Section 2 ThermoFlex 2-9 Thermo Scientific Pumping Capacity T urbine Pump T 0 • Pump curves are nominal values. Pressure values for turbine pumps are differential pressures between the inlet and the outlet of the chiller …
Section 2
2-8 ThermoFlex
Thermo Scientific
Pumping Capacity
Centrifugal Pump P 5
• Pump curves are nominal values. Pressure values for centrifugal and turbine pumps are differential
pressures between the inlet and the outlet of the chiller.
• Pump performance results were obtained with no restrictions on the return to the system or with
any options installed. For example, utilizing the DI option will result in a 0.5 gpm ow reduction.
• Specications obtained at sea level using water as the recirculating uid, at a 20°C process
setpoint, 25°C ambient condition, at nominal operating voltage. Other uids, uid temperatures,
ambient temperatures, altitude or operating voltages will affect performance. See Section 3.
• Thermo Fisher Scientic reserves the right to change specications without notice.
25 50 75 100 125 150 LPM
10 20 30 40 GPM
60 Hz
50
Hz
100
80
60
40
20
7
6
5
4
3
2
1
Bar PSID
Pressure
Flow Rate
Pumping Capacity
Turbine Pump T 1/ T 5
A
B
C
D
10 20 30 40 LPM
2 4 6 8 10 12 GPM
100
80
60
40
20
7
6
5
4
3
2
1
Bar PSID
Pressure
Flow Rate
A: T 5 , 60 Hz
B: T 5, 50 Hz
C: T 1, 60 Hz
D: T 1, 50 Hz
Section 2
ThermoFlex 2-9
Thermo Scientific
Pumping Capacity
Turbine Pump T 0
• Pump curves are nominal values. Pressure values for turbine pumps are differential pressures
between the inlet and the outlet of the chiller.
• Pump performance results were obtained with no restrictions on the return to the system or
with any options installed. For example, utilizing the DI option will result in a 0.5 gpm ow
reduction .
• Specications obtained at sea level using water as the recirculating uid, at a 20°C process
setpoint, 25°C ambient condition, at nominal operating voltage. Other uids, uid temperatures,
ambient temperatures, altitude or operating voltages will affect performance. See Section 3.
• Thermo Fisher Scientic reserves the right to change specications without notice.
60 Hz
50 Hz
160
140
120
100
80
60
40
20
10
8
6
4
2
Bar PSID
Pressure
2.5 5.0 7.5 10.0 12.5 LPM
0.5 1.0 1.5 2.0 2.5 3.0 GPM
Flow Rate
Section 2
2-10 ThermoFlex
Thermo Scientific
ThermoFlex900/1400
Dimensions
(inches/centimeters)
Side View
3
3
/
8
"
8.6
18
1
/
2
"
47.0
24
11
/
16
"
62.8
Front View
27
1
/
4
"*
69.2
12
3
/
16
"
31.0
15
/
16
"
2.4
* Add 1/8" (3 mm) for SEMI
chillers, see Section 5.
• Thermo Fisher Scientic reserves the right to change specications without notice.
