4 Service Work

4.2 Replacing Spare Parts

Service Manual SIPLACE LDU-X Linear Dipping Unit 11/2017 19

4.2 Replacing Spare Parts

4.2.1 List of Spare Parts

The following spare parts are available for the LDU-X:

Item no. Designation

03060794-xx Flux tank, standard

03110865-xx Flat module plug-in board / EDIF secondary IrDA board

03032819-xx Cable IrDa - EDIF secondary

03069261-xx Flat module plug-in board / control board for X adapter

03128818-xx Rear slide bearing assembly

03128490-xx Slide bearing, LDU version

03134341-xx LDU-X robustness V2 kit

03132870-xx Stop pin/X-Series modified

03128482-xx Support X16-88, metal version

03011739-xx Energy and data interface (EDIF) assembly/X-Series

03012683-xx Pressure spring D-027

03050957-xx Collar screw D4x3.15 M3

03055413-xx Display board

03063561-xx Display foil

03062342-xx Service switch

03062334-xx Emergency stop switch

03062897-xx LDU-X control board

03059486-xx Coupling

03059241-xx Dip tray

03059479-xx Motor with gearing and encoder

03068930-xx Proximity switch assembly

03071772-xx Downholder assembly

03023240-xx ISO 7046-2-M3 x 10-A2-70-H (2x)

03062471-xx Handle

03007733-xx ISO4762–M3x6-8.8, galvanized

03062390-xx Side plate, left

03062033-xx Cover panel with screws

03062032-xx Flap assembly

03062461-xx Cover

03063497-xx Cable X adapter - control board

03066594-xx Cable display board - control board

4.2.2 Important Information for Replacing Spare Parts

► Use ESD-proof tools at an ESD-proof workplace.

► Make sure that no flux is left in the LDU-X during this service work.

► Before performing any service work, remove all parts which are not fixed to the LDU-X.

- Flux tank

- Dip plate

- Park plate

- Dip tray

- Top cover

► Always perform a function check after any service work.

4 Service Work

4.2 Replacing Spare Parts

20 Service Manual SIPLACE LDU-X Linear Dipping Unit 11/2017

4.2.3 Replacing the Flux Tank

Overview

Flux tank [03060794-xx]

Equipment required

●

Standard tools

●

Spare part: Flux tank standard [03060794-xx]

Removal

► Unlock the downholder and swing it up.

► Remove the flux tank.

Installation

► Fit the new flux tank into place.

Check that three pins are positioned at the right side of the flux tank.

► Swing the downholder down again and lock it.

► Check the flux tank for correct positioning.

4.2.4 Replacing the IrDA Board

Overview

Flat module plug-in board EDIF secondary IrDA

board [03110865-xx] with flat ribbon cable

1. Flat module plug-in board EDIF sec-

ondary IrDA board

2. Flat ribbon cable to control board for

X adapter

4 Service Work

4.2 Replacing Spare Parts

Service Manual SIPLACE LDU-X Linear Dipping Unit 11/2017 21

Equipment required

●

Standard tools

●

Torx key size 6

●

Spare parts:

– Flat module plug-in board EDIF secondary IrDA board [03110865-xx]

– Flat ribbon cable IrDa – EDIF secondary [03032819-xx]

Removal

► Remove the cover on the X adapter control board (see 4.2.29.11 "Removing the Controller

Cover" [}65]).

► Loosen the cable clamp and unplug the connector to the EDIF unit (see4.2.29.12 "Removing

the EDIF Unit" [}66]).

► Disconnect the flat ribbon cable to the IrDA board (see 4.2.29.15 "Removing the Cable to the

IrDA Board" [}67]).

► Unscrew the two fastening screws(2)

and remove the IrDA board(1).

Installation

CAUTION

Important installation instructions

► Before fitting the IrDA board, connect the flat ribbon cable to the IrDA board.

► Make sure that the flat ribbon cable is not folded, crushed or otherwise damaged.

► Installation is performed by following the above instructions in the reverse order.
