1 Introduction User Manual SIPLACE HS-60

1.2 Important notes on the user manual Software version SR.503.xx 07/2003 US Edition

1.2 Important notes on the user manual

1.2.1 Contents and filing of the user manual

This user manual contains basic information that must be observed when setting up, operating

and maintaining the machine. The service engineers, qualified staff, operators and users must

therefore read it before commencing installation and commissioning. The instructions must be

kept permanently accessible where the machine is used. 1

1.2.2 Qualification and training of personnel

Personnel used for operation, preventive maintenance, inspection and installation must hold the

relevant qualifications for the job. The user must keep tight control over their responsibilities, as-

signment and supervision. Any employee who does not have the relevant training must be trained

and given appropriate instruction. If necessary the user of the machine can have training provided

by the manufacturer/supplier. 1

In addition, the user must ensure that the employees have fully understood the contents of the

user manual. 1

1.2.3 User classification

The operating software is structured so that certain functions or menus can only by used or called

by appropriately trained personnel. There are three different classes of user: 1

– operator,

– line engineer and

– service engineer.

Access to each class may be password-protected. Chapters containing information for user

classes higher than "operator" contain a reference to the user class concerned in the footer. 1

Operators 1

The operator class consists of any person who has been trained in operation of the machine.

These people are authorized to use any functions associated with operating the machine and may

call up any menus needed to use the machine. 1

Line engineers 1

Line engineers have undergone special training and are authorized to carry out line engineer ac-

tivities, such as creating set-up configurations, determining vision parameters, etc. 1

User Manual SIPLACE HS-60 1 Introduction

Software version SR.503.xx 07/2003 US Edition 1.3 Danger notes

Service engineers 1

This class is intended for engineers from SIEMENSDEMATIC AG. They are trained to carry out

servicing work and to upgrade and retrofit the placement system. 1

1.3 Danger notes

WARNING 1

– A thorough knowledge of the relevant part of this User Manual is required before carrying out

any work on the machine.

– All work must be carried out by appropriately trained and qualified personnel.

– All warning, caution and danger notes MUST be observed.

– In addition, read through chapter 2 of the user manual carefully.

1.4 Liability of the manufacturer/supplier

We draw your attention to the fact that this user manual only contains descriptive and explanatory

material and does not include any contractual conditions or undertakings. All obligations of Sie-

mensDematic AG proceed from the conclusion of the contract concerned, under which you have

the machine described herein. This applies in particular to all statements regarding performance

or service life and the agreed liability for faults or defects. The provisions of the contract regarding

the liability for faults or defect are neither extended nor restricted by any statements in this user

manual. 1

1 Introduction User Manual SIPLACE HS-60

1.5 EU-Declaration of Conformity Software version SR.503.xx 07/2003 US Edition

1.5 EU-Declaration of Conformity

The product/device described below

product: Automatic Placement System

type: SIPLACE HS-60

item no.: 119400 1

manufactured by 1

SIEMENSDEMATIC AG

Electronics Assembly Systems

Rupert-Mayer-Str. 44

D-81359 München 1

conforms to the relevant provisions of: 1

– Directive 98/37/EC of the European Parliament and of the Council of June 22, 1998 on the

approximation of the laws of the Member States relating to machinery

– Council Directive 89/336/EEC of May 3, 1989 on the approximation of the laws of the Mem-

ber States relating to electromagnetic compatibility

The product(s) identified above comply with the requirements of the above EU directive by meet-

ing the following standards:

EN 292-1, EN 292-2, EN 294, EN 349, EN 418, EN 811, EN 60204-1, EN 60825-1

BGV A1

, BGV A2

, VBG 5

, EN 61000-3-2/3, EN 61000-4-2/3/4/5/6/8 1

1.6 Revision index

1. National specifications

This declaration certifies the compliance with the indicated directives but implies no warranty of properties.

The safety instructions of the accompanying product documentation shall be observed.

Manual Software version Edition

First version Preliminary user manual 5.03 10/2001 DE

First edition User Manual 5.03 03/2003 US

Revision User Manual 5.03 07/2003 US
