Administrative Functions ■ Administrator Functions
3—8 Data I/O • 096-0460-001B
back
Test After Creating a Package File
After a Package File is created (described in the next few headings) or
it already exists for this package type and job, then this first article
test method is best when your job includes Laser Marking or
Labeling.
1. Create the PSV7000 job—
1a. In TaskLink, create a new job for PSV7000 Systems.
1b. Click Run (or Load) in TaskLink to start the AH700.
2. Run one device—
2a. In AH700, click Start.
2b. In the Setup window, select media options as usual.
2c. At the PSV7000 workspace, set up the input and output
media as usual.
2d. Click Run > Run One.
2e. After it finishes, verify that the job passed the tests.
Note: If a programmer does not have a Socket Adapter, or an incor-
rect Socket Adapter is installed, the programmer will automatically
be disabled.
(Optional) Setting TaskLink to Operator
Mode
Options to add, remove, and edit Tasks are found in TaskLink’s Task
Manager dialog when in Administrator Mode (the default). You can
set TaskLink to Operator Mode which limits actions to running and
viewing tasks in the Operator Dialog but not but not editing or
deleting Tasks, Kits, or Archived Jobs.
To switch between Operator Mode and Administrator Mode, see
TaskLink’s online Help.
Enhanced Yield Programming
1. Several selections on the Setup window > Options tab affect yield
that are not set in TaskLink. Administrators may wish to advise
operators regarding the setting of the Continuity Retries field
and the Fail Retries field.
2. [Automotive Performance Pak only] Optional: Determine if
any of the five utilities available with the AP Pak are required for
this job. They must be set in the AH700 Setup window > Options
tab.
Programmers that are
not used for a particular
job can be turned off in
the AH700 Start window.
For more information
on the AP Pak, see the
AH700 on-screen
Help.
■ Administrator Functions ◘ Dry Run (Ignore Programmers)
PSV7000 Owner’s Manual 3—9
back
2a. Set security rights for each operator that you do—and do
not—authorize to make AP Pak changes. Changes to User
Rights are made in the Security Dialog.
Note: Only installed options are available for selection on the
Options
tab. If different input media (tube, tape, or tray) is desired,
the winAH400.ini file may need to be edited. See the online Help for
instructions editing the WinAH400.int file or contact Data I/O
support or an authorized technician.
Dry Run (Ignore Programmers)
(Optional) If you want to do a Dry Run or transfer devices from input
media to output media with no programming, click Ignore Program-
mers so it is ON (green); the PNP head will not stop at the program-
mers. Laser marking can be used with Ignore Programmers turned
ON. The default is Off.
Note: Set security rights for each operator to use—or not use—the
Ignore Programmers
option. Changes to
User Rights
are made in
the
Security
Dialog.
Teaching the Workspace Locations
The Package File is a text file containing calibration information that
the PNP head uses to properly pick, rotate and place devices.
After your new Package File is taught, it will contain information
about the specific device package and Socket Adapter as well as the
number of programmers, input and output media, and optional
equipment such as laser marking, if applicable.
A Package File must be created for each device that uses a different
Socket Adapter. If a Package File already exists that can be reused
(same device package, same Socket Adapter, and same input/output
media) a new one is not necessary.
Prerequisites
• A Task and a Package File must exist. For more information, see
topics above.
• A primary device has been selected.
For more information
about Security see Creat-
ing Security Profiles on
page 3-6.
Package Files reside in
the Handler Computer in
folder
C:\AH700\Package
.
Administrative Functions ■ Administrator Functions
3—10 Data I/O • 096-0460-001B
back
To teach locations
1. Run the job in TaskLink that uses your new (renamed) Package
File.
1a. Select a Task and click Run.
1b. In the AH700 Application, click Start.
1c. At the Setup window, make setup selections.
1d. Click System > Gantry. A password may be required—refer
to Creating Security Profiles on page 3-6.
2. To continue, see the AH700 on-screen Help (Teaching Locations >
Printable list of the steps). It covers teaching workspace locations
for all media options.
Note: The PSV7000 System can have static trays or a Data I/O
Dual Tray Feeder. Teaching tray locations is the same for both.
Figure 3-2: Run window shown with a Data I/O Dual Tray Feeder
(crosshatch).
Errors
Axis Limit Error
During the process of teaching locations you will be directing the
PNP head to move to various locations inside the work envelope. If
the PNP head is directed to move beyond its X-axis or Y-axis limits,
you will see a red error button.
To resolve axis limit errors:
1. Record the error message—
1a. Note what item was being taught when the error appeared,
such as Programmer 5 or Tray 1 or Tube 2.
1b. Click the Error button to display the error message.
