YV100II PARTLIST - 第19页
KM8-9910 Feeder Floating Detection (Rear) 3 4 Feeder 3 5 4 6 2 5 1 7 8
KM8-9910
Feeder Floating Detection (Front)
33
Feeder Floating
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 KV7-M3903-00X BRACKET SENSOR,2 1
2 KV7-M3910-01X BRACKET SENSOR,1 1
3 KG7-M3906-00X BRACKET 6 2
4 KM0-M3905-10X BRACKET2,SENSOR 1
5 KG9-M3455-11X SENSOR S 1
6 KH5-M3456-A0X SENSOR R 1 GTR3RSPN
7 KG2-M3903-10X SEAL, CAUTION 1 FOR CE
KM8-9910
Feeder Floating Detection (Rear)
34
Feeder
3
5
4
6
2
5
1
7
8
KM8-9910
Feeder Floating Detection (Rear)
34
Feeder Floating
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 KV7-M3901-11X BRACKET SENSOR,2 1
2 KV7-M3910-01X BRACKET SENSOR,1 1
3 KG7-M3906-00X BRACKET 6 2
4 KV7-M3905-30X BRACKET 2, SENSOR 1
5 KM0-M3904-02X PLATE, EXTENSION 2
6 KG9-M3455-11X SENSOR S 1
7 KH5-M3456-A0X SENSOR R 1 FOR CE
8 KG2-M3903-00X SEAL, CAUTION 1 GTR3RSPN
