■ Software ◘ TaskLink
PSV7000 Owner’s Manual 1—17
back
TaskLi n k
TaskLink
™
for Windows
®
is Data I/O’s versatile application for cre-
ating jobs to run on the PSV7000 System. TaskLink resides on the
Handler Computer.
Figure 1-10: TaskLink’s main window displays the selected
programming system. Jobs created or edited will be for this system.
TaskLink online Help is available by clicking Help > Help Topics. It
offers procedural steps as well as general information.
Figure 1-11: TaskLink online Help. It includes update instructions.
Updates and Algorithm Support
Updates to TaskLink (includes algorithm updates) are generally
acquired through our APS Agreement (Annual Programmer Sup-
port). See APS Agreement on our Web site under the SUPPORT tab.
For more information, see TaskLink online Help.
Introduction ■ Software
1—18 Data I/O • 096-0460-001B
back
AH700 Application
Data I/O’s Automated Handler software is a Microsoft
®
Win-
dows
®
-based application for setting up and programming integrated
circuits (devices) on PSV7000 Systems. It offers a selection of many
PSV7000 System options such as input/output configurations,
labeling options, and statistical feedback methods. The AH700
resides in the Handler Computer.
For updates to AH700 Software see Software and Firmware on our
web site under the SUPPORT tab. Then look for PSV7000 under
Download the Latest Firmware.
Figure 1-12: AH700 Start-up window.
Laser Software
The Laser software is a Windows
®
-based application that allows cre-
ating parameters required for laser marking jobs as well as initiating
laser marking. This Lighter Laser Editor software is on the Handler
computer.
Note: The touch screen does not work while in Laser Computer
mode.
When the Laser Marking System is set up and initialized, it receives
commands from the AH700 which starts the marking sequence.
Switching Between Computers
PSV7000 has a separate computer for the Laser software.
The presence of some
features are deter-
mined by the
winAH400.ini file.
For more information
about the Laser Sys-
tem, see Setting Up the
Laser Marking Module
on page 2-29 and
(Optional) Creating a
Laser Marking File on
page 3-24.
■ Software ◘ Laser Software
PSV7000 Owner’s Manual 1—19
back
To switch between the Laser computer and the Handler computers:
1. On the keyboard, press Scroll Lock twice and then number 2 (or
use the Up Arrow or Down Arrow key).
2. Start the Lighter Engine software.
Note: To switch back to the Handler computer, press Scroll Lock
twice and then number 1.
