90011772-0102(E-series_electric_schematic) - 第5页
Sheet Size DIN A3 E-series_electric_schematic_complete Ed. Original version_service_11.2014 liyang Function Date Date Replaced by <Empty identifier> T able of contents Modification Appr Replaced by 14/11/2014 2.3 P…
Sheet
Size DIN A3
E-series_electric_schematic_complete
Ed.
Original
version_service_11.2014
liyang
Function
Date
Date
Replaced by
<Empty identifier>
Table of contents
Modification
Appr
Replaced by
14/11/2014
2.2
Page
Name
Weitergabe sowie Vervielfältigung dieser Unterlage, Verwertung und Mitteilung des Inhalts nicht gestattet, soweit nicht ausdrücklich zugestanden.
Proprietary Data, company confidential. All rights reserved
Copying of this document, giving it to others and the use or communication of the contents thereof, are forbidden without express authority.
GmbH & Co KG
ASM
Assembly Systems
Copyright reserved
Privileged business information. Do not release
Offenders are liable to payment of damages. All rights are reserved in the event of the grant or the registration of a utility model or design.
Zuwiederhandlungen verpflichten zu Schadenersatz. Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung vorbehalten.
==INTRO/2.2
/
5
drawing number:
Doc. No.
Page description supplementary page fieldPage Edited by
Table of contents
Mounting
location
AS-F06_002
DateFunction
90011772-010201HX9
53 liyang11/14/2014Cable Harness, Distributor: Pneumatic, Fan, BoxPC PowerCH DIDistributor_E-series
54 liyang11/14/2014Cable Harness, Distributor :Hood Loc.1, COTi1CH DIDistributor_E-series
55 liyang11/14/2014Cable Harness, Distributor :Hood Loc.2,COTi2CH DIDistributor_E-series
56 liyang11/14/2014Cable Harness, Distributor: Location 1DICH Cable_harness_Distributor
57 liyang11/14/2014Cable Harness, Distributor: Location 2CH DIReject Bin & tap cutter
58 liyang11/14/2014Cable Harness, Distributor: Location 2CH DIReject Bin & tap cutter
59 liyang11/14/2014Cable harness, Control Computer and HMICH CTRLCable_harness_Distributor
60 liyang11/14/2014Machine-CAN-Bus-1 (MCAN1), Gantry-CAN-Bus (GCAN)CH CANCable-harness (CAN)
61 liyang11/14/2014Machine-Can-Bus-2 (MCAN2)CH CANCable-harness [Can]
62 liyang11/14/2014Cable harness, MGCU: Trailing. Y-AxisCH MGCUCable-harness MGCU & Trailing
63 liyang11/14/2014Cable harness, MGCU: Trailing, X-AxisCH MGCUCable-harness MGCU & Trailing
64 liyang11/14/2014Cable harness, MGCU: Trailing, Encoder and VisionMGCUCH Cable-harness MGCU & Trailing
65 liyang11/14/2014Stationary Cameras ***Optional***Loc2stCAM stationary - Camera
66 liyang11/14/2014MT60_Loc1 FCU1Loc1MT60 MT60 _ E-series
67 liyang11/14/2014COT60_Loc1 Harting connection ***Optional***Loc1COT60 COT-i 60 _ E-series
68 liyang11/14/2014COT60_Loc1 COT Insert Control ***Optional***Loc1COT60 COT-i 60 _ E-series
69 liyang11/14/2014COT60_Loc1 FCU Connection ***Optional***Loc1COT60 COT-i 60 _ E-series
70 liyang11/14/2014COT60_Loc2 Harting connection ***Optional***Loc2COT60 COT-i 60 _ E-series
71 liyang11/14/2014COT60_Loc2 COT Insert Control ***Optional***Loc2COT60 COT-i 60 _ E-series
72 liyang11/14/2014COT60_Loc2 FCU Connection ***Optional***Loc2COT60 COT-i 60 _ E-series
73 liyang11/14/2014Gantry1_Interface_YGA1GA Gantry
74 liyang11/14/2014Gantry1_Interface_XGA GA1Gantry
75 liyang11/14/2014Gantry1_Head_InterfaceGA GA1Gantry
76 liyang11/14/2014Gantry1_Vision_Board & CamerasGA GA1Gantry
77 liyang11/14/2014TWIN_1 head_main_board_1 version E-SeriesHD TWINTwin_Head
78 liyang11/14/2014TWIN_1 force_measurement_board_1TWINHD Twin_Head
79 liyang11/14/2014TWIN_2 head_main_board_2 version E-SeriesTWINHD Twin_Head
80 liyang11/14/2014TWIN_2 force_measurement_board_2TWINHD Twin_Head
Sheet
Size DIN A3
E-series_electric_schematic_complete
Ed.
Original
version_service_11.2014
liyang
Function
Date
Date
Replaced by
<Empty identifier>
Table of contents
Modification
Appr
Replaced by
14/11/2014
2.3
Page
Name
Weitergabe sowie Vervielfältigung dieser Unterlage, Verwertung und Mitteilung des Inhalts nicht gestattet, soweit nicht ausdrücklich zugestanden.
Proprietary Data, company confidential. All rights reserved
Copying of this document, giving it to others and the use or communication of the contents thereof, are forbidden without express authority.
GmbH & Co KG
ASM
Assembly Systems
Copyright reserved
Privileged business information. Do not release
Offenders are liable to payment of damages. All rights are reserved in the event of the grant or the registration of a utility model or design.
Zuwiederhandlungen verpflichten zu Schadenersatz. Alle Rechte vorbehalten, insbesondere für den Fall der Patenterteilung oder GM-Eintragung vorbehalten.
==INTRO/2.3
/
5
drawing number:
Doc. No.
Page description supplementary page fieldPage Edited by
Table of contents
Mounting
location
AS-F06_002
DateFunction
90011772-010201HX9
81 liyang11/14/2014CP14p-Head Intermediate Distributor mainCP14pHD CP14p_Head
82 liyang11/14/2014CP14p-Head Intermediate Distributor StarCP14pHD CP14p_Head
83 liyang11/14/2014DLM control Service Port / DisplaysHD DLM_TH2DLM3_Head
84 liyang11/14/2014DLM MHCU_motionHD DLM_TH2DLM3_Head
85 liyang11/14/2014TH2 head_main_board_1 version E-SeriesHD DLM_TH2Twin_Head
86 liyang11/14/2014TH2 force_measurement_board_1HD DLM_TH2Twin_Head
87 liyang11/14/2014DLM4 MHCU_motionHD DLM4DLM4_Head
88 liyang11/14/2014DLM4 controlHD DLM4DLM4_Head
89 liyang11/14/2014Vacuum Pump ControlVAC_P VACVacuum pump
90 liyang11/14/2014Control-wiring-boardCO007 L1single_conveyor_E-series_right
91 liyang11/14/2014Control-wiring_sensor_rail (Standard Flow)CO007 L1single_conveyor_E-series_right
92 liyang11/14/2014Control-wiring_sensor_rail (Reverse Flow)CO007 L1single_conveyor_E-series_Left
93 liyang11/14/2014Motor-wiring-M1/M2CO007 L1single_conveyor_E-series_right
94 liyang11/14/2014Motor-wiring-M3CO007 L1single_conveyor_E-series_right
95 liyang11/14/2014Main_Pneumatics_Unit E-SeriesFLUID Fluid
96 liyang11/14/2014Pneumatic-tubing Gantry with option- Flex configurationFLUID Fluid
97 liyang11/14/2014Pneumatic-tubing Gantry with option- Speed ConfigurationFLUID Fluid
98 liyang11/14/2014Pneumatics-tubing Tape-Cutter & Nozzle ChangerFLUID Fluid
99 liyang11/14/2014Pneumatics-tubing COT-insert UnitFLUID Fluid
Sheet
Size DIN A2
E-series_electric_schematic_complete
Ed.
Original
90011772-010201HX9
version_service_11.2014
liyang
Date
TDH
Date
Replaced by
Assembly overview,
machine, view from location 1
Modification
Appr
Replaced by
14/11/2014
3
Name
overview_graphics
Weitergabe sowie Vervielfältigung dieser Unterlage, Verwertung und
Mitteilung des Inhalts nicht gestattet, soweit nicht ausdrücklich zugestanden.
Proprietary Data, company confidential.
All rights reserved
Copying of this document, giving it to others and the use or
communication of the contents thereof, are forbidden without express authority.
Doc. No.
GmbH & Co KG
ASM
Assembly Systems
Copyright reserved
Privileged business information.
Do not release
Offenders are liable to payment of damages. All rights are reserved in the
event of the grant or the registration of a utility model or design.
Zuwiederhandlungen verpflichten zu Schadenersatz. Alle Rechte vorbehalten,
insbesondere für den Fall der Patenterteilung oder GM-Eintragung vorbehalten.
Page:
Function: Overview Graphics
==OVGR=E12/3
15/
drawing number:
Monitor 2
Monitor 2
Monitor 2
Monitor 2
03106879
==CH+CTRL/59.5
Control Computer
Control Computer
Control Computer
Control Computer
03102044
==CH+CTRL/59.0
Distributor
Distributor
Distributor
Distributor
0310 1221
==DI+DI/47.0
Monitor 1
Monitor 1
Monitor 1
Monitor 1
03106879
==CH+CTRL/59.2
Indicator Lamp
Indicator Lamp
Indicator Lamp
Indicator Lamp
03102106
==CH+DI/51.0
Indicator Lamp
Indicator Lamp
Indicator Lamp
Indicator Lamp
03102106
==CH+DI/52.1
Hood-switch-1
Hood-switch-1
Hood-switch-1
Hood-switch-1
03107665
==CH+DI/54.7
Fan Hood
Fan Hood
Fan Hood
Fan Hood
D1225C24BBAZ-00
D1225C24BBAZ-00
D1225C24BBAZ-00
D1225C24BBAZ-00
03094598
==CH+DI/53.7
Keyboard-1
Keyboard-1
Keyboard-1
Keyboard-1
00373984
==CH+CTRL/59.1
Fan Hood
Fan Hood
Fan Hood
Fan Hood
D1225C24BBAZ-00
D1225C24BBAZ-00
D1225C24BBAZ-00
D1225C24BBAZ-00
03094598
==CH+DI/53.6
Stop Button (Loc1)
Stop Button (Loc1)
Stop Button (Loc1)
Stop Button (Loc1)
03118675
==CH+DI/51.2
Main Power Protection
Main Power Protection
Main Power Protection
Main Power Protection
Circuit Breaker
Circuit Breaker
Circuit Breaker
Circuit Breaker
03118374-
==PS005+PS/37.2
Becker Vacuum-Pump
Becker Vacuum-Pump
Becker Vacuum-Pump
Becker Vacuum-Pump
03115911-
==VAC_P+VAC/89.4
Emergency Stop Button
Emergency Stop Button
Emergency Stop Button
Emergency Stop Button
00334073
==CH+DI/51.2
Start Button (Loc 1)
Start Button (Loc 1)
Start Button (Loc 1)
Start Button (Loc 1)
03118673
==CH+DI/51.1
