Components carriage feed device
Page 14 / 16 23.11.2021
Pos. Item no. Description Part marking
62 03170631S02 X-FCU, 80MHZ, 60 SLOTS SPARE PART
63 03065658-01 EDGE PROT. PROFILE 18MM LONG
00318998S02 CANT HEATER 1 METER SPARE PART
00805140-01 CABLE TIE W=2.4MM L=92MM
TYB-23M
03079375-02 CABLE HARNESS COT-INSERT 60 SPARE PART
03079360-01 CABLE COT-INSERT 60: SIGNALING
03060471-01 CABLE COT-INSERT 60: CAN BUS
03021170-02 FEM. SCREW-LOCK WITH
SPRING/FLAT WASHER
00305040-01 STRAIN RELIEF CLAMP 10-PIN BK-
MOD422
STANDARD PARTS
03074231-01 CABLE SET NC COT-INSERT 60
03060472-01 CABLE COT-INSERT 60: NC 1/2
00305040-01 STRAIN RELIEF CLAMP 10-PIN BK-
MOD422
STANDARD PARTS
03060473-01 CABLE COT-INSERT 60: NC 3/4
00305040-01 STRAIN RELIEF CLAMP 10-PIN BK-
MOD422
STANDARD PARTS
03060474-03 CABLE COT-INSERT 60: TAPE
CUTTER
03060434-01 STRAIN RELIEF PLATE 35MM LIGHT
GREY
00308458-01 CABLE TIES B=2.5MM, L=102MM
PANDUIT
STANDARD PARTS
03060824-01 CABLE COT-INSERT B-SERIES:
POWER
03060825-01 CABLE COT-INSERT 60: UNLOCK
DEVICE
03060827-01 CABLE COT-INSERT 60: REJECT BOX
03060829-01 CABLE COT-INSERT 60:
VALVE/NOZZLE ST. 1
03079357-01 CABLE COT-INSERT 60: SAFETY
84 03075831-01 SAFETY SWITCH 3NC/1NO
SEPARATE ACTUATOR
SPARE PART
03019064-01 CABLE GLAND, M20X1.5, SKINTOP
MS-M
03079358-01 CABLE COT-INSERT 60: INSERT
CONTROL OUT
03079359-01 CABLE COT-INSERT 60: INSERT
Components carriage feed device
Page 15 / 16 23.11.2021
Pos. Item no. Description Part marking
CONT. IN/OUT
03027646-02 TERMINATOR 120 OHM D-SUB 9-PIN
MALE
SPARE PART
00315706-01 METAL FILM RESISTOR 120 OHM
0,6W 1,0%
90 03123949-01 INSERT CONTROL SX1/2 CPL. SPARE PART
03079304-01 MINIATURE ALU. CASING AKG 55 20
50 ME
92 03078946-01 ASSEMBLY METAL F. PLUG
03079601-01 COMPRESSED AIR HOSES COT-
INSERT 60
03066711-01 COMPRESSED AIR HOSE, 6X1-340
LONG
00333778S01 PLASTIC TUBE PUN-6X1 BLUE 5M WEAR PART
03066712-01 COMPRESSED AIR HOSE, 6X1- 210
LONG
00333778S01 PLASTIC TUBE PUN-6X1 BLUE 5M WEAR PART
03066713-01 COMPRESSED AIR HOSE,
4X0,75-480 LONG
03066715-01 COMPRESSED AIR HOSE,
4X0,75-550 LONG
03072534-01 COMPRESSED AIR HOSE 4X0.75
680MM LONG
03072535-01 COMPRESSED AIR HOSE 4X0.75
640MM LONG
03072537-01 COMPRESSED AIR HOSE 6X1
300MM LONG
00333778S01 PLASTIC TUBE PUN-6X1 BLUE 5M WEAR PART
03082280-01 COMPRESSED AIR HOSE 6X1-1000
LONG
00333778S01 PLASTIC TUBE PUN-6X1 BLUE 5M WEAR PART
03037083-02 ZIPPERTUBING D=25MM BLACK
107 03088958S01 WASTE CHUTE DX1/2 COT60 SPARE PART
108 03064026-01 WASTE CHUTE CPL. SX1/2 COT60 SPARE PART
109 03088401-01 WASTE CHUTE CPL. COT60
110 03009344-01 WARNING LABEL NO. 205
111 03037057-01 WARNING LABEL COVER SHEET X-
SERIE
112 03004715S01 HANGAR PIN SPARE PART
113 03045201-01 DIN EN ISO 7380-M4 X 8-A2-70
Components carriage feed device
Page 16 / 16 23.11.2021
Pos. Item no. Description Part marking
114 03072323-01 SAFETY MARK FOR B TAPE CUTTER
00373742-01 SAFETY MARK EMPTY TYPE GUIDE
CHANNEL
116 03088696S02 HOLDER WASTE CHUTE SPARE PART
117 03045201-01 DIN EN ISO 7380-M4 X 8-A2-70
118 03094519-01 PROTECTION WASTE CHUTE DX1/2
LEFT
SPARE PART
119 03094522-01 PROTECTION WASTE CHUTE DX1/2
RIGHT
SPARE PART
