KHT_YSP_PL - 第61页
4 9 Syringe-Head Assy 1 / Valve PSC KHT -1101 1 16 7 31 49 12 34 29 30 9 27 32 33 17 41 25 14 13 1 1 15 3 24 8 36 38 5 29 30 26 18 20 28 40 6 37 42 21 19 22 32 23 10 4 2 39 35 38 43 48 45 44 46 47 No. Part No. Part Name …
3
9
POT-Adpter, Ext.
PSC
KHT-1101
4
5
10
8
717
717
8
6
1
3
2
14
8
7
16
8
7
12
9 11
13
OLD
15
8
6
717
8
6
18
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7396-10 CLEANER SHAFT 6 1 φ6X150mm
2 KHT-M7396-20 CLEANER SHAFT 10 1 φ10X150mm
3 KHT-M7396-30 CLEANER SHAFT 15 1 φ15X150mm
4
KHT-M734A-A1 ADAPTER ASSY,B-1 1 OK MK20098-2013/3/4
KHT-M734A-A0 ADAPTER ASSY,B-1 1 HI-Regist
5 KHT-M734A-00 ADAPTER,POT B-1 1
6 KHT-M734A-10 JIG,ADAPTER B-1 SET 1
7 KHT-M7341-A0 PACKING ASSY,ADAPTER 2
8 KHT-M7342-00 JIG,ADAPTER SET 1
9
KHT-M734B-A1 ADAPTER ASSY,S-1 1 OK MK20098-2013/3/4
KHT-M734B-A0 ADAPTER ASSY,S-1 1 SENJU
10 KHT-M734B-00 ADAPTER,POT S-1 1
11
KHT-M734C-A2 ADAPTER ASSY,T-1 1 OK MK20098-2013/3/4
KHT-M734C-A1 ADAPTER ASSY,T-1 1 OK MG50050-2010/5/20
KHT-M734C-A0 ADAPTER ASSY,T-1 1 TAMURA
12
KHT-M734C-01 ADAPTER,POT T-1 1 OK MG50050-2010/5/20
KHT-M734C-00 ADAPTER,POT T-1 1
13 KHT-M734D-A0 ADAPTER ASSY,C-G-1 1 COOKSON-Green
14 KHT-M734D-00 ADAPTER,POT C-G-1 1
15 KHT-M734E-A0 ADAPTER ASSY,C-W-1 1 COOKSON-White
16 KHT-M734E-00 ADAPTER,POT C-W-1 1
17 KHT-M7341-B0 PACKING ASSY ADAPTER 2 NG MG50050-2010/5/20
18 KHT-M7346-00 PLATE,CLEANER 1 MK20115-2013/2/28
4
9
Syringe-Head Assy 1 / Valve
PSC
KHT-1101
1
16
7
31
49
12
34
29
30
9
27
32
33
17
41
25
14
13
11
15
3
24
8
36
38
5
29
30
26
18
20
28
40
6
37
42
21
19
22
32
23
10
4
2
39
35
38
43
48
45
44
46
47
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7354-00 BASE,DISP. HOLDER 1
2 KHT-M7355-00 CAP,DISP. HOLDER 1
3 KHT-M7356-00 HINGE 1
4 KHT-M7357-00 LOCK 1
5 KHT-M7358-00 PLATE,LOCK 1
6 KHT-M7363-00 NOZZLE BASE 1
7
KHT-M7367-00 BARREL,170
1
8 KHT-M7368-00 BARREL PLUNGER 1
9 KHT-M7371-01 CYLINDER 1
10 KHT-M7372-00 HOLDER,PLNJER 1
11 KHT-M7373-00 CAP,HOLD DIS. 1
12 KHT-M7374-00 NOZZLE 6,DISPENSER 1
13 KHT-M7375-00 JOINT 1
14 KHT-M7376-00 JOINT 1
15 KHT-M7377-00 PACCKING 1
16 KHT-M7378-00 JOINT 1
17 KHT-M7381-02 COVER,CUTTER 1
18 KHT-M7382-01 CUTTER PLATE 1
19 KHT-M7383-A0 PASTE CUTTER ASSY 1
20 KHT-M7380-00 PASTE CUP 1
21 KHT-M7383-01 PASTE CUTTER ASSY 1
22 KHT-M7394-00 KNOBU,M3 2
23 98902-03004 SCREW BINDING HEAD 1 M3X4
24 KHT-M7396-10 CLEANER SHAFT 6 1
25 KW3-M3698-00 TUBE FITTING 1
26 KHT-M6535-A0 SENS. CUT OPEN ASSY 1
27 KHT-M6535-B0 SENS. CUT CLOSE ASSY 1
28 KHT-M6538-A0 SENS.SOL.DEFECT ASSY 1
29 $SC4-M3MA SPEED CONTROLLER 2
30 $ULA4M JOINT 2
31
90990-17J064 O-RING 1 OK MG80101-2010/9/3
90200-20J10A O-RING 1
32 91312-03008 BOLT HEX.SOCKET HEAD 3 M3X8
33 91312-03012 BOLT,HEX.SOCKET HEAD 1 M3X12
34 91312-04006 BOLT HEX.SOCKET HEAD 3 M4X6
35 91312-04008 BOLT HEX.SOCKET HEAD 4 M4X8
36 92012-04008 BOLT,BUTTON HEAD 8 M4X8
37 92012-04012 BOLT,BUTTON HEAD 2 M4X12
38 92902-04200 WASHER PLAIN 8
39 98902-03006 SCREW BINDING HEAD 2 M3X6
40 98902-03008 SCREW BINDING HEAD 2 M3X8
41
98707-05012 SCREW,FLAT HEAD 4 M5X10 OK MG00057-2010/10/22
98707-05010 SCREW,FLAT HEAD (+) 4 M5X10
42 99480-04012 PIN,PARALLEL 2 M4X12
43 KGT-M8582-00 VALVE 1
44 $KM-10 MUFFLER 1
45 $TL6-01 JOINT 1
46 $UP4 JOINT 4
47 91312-03030 BOLT,HEX.SOCKET HEAD 4
48 KG2-M8582-40 VALVE 1 Spare
49 KHT-M7374-A0 NOZZLE DISP. ASSY 1 MG80101-2010/9/3
5
9
Syringe-Head Assy 2
PSC
KHT-1301
9
12
12
29
OLD
18
10
28
1
24
19
25
6
5
3
11
23
16
11
16
23
27
4
16
23
22
29
21
18
28
26
28
28
26
8
21
26
15
7
20
13
14
28
17
20
18
18
26
2
18
29
8
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHT-M7351-00 PLATE,FX AXIS 1
2 KHT-M7352-00 BRKT.,HOLDER SYR. 1
3 KHT-M7362-00 BLOCK,PEAST NOZZL 1
4 KHT-M7364-01 CUTTER BASE 1
5 KHT-M7365-00 BRKT.,SENSOR 1
6 KHT-M7366-00 PLATE HOLDER 1
7 KHT-M7369-01 UP STOPPER,FP 1
8
KHT-M7379-03 BRKT.,FX CABLE 1 NG MG50071-2010/5/24
KHT-M7379-02 BRKT.,FX CABLE 1
9 KHT-M7387-00 BRKT.,HNS. 1
10 KHT-M7388-00 DAMPER 1,FP COVER 1
11 KHT-M7389-01 DAMPER 2,FP COVER 2
12
KHT-M7393-02 COVER, FP HEAD 1 W=160mm NG MG50071-2010/5/24
KHT-M7393-01 COVER, FP HEAD 1 W=135mm
13 KHT-M6538-B0 PNP CHANGER ASSY 1
14 $UL6M JOINT 1
15 $US4M AIR JOINT 2
16 90990-41J042 COLLAR 6
17 91312-04010 BOLT,HEX.SOCKET HEAD 1 M4X10
18 91312-04012 BOLT,HEX.SOCKET HEAD 14 M4X12
19 91312-04035 BOLT HEX.SOCKET HEAD 2 M4X35
20 91312-05012 BOLT HEX.SOCKET HEAD 6 M5X12
21 92902-04200 WASHER PLAIN 5
22 97602-03306 SCREW,PAN HEAD W/W 1
23 98902-03004 SCREW BINDING HEAD 6 M3X4
24 99480-04012 PIN,PARALLEL 2 M4X12
25 $NK-2N NYLON CLIP 1
26 $NK-3N NYLON CLIP 16
27 90990-55J001 CLAMP,CABLE 1
28 90990-11J003 SCREW,PAN HEAD W/W 17
29 90990-12J001 SCREW BIN.HEAD W/W 3
