Chapter 10 Replenishing Components and Using Maintenance Menus
10-7
10-3 Using Manual Menus
The manual menus are used for pre-operation arrangements and troubleshooting. The below
table summarizes the use of manual menus. For detailed information , see the following part.
Manual Menu Purpose Related Error
Axis
Moves a specified head manually for
checking each axis movement.
—
Origin
Allows specified axis/axes to return to
its/their origin. Used for the system startup
and the servo motors down in case of an
error.
Axis overrun and emergency stop
(emergency stop switch is
pressed).
Warm Up Performs Warm up and Self-checking. —
Nozzle Info. See Setting Nozzles to Heads (Chapter 5), and
ANC Initial Setting (Chapter 9).
—
Actuator
Allows to check each actuator movement
and to measure its timing.
Failures of clamps, board stopper,
pickup, vacuum breaker, and
others.
Load Board
Loads a board to the mounter. Used to
specify loading speed, board weight setting,
and registration method.
—
Signal I/O
Allows to check signal input/output status
of switches, motors, actuators, and sensors.
Used to check for wire disconnection.
Failures of clamps, board stopper,
ANC, and others.
PCB Sensors Displays the condition of each sensor. —
Air Pressure
Measures air pressure. Used to adjust the
Choke Thresh./Pick Thresh settings.
Pickup error (retry), placement
error (placement offset), and
nozzle choking.
Conveyor
Width
Moves the conveyor rail and makes the
conveyor axis return to origin.
—
Feeder Info. Specifies feeder type to be used for manual
feeder operation.
—
CTF
Checks the stocker for palette presence, and
moves a specified pallet in and out.
CTF-related error
Note: The “CTF Pallet Information” cannot be opened unless you have the “System Parameter” rights
for operation levels.
Chapter 10 Replenishing Components and Using Maintenance Menus
10-8
10-3-1 Axis
The Axis menu allows for manual operation of the driving axes. You can make the specified
axis/axes inch (move by very small stages).
Note: The T axis cannot inch.
The Axis menu allows the specified motor, conveyor, or tray feeder pallet to move.
When executing axis movement via this menu, do not stick head, hands, or other parts
of the body inside the mounter. Serious injury can result. Also make sure non-operators
are at a safe distance from the machine.
Before executing axis movement, make sure no foreign obstacles are left in the mounter or tray
feeder. Otherwise, costly machine damage can occur.
Menu: Manual>Axis
Mounter
When moving Z axis, pay enough attention to the head tip position. If Z axis is moved to the
lowest position of what is permissible, it might interfere with the conveyor rail and so on.
Action:
① Under [Axis], select a driving axis/axes.
② Under [Head], select a head.
③ Under [Axis Speed], adjust the axis speed (1-100). To speed up, drag the slider to the right.
④ Hold down the left mouse button on an arrow button to execute axis movement. To stop
the movement, release the mouse.
⑤ Close the dialog box by clicking <X> button.
Warning
Caution
Caution
Indicate the X coordinate. Indicate the Y coordinate.
Select a driving axis/axes.
Select a head.
Adjust the axis speed.
* The number of heads differs depending
on the mounter model.
Chapter 10 Replenishing Components and Using Maintenance Menus
10-9
XY axes: The head moves horizontally in eight directions.
Z axis: The up and down arrow buttons are used. The head moves
up or down.
T axis: The right and left arrow buttons are used. With the right
arrow button, the head rotates counter-clockwise in the
downward looking perspective. With the left arrow button,
the head rotates clockwise.
Conveyor
Runs the specified conveyor. Under [Conveyor], select a conveyor and click <Move> button.
Then click <Run> button to run the conveyor.
Head Rotation
Rotates the T axis of the specified head. Select a head and enter rotation angle. Then click
<Rotate> button to rotate the head.
