KHT_YSP_PL - 第34页
2 5 Roll Up Cleaner KHT -1301 48 47 46 33 21 13 31 45 4 29 44 22 28 17 16 42 18 35 32 41 9 6 15 7 20 14 20 14 8 24 38 25 21 33 12 10 34 1 1 39 26 40 36 5 19 1 30 2 43 42 37 3 27 23 23 49 49 No. Part No. Part Name Q'…
1
5
Frame / Guide
Cleaner
KHT-1301
21
9
30
26
8
33
28
36
29
20
25
2
15
27
11
23
37
7
10
26
31
26
38
31
34
4
12
26
29
3
1
28
33
25
30
36
8
26
9
31
5
26
31
26
19
16
16
16
17
25
24
24
13
13
OLD
18
28>29
22
34
19
16
17
25
18
14
14
28
22
25
32
6
35
41
40
39
42
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
KHT-M3601-01 PLATE,BOTTOM 1 M3 screw position changes NG MG30014-2010/6/4
KHT-M3601-00 PLATE,BOTTOM 1
2 KHT-M3602-01 PLATE,SIDE L 1
3 KHT-M3603-01 PLATE,SIDE R 1
4 KHT-M3604-00 PLATE,BACK 1
5 KHT-M3605-00 BRKT.,BACK PLATE L 1
6 KHT-M3607-00
BRKT.,BOTTOM PLATE 1
7 KHT-M3608-00 SHAFT,CLEANER 1
8 KHT-M3609-00 BRKT.,FLAME 2
9 KHT-M3610-00 BLOCK,BASE 2
10 KHT-M3611-00 PIPE,VACUUM 1
11 KHT-M3612-00 HOLDER,BEARING 1
12 KHT-M3613-01 PLATE,CLYNDER R 1
13
KHT-M3614-01 PLATE,CLYNDER L 1 Ø6.5 NG MF00133-2009/11/2
KHT-M3614-00 PLATE,CLYNDER L 1 Ø5.5
14
KHT-M3615-01 PLATE,SHAFT 1 Ø6.5 NG MF00133-2009/11/2
KHT-M3615-00 PLATE,SHAFT 1 Ø5.5
15 KHT-M3616-00 PIPE,VACUUM 2 1
16
KHT-M3617-01 SHAFT,LINEAR BUSH 2 M6 NG MF00133-2009/11/2
KHT-M3617-00
SHAFT,LINEAR BUSH 2 M5
17 KHT-M3617-10 BUSH 2
18
90990-28J152 WASHER,PLAIN 2 OK MJ20016-2012/2/9
KHT-M3618-00 WASHER,PLAIN 2
19
90990-28J153 WASHER,PLAIN 2 OK MJ20016-2012/2/9
KHT-M3619-00 WASHER,PLAIN 2
20
KHT-M3649-00 STOPPER,HOSE 1
21
KHT-M3673-10 GUIDE,HOSE 1 OK MJY0063-2013/1/8
KHT-M3673-01 GUIDE,HOSE 1
22 90990-28J094 WASHER,PLAIN 2
23 90933-01J805 BEARING 1
24 91312-03008 BOLT HEX.SOCKET HEAD 8 M3X8
25 91312-04006 BOLT HEX.SOCKET HEAD 10 M4X6
26 91312-04008 BOLT HEX.SOCKET HEAD 19 M4X8
27 91312-04012 BOLT,HEX.SOCKET HEAD 4 M4X12
28 91312-05012 BOLT HEX.SOCKET HEAD 6 M5X12
29 91312-06012 BOLT HEX.SOCKET HEAD 2 M6X12
30 91312-08020 BOLT HEX.SOCKET HEAD 4 M8X20
31 92902-04200 WASHER PLAIN 10
32 92902-04600 WASHER PLAIN 2
33 92902-05200 WASHER PLAIN 4
34 95302-06600 NUT HEXAGON 4
35 98702-05012 SCREW,FLAT HEAD 3 M5X12
36 98902-04005 SCREW BINDING HEAD 10 M4X5
37 99009-25400 CIRCLIP 1
38 KHT-M3605-10 BRKT,BACK PLATE L 1
39 KHT-M3675-00 BASE,TUBE BAND 1 MJY0063-2013/1/8
40 KHT-M3676-00 TUBE BAND 1 MJY0063-2013/1/8
41 91312-04006 BOLT HEX.SOCKET HEAD 2 MJY0063-2013/1/8
42 98702-05012 SCREW,FLAT HEAD 1 MJY0063-2013/1/8
2
5
Roll Up
Cleaner
KHT-1301
48
47
46
33
21
13
31
45
4
29
44
22
28
17
16
42
18
35
32
41
9
6
15
7
20
14
20
14
8
24
38
25
21
33
12
10
34
11
39
26
40
36
5
19
1
30
2
43
42
37
3
27
23
23
49
49
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M3621-00 BODY,NOZZLE 1
2 KHT-M3624-00 BLOCK,MANIFOLD 1
3 KHT-M3626-00 HOLDER,BEARING 1
4 KHT-M3627-00 SHAFT,BRAKE 1
5 KHT-M3628-00 DOG,ROLL UP 1
6 KHT-M3630-00 STAY,MOTOR 1
7
KHT-M3631-00 BUSH
1
8 KHT-M3632-00 ARM 1
9 KHT-M3633-00 SHAFT,ROLL UP 1
10 KHT-M3634-00 BLOCK,CLYNDER 1
11 KHT-M3635-00 BLOCK,COLLAR 1
12 KHT-M3636-00 HOLDER,CYL. 1
13 KHT-M3637-00 SHAFT,LINK 1
14
90990-28J154 WASHER,PLAIN 2 OK MJ20016-2012/2/9
KHT-M3639-00 WASHER,PLAIN 2
15
90990-28J155 WASHER,PLAIN 1 OK MJ20016-2012/2/9
KHT-M3640-00 WASHER,PLAIN 1
16 KHT-M3641-00 TUBE 4-295 1
17 KHT-M3641-00 TUBE 4-295 1
18 KHT-M3648-A0 BRAKE MAGNETIC ASSY 1
19
90990-41J144 COLLAR 1 OK MJ20016-2012/2/9
KHT-M3658-00 COLLAR 1
20 KGJ-M3648-01 ROLLER,CLUTCH 2
21 90440-01J040 CIRCLIP 2
22 90990-11J001 SCREW PAN HEAD 3
23
90990-11J003 SCREW,PAN HEAD W/W 25
24 90990-28J007 WASHER,PLAIN 1
25 90990-28J053 WASHER,PLAIN 1
26 90990-41J039 COLLAR 1
27 90933-01J801 BEARING 2
28 91B00-04012 KEY STRAIGHT: 4X4X12 1 M4X12
29 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
30 91312-03012 BOLT,HEX.SOCKET HEAD 2 M3X12
31 $NK-4N NYLON CLIP 10
32 91312-04008 BOLT HEX.SOCKET HEAD 1 M4X8
33 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
34 91312-04014 BOLT HEX.SOCKET HEAD 2 M4X14
35 91312-04025 BOLT HEX.SOCKET HEAD 3 M4X25
36 91312-05025 BOLT HEX.SOCKET HEAD 1 M5X25
37 92012-04010 BOLT,BUTTON HEAD 12 M4X10
38 91312-05010 BOLT HEX.SOCKET HEAD 1 M5X10
39 92902-05200 WASHER PLAIN 1
40 92902-05600 WASHER PLAIN 1
41 99009-15400 CIRCLIP 1
42
$BF4-M3 JOINT 2 OK MF80008-2009/8/6
$BF4BU-M3 JOINT 2
43 $UTF4 JOINT 1
44 $NK-2N NYLON CLIP 18
45 $NK-3N NYLON CLIP 4
46 KGY-M9167-00 CYLINDER 1
47 KGY-M9187-00 CAP,SYL. 1
48 $TL4-M5 JOINT 2
49 KHT-M362B-00 SLEEVE,CLAMP 2 MJ30091-2012/4/11
3
5
Cylinder / Roll Unit
Cleaner
KHT-1110
34
20
7
5
31
21
1
23
38
35
11
10
14
30
25
19
29
24>21
2
29
24>21
2
15
22
17
16
31
21
1
23
14
8
30
6
34
34
4
38
33
13
12
35
32
45
41
40
44
43
44
43
39
42
28
37
27
26
42
28
15
22
17
18
48
47
46
46
3
9
33
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1
90990-28J151 WASHER,PLAIN 2 OK MJ20016-2012/2/9
KHT-M3620-00 WASHER,PLAIN 2
2 KHT-M3625-00 HOLDER,DRY BRG. 2
3 KHT-M3629-00 STAY,SENSOR 1
4 KHT-M3670-00 COVER 1 1
5 KHT-M3671-01 COVER L 1
6 KHT-M3672-01 COVER R 1
7
KHT-M3674-02 TUBE 25 1 OK MK30038-2013/3/22
KHT-M3674-01 TUBE 25 1 L=1590mm OK MHX0073-2011/11/29
KHT-M3674-00 TUBE 25 1 L=1430mm
8 KHT-M6521-W0 SENSOR GAUZE ASSY 1
9 KHT-M6525-B0 SENS. ROLL SYL. ASSY 1
10 KHT-M6526-A1 SENS. CL-L HI ASSY 1
11 KHT-M6526-B1 SENS. CL-L LOW ASSY 1
12 KHT-M6526-C1 SENS. CL-R HI ASSY 1
13 KHT-M6526-D1 SENS. CL-R LOW ASSY 1
14 KGJ-M2619-00 CYLINDER,MASK 2
15
KHT-M3647-00 SPRING 2 2 OK MH00064-2011/11/4
KGJ-M3660-00 SPRING 2 2
16 KGY-M3650-00 SHAFT,SPRING 1
17 KGY-M3652-00 OIL FREE BUSH 2
18 KGY-M3655-00 SHAFT21,SPRING 1
19 KGY-M3663-00 PLATE,STOPPER 1
20 KGY-M3730-00 TUBE 25,BAND 1
21
90990-28J017 WASHER,PLAIN 6 OK MH00064-2011/11/4
90990-28J017 WASHER,PLAIN 2
22 90990-28J020 WASHER,PLAIN 2
23 90990-28J055 WASHER,PLAIN 2
24
Delete MH00064-2011/11/4
90990-28J081 WASHER,PLAIN 2
25 91312-03008 BOLT HEX.SOCKET HEAD 2 M3X8
26 91312-03020 BOLT,HEX.SOCKET HEAD 1 M3X20
27 91312-03025 BOLT,HEX.SOCKET HEAD 2 M3X25
28 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
29 91312-05010 BOLT HEX.SOCKET HEAD 2 M5X10
30 91312-05055 BOLT HEX.SOCKET HEAD 4 M5X55
31 92012-05014 BOLT,BUTTON HEAD 2 M5X14
32 97602-03306 SCREW,PAN HEAD W/W 4
33 98902-03008 SCREW BINDING HEAD 3 M3X8
34 98902-04005 SCREW BINDING HEAD 10 M4X5
35 $TSH4-M5M JOINT 2
36 $UL4M JOINT 2
37 $UT4M JOINT 2
38 $SC4-M5A SPEED CONTROLLER 2
39
KHT-M3661-00 PIPE,PAPER 530 1 L=530
KGY-M3661-A0 PIPE,PAPER 440 1 L=440
KGY-M3661-B0 PIPE,PAPER 360 1 L=360
KGY-M3661-C0 PIPE,PAPER 260 1 L=260
40
KHT-M36C0-00 ROLL UNIT 530 1 L=530
KHT-M36C0-A1 ROLL UNIT 440 1 L=440 OK MH90038-2011/9/21
KHT-M36C0-B1 ROLL UNIT 360 1 L=360 OK MH90038-2011/9/21
KHT-M36C0-C1 ROLL UNIT 260 1 L=260 OK MH90038-2011/9/21
KHT-M36C0-A0 ROLL UNIT 440 1 L=440
KHT-M36C0-B0 ROLL UNIT 360 1 L=360
KHT-M36C0-C0 ROLL UNIT 260 1 L=260
41
KHT-M3622-00 NOZZLE,VACUUM 530 1 L=530
KHT-M3622-A0 NOZZLE,VACUUM 440 1 L=440
KHT-M3622-B0 NOZZLE,VACUUM 360 1 L=360
KHT-M3622-C0 NOZZLE,VACUUM 260 1 L=260
42
KHT-M3660-00 BENCOT,ROLL 530 1 L=530
KGY-M3660-A0 BENCOT,ROLL 440 1 L=440
KGY-M3660-B0 BENCOT,ROLL 360 1 L=360
KGY-M3660-C0 BENCOT,ROLL 260 1 L=260
KHT-M366S-00 ROLL SET, 530 1 L=530 10SET of parts numbers
KGY-M366S-A0 ROLL SET, 440 1 L=440 10SET of parts numbers
KGY-M366S-B0 ROLL SET, 360 1 L=360 10SET of parts numbers
KGY-M366S-C0 ROLL SET, 260 1 L=260 10SET of parts numbers
43
KHT-M3690-00 ADAPTER,530,R 2 L=530
KHT-M3690-A0 ADAPTER,440,R 2 L=440
KHT-M3690-B0 ADAPTER,360,R 2 L=360
KHT-M3690-C0 ADAPTER,260,R 2 L=260
44
KHT-M3662-A1 ADAPTER,440,L 2 L=440 OK MH90038-2011/9/21
KHT-M3662-B1 ADAPTER,360,L 2 L=360 OK MH90038-2011/9/21
KHT-M3662-C1 ADAPTER,260,L 2 L=260 OK MH90038-2011/9/21
KHT-M3662-A0 ADAPTER,440,L 2 L=440
KHT-M3662-B0 ADAPTER,360,L 2 L=360
KHT-M3662-C0 ADAPTER,260,L 2 L=260
45 91312-03008 BOLT HEX.SOCKET HEAD 22 M3X8
46 91312-04005 BOLT HEX.SOCKET HEAD 4 M4X5
47 92902-04600 WASHER PLAIN 2
48 KHT-M3638-00 BRKT.,SENSOR 1
