Contents iv Data I/O • 096-0460-001B Adjusting Pressure of the PSA Seal Rollers 4–57 Troubleshooting the Tape Output System 4–57 Dual Tray Feeder 4–61 Cleaning and Inspecting the Dual Tray Feeder 4–61 Electrical Equipmen…
Contents
PSV7000 Owner’s Manual iii
3D Coplanarity Option 3–28
Running a Job with 3D Inspection 3–28
3D Inspection Results 3–31
Turning OFF the 3D Inspection Computer 3–33
Additional Features 3–34
Automotive Performance Pak 3–34
¤ ¤ ¤ ¤ ¤ ¤ ¤
4 • Maintenance
Maintenance Schedule 4–2
Materials Required 4–5
Turning Off the System 4–6
Self-Service Spares Kit 4–7
Workspace, Head and Gantry 4–8
Socket Adapters and Actuation 4–8
Cleaning the PSV7000 Machine 4–12
Pick and Place Probes 4–14
Adjusting Probe Blow-Off Pressure 4–15
Adjusting the Vacuum Generator Sensors 4–17
Replacing the Input Air Filter 4–18
Vacuum Generator Filters and Silencers 4–19
Inspecting Gantry Parts 4–22
Gantry Belt Tension 4–23
Replacing a PNP Probe Assembly 4–24
Programmers 4–28
FlashCORE Programmer Diagnostics 4–28
Replacing a FlashCORE Programmer 4–30
The Laser Module 4–34
The Laser Module 4–34
Laser Marking Fume Extractor 4–35
Handler Computer 4–41
Handler Computer Air Filter 4–41
Installing AH700 Software Updates 4–41
3D Coplanarity Inspection System 4–43
Cleaning the 3D Inspection PC Filter 4–43
Troubleshooting 4–44
Common Error Messages 4–44
Collect all PSV7000 System Logs 4–45
Programming Problems 4–48
Pick and Place Problems 4–49
Air Pressure Problems 4–50
Tube Input and Output Problems 4–51
Tray Feeder Problems 4–52
Handler Computer Failure 4–52
Laser Marking Problems 4–53
Tape Output System 4–54
Cleaning the Pressure Seal 4–54
Contents
iv Data I/O • 096-0460-001B
Adjusting Pressure of the PSA Seal Rollers 4–57
Troubleshooting the Tape Output System 4–57
Dual Tray Feeder 4–61
Cleaning and Inspecting the Dual Tray Feeder 4–61
Electrical Equipment Disposal Notice 4–62
Maintenance Sign-off Chart 4–63
¤ ¤ ¤ ¤ ¤ ¤ ¤
Glossary • Glossary
Alphabetical Glossary–1
¤ ¤ ¤ ¤ ¤ ¤ ¤
Index • Index
Index Index–1
P
PSV7000 Owner’s Manual v
1 Preface
This chapter covers
• Using this Manual which includes safety symbols
and symbols for specific equipment.
• Contact information
• Service information.
Using This Manual
Knowing the conventions used in this manual helps
make it easy find information, as well as to make
the PSV7000 machine easy-to-use and keep the
operator safe.
Warnings and Cautions
Special paragraphs with red lines are safety warnings as follows:
WARNING: A warning message like this has red text and
calls your attention to potentially hazardous situations and
practices that might injure people or cause serious monetary
loss.
Definition of a Warn-
ing.
