Chapter 1 General 1-11 Rear view Note: When CTF-40 is not used, but CFB-36 is used on the rear of the mounter, insert the short-circuit connector into the connector for CTF-40 Signal & Power. Connector for CTF-40 Sig…

Chapter 1 General

1-10

1-1-2 Connector Panel

M10

Front view

CN1

(Signal connector

for post-process)

CN2

(Signal connector

for pre-process)

Air regulator

1. Main Switch

Vacuum gauge

LAN port

Chapter 1 General

1-11

Rear view

Note: When CTF-40 is not used, but CFB-36 is used on the rear of the mounter, insert the short-circuit connector

into the connector for CTF-40 Signal & Power.

Connector for CTF-40

Signal & Power

Air socket for CTF-40

Chapter 1 General

1-12

M20

Front view

CN1

(Signal connector

for post-process)

CN2

(Signal connector

for pre-process)

Vacuum gauge

1. Main Switch

LAN port

Air regulator
