KM8-9910 Push In 7 5 Conveyor Unit 6 11 10 7 4 12 9 8 3 5 2 1 7 2 See
KM8-9910
Main Stopper
73
Conveyor Unit
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 KU0-M9161-00X PLATE 1, STOPPER 1
2 KU0-M9162-00X BRACKET, STOPPER 1
3 KM7-M9163-00X STOPPER 1
4 KU0-M9164-01X BRACKET, CYLINDER 1
5 KG7-M9165-00X CYLINDER 1
6 K46-M9174-10X GUIDE 1
7 $SC4-M5A SPEED, CONTROLLER 2
8 KU0-M9179-00X RING 1
9 KU0-M91B2-00X BRKT., SENSOR 1
10 KH4-M655F-20X SENSOR 1-3 1
11 91317-06010 BOLT, HEX. SOCKET HEAD 1
12 91317-04010 BOLT, HEX. SOCKET HEAD 2
13 91317-04005 BOLT, HEX. SOCKET HEAD 2
14 91317-03008 BOLT, HEX. SOCKET HEAD 7
KM8-9910
Push In
75
Conveyor Unit
6
11
10
7
4
12
9
8
3
5
2
1
7
2
See
KM8-9910
Push In
75
Conveyor Unit
No. Part No. Part Name Q'ty Remarks No. Part No. Part Name Q'ty Remarks
1 KU0-M9221-00X PLATE, PUSH IN 1
2 KU0-M9222-00X COLLAR 1
3 KU0-M9223-00X HOLDER, CYLINDER 1
4 KG7-M9224-00X COLLAR 1 1
5 KU0-M9226-00X SHOULDER BOLT 1
6 KU0-M9227-00X ROD END CYLINDER 1
7 K98-M7193-00X BRG 1
8 KG7-M9166-00X CYLINDER 1
9 $SC4-M5A SPEED CONTROLLER 2
10 KU0-M9228-00X BRKT., CYL.. 2 1
11 91317-04008 BOLT, HEX. SOCKET HEAD 2
12 91317-06025 BOLT, HEX. SOCKET HEAD 1
