PSV7000 Owner’s Manual 2—1
Chapter
2
2Setup
This chapter covers setting up the PSV7000 machine
as well as setting up equipment on the machine.
This includes optional equipment such as the Tape
Output equipment, as well as the various device
media choices for running jobs, such as setting up
Static Trays or an Automatic Tray Feeder.
Machine Installation
Installation of the PSV7000 is performed by Data I/O service per-
sonnel or an authorized distributor. After the PSV7000 arrives, ensure
that there is no damage to the exterior of the crate. Remove the
PSV7000 Machine from the crate and inspect for damage that may
have occurred during shipping. If no damage is evident, unbolt the
machine from the shipping pallet.
For the intended area for PSV7000 installation see Room Considerations
on page 1-21.
Setup ■ Machine Installation
2—2 Data I/O • 096-0460-001B
back
Leveling
When the PSV7000 is at the desired location, adjust the feet to level it.
WARNING: Possible machine damage or personal injury!
Instability such as vibrating, walking, or rocking, may occur if
fewer than four of the installed feet make suitable contact
with the floor, or if the leg locknuts are not tightened against
the frame.
Only the adjustable feet provided on the PSV7000 Machine
should be used for leveling. Do not use shims to assist in level-
ing.
■ Connecting Facilities ◘ Connecting Air
PSV7000 Owner’s Manual 2—3
back
Connecting Facilities
The PSV7000 requires two external services: pressurized air and elec-
trical power. It also allows one optional connection to an Internet via
a Network connection. These services connect to the PSV7000
Machine at the Power Panel located on the left side of the machine.
With the two required services, the machine creates all the unique
electrical voltages needed as well regulating pneumatic pressure for
all systems within the machine.
Connecting Air
The machine requires clean, dry, oil-free air from an industrial grade
compressor.
PSV7000 Air Requirements Table
Note: If the compressor cannot maintain the correct air pressure
and stable air volume, PSV7000 System performance will be
affected and may damage devices.
System Air Volume
@ Air
Pressure at
inlet
regulator on
PSV7000
Supply Air
Min. Air
Tube
Length
1
Customer
supplies a
primary
filter/regulator
required between
factory
compressor and
PSV7000
2
—Metric 85 L/minute
[.084 Nm3/min],
constant
5.5 ±0.3 Bar 5.5 - 8.2 Bar 3 Meters 10 micron
—US 3 SCFM constant 80 ±5 PSI 80 to 120 PSI 10 Feet 10 micron
1
This external air line must allow the supplied air to cool sufficiently so that water vapor in the air
condenses and can be extracted.
2
The air filter on the Power Panel is a secondary filter only.
