2 Assembly instructions: Reject bin sensor for the SIPLACE HF-series Reject bin sensor
08/2006 Edition
20
2.7 Assembly at locations with two reject bins
2
2
2
Sensors with cable
Reject bin sensor 2 Assembly instructions: Reject bin sensor for the SIPLACE HF-series
08/2006 Edition
21
2.8 Assembly at locations with one reject bin
2
: Fit the second sensor in the park position. Fit the scanning plate using the enclosed hexagon
socket head screws (needed to activate the sensor).
2
Sensor for scanning
the reject bin
Scanning
plate
Sensor in the
park position
2 Assembly instructions: Reject bin sensor for the SIPLACE HF-series Reject bin sensor
08/2006 Edition
22
2.9 Fitting the sensors on locations with large reject
bin
Fit a sensor beneath the large reject bin. 2
2
Reject bin
Sensor beneath
the reject bin
Sensor beneath
the reject bin
