Fluid Top Off

Remove the reservoir cap by unscrewing it counterclockwise.

 







Slowly

failure to comply may result in internal spillage.

Note



O FLO

expand when heated.



Note

already in the reservoir will temporarily affect the chiller's stability

performance.



Before replacing the reservoir cap ensure the reservoir sight tube

ball stopper is securely in place.



Reservoir Ball Stopper

Figure 3-8 Reservoir Ball Stopper

CAUTION

Section 3

3-20 ThermoFlex

Thermo Scientiﬁc

ThermoFlex 4-1

Thermo Scientiﬁc

Basic Controller

Section 4 Operation

The controller controls temperature using a Proportional-Integral-Derivative

(PID) algorithm. It is designed with an easy to use operator interface.

This key is used to start and stop the chiller.

This key is used to navigate through the controller displays, to

make changes and to save changes once they are made. It is

also used to clear error codes.

This key is also used to navigate through controller displays.

The up arrow key is used to navigate through the controller

displays and to increase adjustable values.

The down arrow key is used to navigate through the

controller displays and to decrease adjustable values.

Figure 4-1 Basic Controller

mode

enter

mode
