2 Assembly instructions: Reject bin sensor for the SIPLACE HF-series Reject bin sensor
08/2006 Edition
28
: Start the machine and check the correct sensor functions by removing the reject bins one after
the other.
An "Insert reject bin" message must appear on the user interface.
2
2
: Then calibrate the nozzle changers.
2
2
