Administrative Functions ■ Administrator Functions 3—4 Data I/O • 096-0460-001B back Administrator Functions Administrators are responsible for creating T asks in T askLink™ and other functions not generally performed by…
■ Safety Messages and Precautions ◘
PSV7000 Owner’s Manual 3—3
back
Safety Messages and Precautions
For your safety and preventing loss of time and damage to equip-
ment, this manual uses special symbols, paragraphs, and color to call
your attention to hazardous situations and recommend safe practices
to help avoid them.
Refer to Using This Manual on page v (in the Preface) for symbols and
fonts used for safety messages.
Refer to Safety Systems on page 1-4 for safety regarding Emergency
Stops, the safety doors, and ESD.
Administrative Functions ■ Administrator Functions
3—4 Data I/O • 096-0460-001B
back
Administrator Functions
Administrators are responsible for creating Tasks in TaskLink™ and
other functions not generally performed by operators. Administra-
tors would likely perform these functions:
• Editing the winAH400.ini File on page 3-5
• Creating a Task in TaskLink on page 3-5
• Creating Security Profiles on page 3-6
• (Optional) Do a First Article Test on page 3-7
• (Optional) Setting TaskLink to Operator Mode on page 3-8
• Enhanced Yield Programming on page 3-8
• Teaching the Workspace Locations on page 3-9
• Optimize Movetimes on page 3-11
• Monitoring Statistics on page 3-12
• Maximizing Programming Yields on page 3-20
• (Optional) Creating a Data File from a Master Device on page 3-23
• (Optional) Creating a Laser Marking File on page 3-24
• Automotive Performance Pak on page 3-34
These functions are discussed in this section.
Reference List of Operator Functions
These functions for operators are discussed in the separate Opera-
tors Manual. All users, administrators, and operators should know
these procedures.
Checking the System
Installing Input/Output Media
Installing Socket Adapters and Actuator Plates
Installing the Correct Probes
(Optional) Installing the Correct Shuttle Cups
Turning PSV7000 System Power ON
Selecting a Job (Starting AH700 via TaskLink)
(Optional) Preselecting Programmers
Setting Media and Options—the Setup window
Starting Programming
—After Starting a Job...
Stopping the System
Light Tower Interpretation
(Optional) Changing Programmer Status
Turning PSV7000 System Power OFF
■ Administrator Functions ◘ Editing the winAH400.ini File
PSV7000 Owner’s Manual 3—5
back
(Optional) Operating the Data I/O Dual Tray Feeder
Editing the winAH400.ini File
The winAH400.ini file can be edited to add or remove options which
determines their availability in the AH700 Setup window. It also sets
non-programming features such as language and which events cause
warnings to display. This is a text file that can be edited in text editors
such as Notepad or UltraEdit. Do not use Microsoft Word or other
word processors since they may add hidden special characters such
as end-of-page characters.
CAUTION: File corruption hazard! Before making any changes to
your winAH400.ini file, save a backup copy.
The winAH400.ini is on the Handler computer in the
C:\AH700\
folder.
Cr e at ing a Ta sk in Ta sk L in k
TaskLink stores Tasks (settings for programming job) in a Task data-
base file (*.TSK). A Task contains all the information necessary for
programming and testing specific devices with a specific algorithm.
Settings and Files Selected in TaskLink
Tasks include:
• Device settings - identifies a specific device (or family of devices
to select from)
• Data file name and apropos settings
• System settings - Package file name
• Process settings - Continuity check, electronic ID check, blank
check, erase, verify, program, and device marking/labelling
information.
• (Optional) Setting the Pass Limit (the quantity of devices to pro-
gram for this job) after clicking Run.
More information about
the winAH400.ini file is
in the AH700 on-screen
Help.
Once a Task is selected
and a Pass Limit is set, the
Task is referred to as a
job to run on the
PSV7000 System. The
same Task can be used for
many jobs.
Note that operators can
change the Pass Limit in the
AH700
Setup > Job Info
tab.
