PSV7000 Owner’s Manual 1—1 Chapter 1 1 Intr oduction This chapter describes PSV7000 and its compo- nents, software, safety and room considerations. The Automated Programming System (PSV7000 System) is a versatile product…
Preface • Repair Service
xii Data I/O • 096-0460-001B
back
Repair Service
After the warranty period expires, Annual Service Agreements are
available. As the end of your warranty period approaches, our sales
group will contact you with the Service Agreement options. Repairs
to systems or sub-assemblies that are not on a service agreement will
typically be charged for labor and material costs.
For more information or to order a Service Contract, call Data I/O
Customer Support at the numbers listed — See “Contacting Data
I/O” on page x.
Change of Address
If your address has changed, please notify Data I/O Customer Sup-
port via e-mail. This ensures that you receive information about
product enhancements. Be sure to include the machine model and
serial number.
PSV7000 Owner’s Manual 1—1
Chapter
1
1Introduction
This chapter describes PSV7000 and its compo-
nents, software, safety and room considerations.
The Automated Programming System
(PSV7000 System) is a versatile production pro-
grammer that handles and programs devices in tra-
ditional and fine-pitched packages. These include
BGA, FPGA, µBGA, QFP, TQFP, CSP,
TSOP, SSOP, SON, WSON, SOIC
Device technologies supported include NOR and
NAND Flash, MicroControllers, Serial EEPROM, and
the latest e-MMC memories.
The PSV7000 System refers to the machine, accessories, the software
and, more generally, the interactions of all these parts. The Machine
is used to mean the physical machine, not the software. For example,
you might connect an air supply hose to the Machine, but change
programming jobs on the PSV7000 System.
The modular design of PSV7000 creates flexibility, allowing you to
optimize to the level of production required by your facility.
Definition of terms:
Introduction ■ Snapshot of PSV7000
1—2 Data I/O • 096-0460-001B
back
Snapshot of PSV7000
Figure 1-1: Features of PSV7000. For a more detailed image with
components labeled, see the Operators Manual. For component
descriptions see Component Descriptions on page 1-10.
Many software options
such as the Automotive
Performance Pak
Support for laser
marking option
(far side); 2-29
Adjustable feet for
leveling and wheels
for relocating ease
Light Tower displays
machine status
Clear safety doors open
(front and back)
Flexible options for input &
output: • static tray (shown),
• automatic tray feeder,
• tube, • tape; 2-10
Uses FlashCORE pro-
grammer modules
offering the latest
industry technology
Keyboard and Touch
Screen monitor
which displays
real-time processes
& online Help.
Supports Tape
Feeder input (see
Operators Man-
ual) or Vibrator
Tube Input; 2-18
Laser guided
Device-position Sensor
for precise device
placement; 4-12
ESD ground connec-
tion (front and inside
workspace at back)
1-6
E-Stop button on
front & back; 1-4
Built-in mounts for the
optional Tray Stacker and
Tape Output Modules
