KHT_YSP_PL - 第25页
2 4 3S-Motor / Sensor Head KHT -1004 22 24 7 24 30 21 14 29 1 34 5 4 3 23 16 33 27 26 33 25 9 12 25 9 12 16 16 33 9 6 19 2 15 28 20 31 1 1 10 18 17 32 9 26 13 8 No. Part No. Part Name Q'ty Remarks Compati. Revision …
1
4
3S Gear Box
Head
KHT-0906
36
4
15
39
29
30
11
15
39
16
30
11
10
12
29
17
15
9
30
43
31
14
13
29
22
21
28
33
34
46
32
7
24
2
33
28
25
20
1
44
8
45
37
43
43
3
26
44
6
5
27
23
38
42
40
19
43
41
35
40
18
43
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7101-00 PLATE,LC 1
2 KHT-M7102-00 HOLDER BLOCK 1
3 KHT-M7103-00 GEAR BOX 1 1
4 KHT-M7104-00 GEAR BOX 2 1
5 KHT-M7105-00 HOLDER,HARMONIC 1
6 KHT-M7106-00 FRANGE SHAFT 1
7 KHT-M7107-00 DAMPER 2 1
8 KHT-M7108-01 STOPPER PLATE,3S 1
9 KHT-M7110-00 SHAFT 1 1
10 KHT-M7111-00 SHAFT 2 1
11 KHT-M7112-00 COLLAR 1,SHAFT 2 2
12 KHT-M7113-00 COLLAR 2,SHAFT 2 1
13 KHT-M7114-00 SHAFT 3 1
14 KHT-M7115-00 GEAR 1 1
15 KHT-M7116-00 GEAR 2 3
16 KHT-M7117-00 OIL SEAL(AG 0141 E2) 1
17 KHT-M7118-00 WAVE WASHER,BRG. 1
18 KHT-M7119-00 HOLDER R,SHAFT 2 1
19 KHT-M7119-10 HOLDER L,SHAFT 2 1
20 KGY-M7155-00 HOLDER R,BRG. 1
21 KGY-M7155-10 HOLDER F,BRG. 1
22 KGY-M7156-00 SHAFT,BRG. 1
23 KGY-M7157-00 HARMONIC DRIVE,3S 1
24 KGY-M7181-00 OIL SEAL(AG 0256 E0) 1
25 90185-01J000 NUT, U 1
26 90200-01J500 O-RING 1
27 90200-01J560 O-RING 1
28 90933-01J001 BEARING 2
29 90933-01J900 BEARING 3
30 90933-02J698 BEARING 3
31 90990-28J058 WASHER,PLAIN 1
32 90990-28J059 WASHER,PLAIN 2
33 90990-29J040 SHIM 2
34 91312-03008 BOLT HEX.SOCKET HEAD 2 M3X8
35 91312-03045 BOLT HEX.SOCKET HEAD 3 M3X45
36 91312-04045 BOLT HEX.SOCKET HEAD 4 M4X45
37 91312-05014 BOLT HEX.SOCKET HEAD 4 M5X14
38 91312-05016 BOLT HEX.SOCKET HEAD 4 M5X16
39 91B00-03616 KEY, STRAIGHT 2
40 92012-04012 BOLT,BUTTON HEAD 2
41 99009-08400 CIRCLIP 1
42 99480-04008 PIN,PARALLEL 2 M4X8
43 99480-04010 PIN PARALLEL 7 M4X10
44 91312-04010 BOLT HEX.SOCKET HEAD 9 M4X10
45 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
46 92902-03200 WASHER PLAIN 2
2
4
3S-Motor / Sensor
Head
KHT-1004
22
24
7
24
30
21
14
29
1
34
5
4
3
23
16
33
27
26
33
25
9
12
25
9
12
16
16
33
9
6
19
2
15
28
20
31
11
10
18
17
32
9
26
13
8
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7120-00 PLATE,SQG. 1
2 KHT-M7121-00 BRKT.,3S ORG. SENSOR 1
3 KHT-M7122-00 DOG,SR 1
4 KHT-M7123-00 SPACER,DOG SR 1
5 KHT-M7124-00 DOG,FX SAFETY 1
6 KHT-M7125-00 DAMPER,SR 1
7 KHT-M7128-00 WEIGHT 1,3S 1
8 KHT-M7129-00 WEIGHT 2,3S 8
9 KHT-M7531-00 COLLAR 5
10 KHT-M6523-A1 SENSOR SR ORG ASSY 1
11 KHT-M6524-A1 SENS. SR SAFE 1 ASSY 1
12 KGJ-M3169-00 DAMPER,R 2
13 KGJ-M7116-01 BALL PLUNGER 1
14 KGY-M7177-00 DAMPER 3 1
15 90K63-021H48 AC SERVO MOTOR 1
16 90990-11J003 SCREW,PAN HEAD W/W 3
17 91312-03010 BOLT HEX.SOCKET HEAD 1 M3X10
18 91312-03012 BOLT,HEX.SOCKET HEAD 4 M3X12
19 91312-03020 BOLT,HEX.SOCKET HEAD 1 M3X20
20 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
21 91312-04014 BOLT HEX.SOCKET HEAD 4 M4X14
22 91312-04016 BOLT,HEX.SOCKET HEAD 2 M4X16
23 91312-04020 BOLT HEX.SOCKET HEAD 1 M4X20
24 91312-04050 BOLT HEX.SOCKET HEAD 2 M4X50
25 91312-05010 BOLT HEX.SOCKET HEAD 2 M5X10
26 91312-05012 BOLT HEX.SOCKET HEAD 3 M5X12
27 92902-03200 WASHER PLAIN 1
28 92902-04600 WASHER PLAIN 2
29 92A08-04305 SET SCREW 1 M4X5
30 95302-05700 NUT HEXAGON 1
31 98902-03008 SCREW BINDING HEAD 2 M3X8
32 99480-06018 PIN PARALLEL 1 M6X18
33 $NK-2N NYLON CLIP 3
34 99480-04010 PIN PARALLEL 2
3
4
W-SQC
Head
KHT-1301
20
20
40
40
3
39
39
22
22
27
10
31
19
12
32
31
33
13
4
2
2
2
23
35
35
14
14
18
21
21
25
21
25
37
17
18
20
17
20
25
34
34
15
30
30
36
16
36
30
37
6
21
25
5
5
9
26
24
29
4
4
4
4
13
13
13
28
28
22
39
22
39
38
3
11
22
41
47
52
51
41
47
43
46
48
44
45
49
50
22
39
39
7
27
19
12
32
1
1
8
16
OLD
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7151-01 PLATE,LC W 1
2 KHT-M7152-01 PLATE,SQ 2
3 KHT-M7153-00 CYLINDER,SQG. 2
4 KHT-M7154-01 GUIDE SHAFT,W 4
5 KHT-M7155-00 HOLDER,FLOAT SHAFT 2
6 KHT-M7156-00 PLATE F,SQG. 1
7 KHT-M7157-00 BRACKET,SGQ. CYL. 2
8
KHT-M7158-00 STOPPER PLATE,W 1
9 KHT-M7161-00 COVER,W SQG. 1
10 KHT-M6534-A0 SENS. SQG. 1 UP ASSY 1
11 KHT-M6534-B0 SENS. SQG. 2 UP ASSY 1
12
90990-41J156 COLLAR 2 OK MJY0091-2013/2/14
KHT-M7531-00 COLLAR 2
13 KHT-M7164-00 SLIDE BUSH 4
14 KGY-M7156-00 SHAFT,BRG. 2
15 KHU-M2242-00 PLATE R,SQG. 1
16 KHU-M2245-00 BALL PLUNGER 2
17 KHU-M2248-00 HOLDER R,BRG. 2
18 KHU-M2248-50 HOLDER F,BRG. 2
19 KGJ-M3169-00 DAMPER,R 2
20 90185-01J000 NUT, U 2
21 90933-01J001 BEARING 4
22 90990-11J003 SCREW,PAN HEAD W/W 6
23 90990-28J088 WASHER,PLAIN 4
24 90990-28J100 WASHER,PLAIN 4
25 90990-29J040 SHIM 4
26 91312-04006 BOLT HEX.SOCKET HEAD 2 M4X6
27 91312-05012 BOLT HEX.SOCKET HEAD 4 M5X12
28 91312-04010 BOLT HEX.SOCKET HEAD 16 M4X10
29 91312-04012 BOLT,HEX.SOCKET HEAD 8 M4X12
30 91312-04014 BOLT HEX.SOCKET HEAD 8 M4X14
31 91312-04025 BOLT HEX.SOCKET HEAD 6 M4X25
32 91312-05008 BOLT HEX.SOCKET HEAD 2 M5X8
33 91312-05016 BOLT HEX.SOCKET HEAD 4 M5X16
34 91312-05030 BOLT HEX.SOCKET HEAD 4 M5X30
35 91312-06014 BOLT HEX.SOCKET HEAD 4 M6X14
36 95302-05600 NUT HEXAGON 2
37 99480-04008 PIN,PARALLEL:4X8 4
38 99480-04010 PIN PARALLEL: 4X10 2
39 $NK-2N NYLON CLIP 6
40 $SC4-M5A SPEED CONTROLLER 4
41 KHT-M7159-00 SPASER,SZ STOP 2
42
43 KHT-M7162-00 BRKT.,HNS. 1
44 KGT-M8582-00 VALVE 1
45 91312-03030 BOLT,HEX.SOCKET HEAD 4 M3X30
46 91312-04010 BOLT,HEX.SOCKET HEAD 2 M4X10
47 91312-05050 BOLT HEX.SOCKET HEAD 2 M5X50
48 $TL6-01 JOINT 1
49 $KM-10 MUFFLER 1
50 $UP4 JOINT 2
51 KHT-M7163-00 SPACER,COLLOR SPR. 2
52 91312-04020 BOLT HEX.SOCKET HEAD 8 M4X20
