2 7 Inspection Camera Camera KHT -0906 1 13 14 4 1 1 7 15 12 16 25 1 1 28 30 29 17 21 19 20 18 22 30 28 29 9 3 5 10 2 8 27 6 12 1 1 23 24 26 No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KHT -M790…
1
7
PCB Camera
Camera
KHT-0906
1
10
2
6
5
11
13
9
3
9
7
13
7
8
12
4
13
7
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7801-00 HOLDER,CAMERA 1
2 KHT-M7802-00 SATY,FID.LIGHT 1
3 KHT-M7803-00 BRKT.,HARNESS 1
4 KHN-M7210-01 CCD CAMERA 1
5 KHY-M7211-00 LENS FID. 1
6 KHN-M7600-00 FIDUCIAL LIGHT ASSY. 1
7 90990-11J003 SCREW,PAN HEAD W/W 5
8 91312-05025 BOLT HEX.SOCKET HEAD 2 M5X25
9 91312-04008 BOLT HEX.SOCKET HEAD 2 M4X8
10 91312-05030 BOLT HEX.SOCKET HEAD 2 M5X30
11 91312-05040 BOLT HEX.SOCKET HEAD 4 M5X40
12 99480-04010 PIN PARALLEL 2 M4X10
13 $NK-3N NYLON CLIP 5
2
7
Inspection Camera
Camera
KHT-0906
1
13
14
4
11
7
15
12
16
25
11
28
30
29
17
21
19
20
18
22
30
28
29
9
3
5
10
2
8
27
6
12
11
23
24
26
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7901-00 FRAME,MAIN 1
2 KHT-M7902-01 STAY,CAMERA 1
3 KHT-M7903-00 HOLDER,CAMERA 2 1
4 KHT-M7911-00 BRKT.,HNS. 1
5 KJH-M7210-10 CCD CAMERA 1
6 KGY-M7932-00 LENS,INSP. 1
7 91312-04008 BOLT HEX.SOCKET HEAD 2 M4X8
8 91312-05045 BOLT HEX.SOCKET HEAD 2 M5X45
9 92902-06200 WASHER PLAIN(N) 1
10 92902-05200 WASHER PLAIN 2
11 $NK-3N NYLON CLIP 3
12 90990-11J003 SCREW,PAN HEAD W/W 2
13 99480-04010 PIN PARALLEL 2 M4X10
14 91312-05040 BOLT HEX.SOCKET HEAD 4 M5X40
15 90115-02J006 BOLT HEX.SOCKET HEAD 4
16 91312-06025 BOLT HEX.SOCKET HEAD 1 M6X25
17 KHT-M7908-00 CASE,LIGHT 1
18 KHT-M7909-00 DIFFUSER 1 1
19 KHT-M79B0-00 INSP LIGHT ASSY 1
20 KHT-M79A0-00 INSP CAMERA ASSY 1
21 KHT-M795S-00 ISP LIGHT BRD.SET 1
22 KHT-M7943-00 HNS,INSP S.LIGHT 1
23 KHT-M7943-10 HNS,INSP M.LIGHT 1
24 90563-03J250 SPACER BOLT 4
25 90990-11J001 SCREW PAN HEAD 1
26 91312-03006 BOLT HEX.SOCKET HEAD 4 M3X6
27 91312-03014 BOLT,HEX.SOCKET HEAD 2 M3X14
28 91312-04006 BOLT HEX.SOCKET HEAD 4 M4X6
29 98902-03004 SCREW BINDING HEAD 32 M3X4
30 92902-04200 WASHER PLAIN 4
1
8
Main Base - Width
Conveyor
KHT-1301
66
38
42
44
46
30
19
9
54
65
1
58
23
70
69
36
43
59
4
66
48
51
3
32
45
55
26
15
39
53
53
46
66
65
33
56
52
13
63
41
41
63
53
8
8
28
14
29
10
37
44
9
5
59
19
54
65
66
42
38
47
46
11
32
39
66
65
51
17
54
66
22
45
6
54
50
49
68
58
36
43
61
24
23
66
65
2
54
54
65
58
34
48
60
53
64
60
40
67
54
62
21
49
51
31
18
66
65
64
12
71
63
41
41
7
27
60
52
63
40
25
51
31
25
54
46
6
57
18
35
46
62
20
49
46
65
16
50
49
61
24
23
24
54
OLD
OLD
OLD
71
OLD
72
20
35
57
72
21
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M9101-00 LEG F R 1
2 KHT-M9101-50 LEG F R 1
3
KHT-M9102-01 LEG R R 1 OK MGX0061-2010/11/17
KHT-M9102-00 LEG R R 1 OK MF50064-2009/5/15
KHT-M9102-00 LEG R R 2
4 KHT-M9103-00 STAY,GUIDE 1
5 KHT-M9103-50 STAY,GUIDE 1
6 KHT-M9104-00 GUIDE,WM 1
7 KHT-M9105-00 BRKT.,BEARING 1
8
KHT-M9105-51 PLATE LEG 1 NG MF60032-2009/6/10
KHT-M9105-50 PLATE LEG 1
9 KHT-M9H00-00 BALL SCREW,WM 2
10
KHT-M9108-01 PLATE ,MOTOR 1 NG MG00092-2010/11/5
KHT-M9108-00 PLATE ,MOTOR 1
11 KHT-M9108-50 PLATE,BEARING 1
12
Delete MF60032-2009/6/10
KHT-M9109-00 BRKT.,TENSION 1
13 KHT-M9110-00 BELT,W 1
14
KGT-M916U-00 BELT(201-3GT-9) 1 OK MH50029-2011/5/19
KHT-M9115-01 BELT(201-3GT-9) 1 NG MG00092-2010/11/5
KHT-M9115-00 BELT(216-3GT-9) 1
15 KHT-M9155-00 BRKT.,HARNESS 1
16 KHT-M9128-00 PLATE EDGECLAMP 1
17 KHT-M9128-50 PLATE2 EDGECLAMP 1
18 KHT-M9129-00 BLOCK 2
19 KHT-M9161-00 DAMPER 1,W 2
20
KHT-M9171-01 BRKT.,SENSOR 1 OK ML40043-2014/6/30
KHT-M9171-00 BRKT.,SENSOR 1
21
KHT-M9171-51 BRKT.,SENSOR 1 OK ML40043-2014/6/30
KHT-M9171-50 BRKT.,SENSOR 1
22 KHT-M9174-00 DOG W DANGER 1
23
KHT-M9186-01 BRKT.,SENSOR 2 SET MH10026-2011/1/25
KHT-M9186-00 BRKT.,SENSOR 2
24
KHT-M9188-01 PLATE,NUT 2 SET MH10026-2011/1/25
KHT-M9188-00 PLATE,NUT 2
25 KHT-M7531-00 COLLAR 2
26 KHT-M9156-00 COVER,HARNESS 1
27 KG7-M9111-01 PULLEY 1 1
28 KG7-M9112-01 PULLEY 2 1
29 KG7-M9113-01 PULLEY 3 1
30 KGY-M9108-00 PLATE,BEARING 1
31 KGY-M9115-00 DAMPER 2,W 2
32 KH2-M9121-00 BEARING 2
33 KHT-M6521-P0 SENSOR W2 ORG ASSY 1
34 KHT-M6522-A0 SENS. W2 Z SAFE ASSY 1
35 KHT-M6537-A0 SENS. PIN INT. ASSY 1
36
KHT-M6537-B2 SENS. MS INTLCK ASSY 1 NG MF50150-2009/5/29
KHT-M6537-B1 SENS. MS INTLCK ASSY 1
37
90K63-021344 AC SERVO MOTOR 1 OK MJ50009-2012/5/14
90K63-021744 AC SERVO MOTOR 1 NG MG00092-2010/11/5
90K63-001744 AC SERVO MOTOR 1
38 90990-28J070 WASHER,PLAIN 2
39 90990-28J093 WASHER,PLAIN 2
40
90990-41J057 COLLAR 1 OK MF60032-2009/6/10
90990-41J057 COLLAR 2
41
90990-25J024 BEARING 2 OK MJ70186-2012/10/3
90933-03J608 BEARING 4
42 90933-01J000 BEARING 2
43 91312-03008 BOLT HEX.SOCKET HEAD 4 M3X8
44 91312-03010 BOLT HEX.SOCKET HEAD 7 M3X10
45 91312-04006 BOLT HEX.SOCKET HEAD 7 M4X6
46 91312-04008 BOLT HEX.SOCKET HEAD 6 M4X8
47
91312-04010 BOLT HEX.SOCKET HEAD 6 M4X10 OK MH20044-2011/2/18
91312-04010 BOLT HEX.SOCKET HEAD 4 M4X10
48
91312-04014 BOLT,HEX.SOCKET HEAD 4 M4X14 OK MH20044-2011/2/18
91312-04012 BOLT,HEX.SOCKET HEAD 6 M4X12
49 91312-04016 BOLT,HEX.SOCKET HEAD 24 M4X16
50 90K81-200004 CAP C4 16
51 91312-05016 BOLT HEX.SOCKET HEAD 6 M5X16
52
91312-05025 BOLT HEX.SOCKET HEAD 1 M5X25 MGX0060-2010/11/17
91312-05020 BOLT HEX.SOCKET HEAD 2 M5X20
53 91312-06016 BOLT HEX.SOCKET HEAD 6 M6X16
54 91312-06030 BOLT HEX.SOCKET HEAD 16 M6X30
55 98902-04006 SCREW BINDING HEAD 4 M4X6
56 98502-03008 SCREW PAN HEAD (+) 2 M3X8
57
98902-03012 SCREW BINDING HEAD 4 M3X12 NG ML40043-2014/6/30
98902-03010 SCREW BINDING HEAD 4 M3X10
58
98902-03010 SCREW BINDING HEAD 5 M3X10 SET MH10026-2011/1/25
98902-03012 SCREW BINDING HEAD 5 M3X12
59 99480-05012 PIN,PARALLEL 2 M5X12
60 92A08-04306 SET SCREW 6 M4X6
61 92902-03200 WASHER PLAIN 4
62 92902-04200 WASHER PLAIN 4
63 92902-05600 WASHER PLAIN 5
64 92902-06200 WASHER PLAIN(N) 4
65 $NK-2N NYLON CLIP 8
66 90990-11J003 SCREW,PAN HEAD W/W 8
67 KHT-M9102-01 LEG R R 1 MF50064-2009/5/15
68 KHT-M9106-00 PLATE,NUT 1 MF60032-2009/6/10
69 KHT-M9189-00 PLATE, ADJ. SENS. 2 SET MH10026-2011/1/25
70 91312-03006 BOLT HEX.SOCKET HEAD 4 SET MH10026-2011/1/25
71 KW3-M9139-00 MASK 1 2 ML40043-2014/6/30
72 KHT-M9175-00 PLATE,NUT 2 ML40043-2014/6/30
