KHT_YSP_PL
P AR TS LIST Y SP KHT -1002(PL) Universal High-end Printer
Contents
1 Base Section
Base .....................................................................1-1
Blower Unit / Plate Side ........................................1-2
Foot / Air / Magnet ................................................1-3
2 Cover Section
Cover / LCD Stay ..................................................2-1
Door FT / R ...........................................................2-2
Door FT ................................................................2-3
R / L Conveyor .....................................................2-4
3 Moving-axis Section
SZ-Base / Load Cell .............................................3-1
SZ-Motor / Sensor / Duct ......................................3-2
SY-Frame / Guide .................................................3-3
SY-Motor / Sensor / Clamper ................................3-4
Y-Base / Guide .....................................................3-5
Y-Motor / Sensor / Cover ......................................3-6
X-axis / Support. ...................................................3-7
Z-Base / Screw .....................................................3-8
Z-Motor / Sensor ...................................................3-9
XYZ-Cable ..........................................................3-10
PU-Plate / Motor / Sensor / Guide ......................3-11
PCB Camera / X-axis .........................................3-12
Mask Clamp A.D.P. L / R (O/P) ...........................3-13
4 Head Section
3S Gear Box .........................................................4-1
3S-Motor / Sensor ................................................4-2
W-SQC .................................................................4-3
SQG-3S-Metal ......................................................4-4
SQG-3S-Urethane ................................................4-5
SQG-Metal (Half Etching Type) .......................4-6
SQG-Urethane ......................................................4-7
SQG-3S-Metal (Half Etching Type) .....................4-8
SQG-Metal ...........................................................4-9
5 Cleaner Section
Frame / Guide .......................................................5-1
Roll Up ..................................................................5-2
Cylinder / Roll Unit ................................................5-3
Tank / Pump / Feeder ...........................................5-4
6 MC&MS X-axis Section
Mask Camera / X-axis ..........................................6-1
Main Stopper / Sensor ..........................................6-2
7 Camera Section
PCB Camera ........................................................7-1
Inspection Camera ...............................................7-2
Contents
8 Conveyor Section
Main Base - Width ................................................8-1
Main Base - Transport ..........................................8-2
Main F - Frame / ARM ..........................................8-3
Main F - Belt / Sensor / CYL / Edge / V.Plate .......8-4
Main R - Frame / ARM ..........................................8-5
Main R - Belt / Sensor / CYL / Edge / V.Plate .......8-6
Main Duct Assy .....................................................8-7
ENT Width ............................................................8-8
ENT Transport ......................................................8-9
EXT Width ..........................................................8-10
EXT Transport ....................................................8-11
EXP Width ..........................................................8-12
EXP Transport ....................................................8-13
PCB Vacuum (Op.) .............................................8-14
PCB Back Up (Op.) ............................................8-15
PCB Press (Op.) .................................................8-16
Matrix-Plate ........................................................8-17
9 PSC Section
POT-Head Assy 1 .................................................9-1
POT-Head Assy 2 .................................................9-2
POT-Adpter , Ext. .................................................9-3
Syringe-Head Assy 1 / Valve ................................9-4
Syringe-Head Assy 2 ............................................9-5
Syringe-Dispence Supply .....................................9-6
FX-axis .................................................................9-7
FX-axis Sensor,Cable Duct / Distance Sensor .....9-8
10 Controller Section
Control Box. ........................................................10-1
11 Exterior, etc Section
Exterior, etc .........................................................11-1
Key Board ...........................................................11-2
Temp. Con. Spare. .............................................11-3
