PSV7000 Owner’s Manual 4—1
Chapter
4
4Maintenance
Performing the maintenance procedures described
in this chapter optimizes operation of your
PSV7000 System, enhances longevity by minimizing
wear and malfunctions, and reduces any downtime.
The manuals that came with any optional equip-
ment on your system may contain additional main-
tenance procedures.
Note: Only individuals trained on these procedures by Data I/O or
its representatives are qualified to perform maintenance on the
PSV7000 System.
This section describes the preventive maintenance schedule for the
PSV7000 System and equipment options, with topics appearing in
this order:
Maintenance Schedule
Workspace, Head and Gantry on page 4-8
Programmers on page 4-28
The Laser Module on page 4-34
Handler Computer on page 4-41
Troubleshooting on page 4-44
Tape Output System on page 4-54
Dual Tray Feeder on page 4-61
A handy sign-off chart
is at the end of this
chapter.
Maintenance ■ Maintenance Schedule
4—2 Data I/O • 096-0640-001B
back
Maintenance Schedule
This Maintenance Interval Chart below recommends intervals based
on single-shift daily usage. Information about the specified proce-
dures and intervals can be found on the pages referenced in the right
column.
Make copies of this
chart and post near
your work area.
Date
completed
/ initials
Component
Action
(see precautions also, on page listed)
Page
Items to check Every Day
Every day Sockets Clean with dry compressed air. Check for wear; replace
if necessary.
For HIC Socket Adapters, see more information in cus-
tomer letter Cleaning HIC Sockets (PN 983-5053) on our
web site Technical Library. This link opens the PDF
which lists cautions and suggested items, such as
Cleaning brush (PN 5655500901) and ProGold Wipes
(PN 5705500902).
page
4-8
Every day Input air pressure
Verify the input air pressure at the regulator is within
specifications
and that it is constant, that is the
Nm3/min. [Normal Cubic Meter/min.] (SCFM ) must be
stable. For specifications, see PSV7000 Air Requirements
Table on page 2-3.
—
Items to check Every Week
* denotes optional equipment
