangular and round,
passive components. The
PCB magazines (bulk cases)
are simply replaced for refill-
ing - without stopping the
machine.
The module essentially con-
sists of the basic element
plus two feeder rails and
PCB magazines to suit the
component type and height.
The components are sepa-
rated and fed along the rails
by compressed air.
The principle of the station-
ary component table has
proven its worth, even when
bulk cases are used: the
vibrations that can occur with
other placement machine
concepts can have a highly
detrimental effect on the
component quality due to
abrasion, for example.
Even with stick magazines,
the stationary component
supply has significant advan-
tages: the universal vibratory
stick feeder can be topped up
during placement.
The DIP module is suitable
for dip-fluxing flip-chips,
CSPs (chip-scale/size pack-
ages) and for wetting flip-chip
bumps with isotropic, con-
ductive adhesive.
