1 7 PCB Camera Camera KHT -0906 1 10 2 6 5 1 1 13 9 3 9 7 13 7 8 12 4 13 7 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KHT -M7801-00 HOLDER,CAMERA 1 2 KHT -M7802-00 SA TY ,FID.LIGHT 1 3 KHT -M78…
2
6
Main Stopper / Sensor
MC&MS X-axis
KHT-1301
35
50
23
19
48
47
32
30
9
31
L>R
R>L
1
49
2
8
29
28
24
24
3
3
24
40
41
41
39
25
38
37
40
25
38
37
37
40
24
25
5
5
12
43
35
22
7
7
24
24
35
11
22
43
25
25
14
14
4
10
6
18
13
27
16
34
26
34
17
28
2
OLD
30
20
36
42
21
41
41
39
25
38
37
40
25
OLD
OLD
OLD
OLD
38
47
46
44
45
33
15
OLD
5
fig.1
fig.2
51
OLD
fig.3
5
12
43
52
OLD
13
43
35
53
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7608-00 BRKT.,CYL. 1
2
KHT-M7660-A0 MS CLY. ASSY. 1 OK MG30150-2010/3/26
KHT-M7609-00 CYL.1,MS 1
3
KHT-M7610-01 PLATE 3,MS 1 NG MF60290-2009/7/2
KHT-M7610-00 PLATE 3,MS 1
4 KHT-M7611-00 GUIDE 1
5
KHT-M7612-03 BRKT.,MS 1 SET MK60080-2013/9/13
KHT-M7612-02 BRKT.,MS 1 g.3 NG MF60290-2009/7/2
KHT-M7612-01 BRKT.,MS 1 g.2 NG MF50115-2009/5/26
KHT-M7612-00 BRKT.,MS 1 g.1
6 KHT-M7613-00 CYL.2,MS 1
7
KHT-M7614-01 JOINT,CYL. 1 NG MF60290-2009/7/2
KHT-M7614-00 JOINT,CYL. 1
8 KHT-M7616-00 BRKT.,HARNESS 1
9 KHT-M7617-00 HOLDER,CAMERA 1
10 KHT-M7621-00 BRKT.,CYL. 1
11 KHT-M7622-00 JOINT,CYL. 1
12
KHT-M7623-02 DOG MS 1 Slotted hole 3.5x5 OK ML20094-2014/2/28
KHT-M7623-01 DOG MS 1 H=24 OK MK00026-2013/10/11
KHT-M7623-00 DOG MS 1 H=26
13
KHT-M7624-01 STAY,SENSOR MS 1 OK ML20094-2014/2/28
KHT-M7624-00 STAY,SENSOR MS 1
14
KHT-M7658-00 BLOCK, STOPPER 1 width 8mm NG MF50115-2009/5/26
KGY-M9161-00 BLOCK,STOPPER 1 width 10mm
15
KHT-M6521-M2 SENSOR MS ORG ASSY 1 L=120mm NG MF50150-2009/5/29
KHT-M6521-M1 SENSOR MS ORG ASSY 1 L=140mm
16 KHT-M6524-F0 SENS. M-ST BACK ASSY 1
17 KHT-M6524-G0 SENS. M-ST UP ASSY 1
18 KHT-M6536-A0 SENS. M-ST LOW ASSY 1
19
KHT-M6532-A0 SENS. PCB POS. ASSY
1
20 $TSH4-M5M JOINT 2
21 $UEF4BU-M3 JOINT 2
22 90990-28J071 WASHER,PLAIN 2
23 90990-11J003 SCREW,PAN HEAD W/W 23
24
91312-03006 BOLT HEX.SOCKET HEAD 5 M3X6 MK60080-2013/9/13
91312-03006 BOLT HEX.SOCKET HEAD 7 NG MF60290-2009/7/2
91312-03006 BOLT HEX.SOCKET HEAD 11 M3X6
25 91312-03008 BOLT HEX.SOCKET HEAD 5 M3X8
26 91312-03045 BOLT HEX.SOCKET HEAD 2 M3X45
27 91312-04006 BOLT HEX.SOCKET HEAD 2 M4X6
28 91312-04010 BOLT HEX.SOCKET HEAD 3 M4X10
29 91312-04014 BOLT HEX.SOCKET HEAD 1 M4X14
30 91312-04030 BOLT HEX.SOCKET HEAD 6 M4X30
31 91312-05050 BOLT HEX.SOCKET HEAD 3 M5X50
32 97002-05020 BOLT,HEXAGON 2 M5X20
33 98502-03006 SCREW PAN HEAD 2 M3X6
34 98902-03008 SCREW BINDING HEAD 3 M3X8
35
92902-03200 WASHER PLAIN 5 ML20094-2014/2/28
92902-03200 WASHER PLAIN 3
36 $NK-2N NYLON CLIP 23
37
KHT-M7615-01 BRKT.,SENSOR 1 NG MF60290-2009/7/2
KHT-M7615-00 BRKT.,SENSOR 1
38
KHT-M7651-01 STAY,SENSOR 1 OK MF60290-2009/7/2
KHT-M7651-00 STAY,SENSOR 1
39
KHT-M7652-00 LIGHT FIBER 1 MF60290-2009/7/2
KHT-M7652-00 LIGHT FIBER 2
40
KHT-M7653-00 PLATE,NUT 1 OK MF60290-2009/7/2
KGY-M9174-00 NUT,SENSOR 1
41 92A08-03003 SET SCREW 2 M3X3
42 $US4 JOINT 2
43
91312-03005 BOLT HEX.SOCKET HEAD 10 M3X5 ML20094-2014/2/28
91312-03005 BOLT HEX.SOCKET HEAD 8 M3X5 MK60080-2013/9/13
91312-03005 BOLT HEX.SOCKET HEAD 4
44 KHT-M7625-01 STAY,SENSOR 1
45
Delete MF60290-2009/7/2
K46-M641F-00 PARTS 1-3(STOPPER) 2
46 92902-04600 WASHER PLAIN 2
47 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
48 KHT-M7657-00 BRKT, AMP. 1
49 91312-03016 BOLT HEX.SOCKET HEAD 4 M3X16
50 90990-33J005 BOLT, STOPPER 1
51 99480-04008 PIN PARALLEL 2
52 KHT-M7619-00 BLOCK,MS 1 SET MK60080-2013/9/13
53 KHT-M762A-00 STAY 2,SENSOR MS 1 ML20094-2014/2/28
1
7
PCB Camera
Camera
KHT-0906
1
10
2
6
5
11
13
9
3
9
7
13
7
8
12
4
13
7
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7801-00 HOLDER,CAMERA 1
2 KHT-M7802-00 SATY,FID.LIGHT 1
3 KHT-M7803-00 BRKT.,HARNESS 1
4 KHN-M7210-01 CCD CAMERA 1
5 KHY-M7211-00 LENS FID. 1
6 KHN-M7600-00 FIDUCIAL LIGHT ASSY. 1
7 90990-11J003 SCREW,PAN HEAD W/W 5
8 91312-05025 BOLT HEX.SOCKET HEAD 2 M5X25
9 91312-04008 BOLT HEX.SOCKET HEAD 2 M4X8
10 91312-05030 BOLT HEX.SOCKET HEAD 2 M5X30
11 91312-05040 BOLT HEX.SOCKET HEAD 4 M5X40
12 99480-04010 PIN PARALLEL 2 M4X10
13 $NK-3N NYLON CLIP 5
2
7
Inspection Camera
Camera
KHT-0906
1
13
14
4
11
7
15
12
16
25
11
28
30
29
17
21
19
20
18
22
30
28
29
9
3
5
10
2
8
27
6
12
11
23
24
26
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7901-00 FRAME,MAIN 1
2 KHT-M7902-01 STAY,CAMERA 1
3 KHT-M7903-00 HOLDER,CAMERA 2 1
4 KHT-M7911-00 BRKT.,HNS. 1
5 KJH-M7210-10 CCD CAMERA 1
6 KGY-M7932-00 LENS,INSP. 1
7 91312-04008 BOLT HEX.SOCKET HEAD 2 M4X8
8 91312-05045 BOLT HEX.SOCKET HEAD 2 M5X45
9 92902-06200 WASHER PLAIN(N) 1
10 92902-05200 WASHER PLAIN 2
11 $NK-3N NYLON CLIP 3
12 90990-11J003 SCREW,PAN HEAD W/W 2
13 99480-04010 PIN PARALLEL 2 M4X10
14 91312-05040 BOLT HEX.SOCKET HEAD 4 M5X40
15 90115-02J006 BOLT HEX.SOCKET HEAD 4
16 91312-06025 BOLT HEX.SOCKET HEAD 1 M6X25
17 KHT-M7908-00 CASE,LIGHT 1
18 KHT-M7909-00 DIFFUSER 1 1
19 KHT-M79B0-00 INSP LIGHT ASSY 1
20 KHT-M79A0-00 INSP CAMERA ASSY 1
21 KHT-M795S-00 ISP LIGHT BRD.SET 1
22 KHT-M7943-00 HNS,INSP S.LIGHT 1
23 KHT-M7943-10 HNS,INSP M.LIGHT 1
24 90563-03J250 SPACER BOLT 4
25 90990-11J001 SCREW PAN HEAD 1
26 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
27 91312-03014 BOLT,HEX.SOCKET HEAD 2 M3X14
28 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
29 98902-03004 SCREW BINDING HEAD 32 M3X4
30 92902-04200 WASHER PLAIN 4
