M1plusPartsList.pdf - 第67页
No. Part No. Part Name Qty Note 1 LG0-M8903-00X ID SEAL TOOL, ASSY. 1 Labeler for ID Mark Sticker 2 LG0-M8920-00X TOOL 1 Hex. Wrench, Screw Driver set 3 LG0-M89A3-00X WRENCH SET 1 Hex. Wrench 7 pieces 4 LG0-M89A2-00X SCR…
No. Part No. Part Name Qty Note
1 LG0-M71A8-00X SILENCER ELEMENT 1 For Head vacuum generator
2 LG0-M71A9-00X FILTER ELEMENT 1 For Head air filter assy.
3 LG0-M86A2-00X FILTER ELEMENT 1 For air regurator
4 LC0-M8611-00X M71B-SP.(1)ASSY. 1 Head spline shaft assy.
5 LC0-M8612-00X R-AXIS MOTOR ASSY. 1
6 LG0-M86A1-00X GUN,GREASE 1 Grease gun with nozzles.
7 LG0-M86A2-10X FILTER ELEMENT 1 For mist separator
8 LG0-M86A3-00X GREASE,AFA 1 70g
9 LG0-M86A4-00X GREASE,AFB 1 70g
10 LG0-M53H8-00X BATTERY,UPS2 1
11 LC0-M90K3-00X MOTOR,CONV. ASSY. 1 Conveyor motor and gearbox
12 LC0-M90K3-10X DC MOTOR ASSY. 1 Conveyor motor
No. Part No. Part Name Qty Note
1 LG0-M8903-00X ID SEAL TOOL, ASSY. 1 Labeler for ID Mark Sticker
2 LG0-M8920-00X TOOL 1 Hex. Wrench, Screw Driver set
3 LG0-M89A3-00X WRENCH SET 1 Hex. Wrench 7 pieces
4 LG0-M89A2-00X SCREW DRIVER(-) 1 Fine Blade Screwdriver(-)
5 LG0-M89A4-00X LENS CLEANER SET 1 Lens Cleaning Set
6 LG0-M89AB-00X GREASE SILICON 1 Silicone Grease
7 LG0-M89A5-00X MANOMETER ASSY. 1 Vacuum Gauge Set
8 LG0-M89A1-00X COUPLER 1 Air Coupler (85SN)
