Chapter 15 Data
15-6
15-1 MMI Messages
Note:
“%s” and “%m” represent character strings (e.g. cover name, conveyor name, switch name, motor
name” will be inserted.
“%d1” to “%d8” represent numbers (e.g. station No., pallet No., component count, retry count) will be
inserted.
No. Main Detail
100 Cannot handle the component. %m
Inapplicable process code is downloaded or specified.
Contact us.
101 Invalid input data.
102 Image library data is not found. %m
Image library data that is not downloaded is specified.
Check image library.
103
There is no resolution data for the specified camera.
%m
Check the user parameter to see if the resolution
data is acquired, then contact us.
104 Cannot handle the component. %m Unauthorized process mode is specified. Contact us.
105 Failed in detecting threshold of the object. %m
Check image data (outer dimensions) or illumination
setting.
106 Your request for an image recheck cannot be granted. Your request for an image recheck cannot be granted.
107 Inapplicable unit or machine model is specified. Inapplicable unit or machine model is specified.
108 This function is currently not available. This function is currently not available.
109 Incorrect chain length.
110 Failed in labeling mask function.
111 Incorrect labeling area.
112 Failed in labeling fuction.
113 Angle over.
114
Compensation angle exceeded acceptable range. %m
Head%c1
Compensation angle exceeds 45 degrees. Check
component data/thickness/condition, illumination, and
camera.
115
Compensation angle exceeded acceptable range. %m
Head%c1
Compensation angle exceeds 20 degrees. Check
component data/thickness/condition, illumination, and
camera.
116
Detection result exceeds the acceptable range. %m
Head%c1
117 Failed in provisional positioning. %m Head%c1
The object could not be detected because a
disturbing image may come into the provisional
detection area or boarder between the object and the
background is not clear.
118 Failed in positioning. %m Head%c1
The object could not be detected because a
disturbing image may come into the provisional
detection area or boarder between the object and the
background is not clear.
119 Failed in provisional positioning. %m Head%c1
The object could not be detected because a
disturbing image may come into the provisional
detection area or boarder between the object and the
background is not clear.
120 Component data includes errors. %m Head%c1 Correct component data.
121 Failed in detection of component size. (magnification)
Check component data/thickness/condition,
illumination, and camera.
122 Internal Error 122 %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
123
Position or size of process area exceeds allowable
range. %m
Check component data/thickness/condition,
illumination, and camera.
124 Guide window does not fit into screen. %m Head%c1 Check multiple view assignment and specified camera.
125 Internal Error 125 Number of windows exceeds the limit. Contact us.
126 Number of registered models exceeds the limit. Max number of models per program is 100.
127 Model size is too large. Make model size smaller.
128 Model size is too small. Make model size larger.
129 Wrong head number is specified. Check head number.
130 No model data is found.
Model data that is not downloaded is specified .
Check image data.
134 Mark detection fails. Check illumination, gain/offset data, equipment.
135 Mark detection fails. Check illumination, gain/offset data, equipment.
136 Wrong camera number is specified. Check camera number.
138 Model data is destroyed. Re-acquire model.
139 Mark detection failed. Check mark coordinates or lower matching threshold.
140 Mark detection failed. Check mark coordinates or lower matching threshold.
141 Detection score is abnormal. Check mark coordinates or lower matching threshold.
142 Pattern matching failed. Check coordinates or lower matching threshold.
143 Edge detection failed. No part of the mark is found in search area.
144 Failed to detect a mark. Failed to detect a mark in pattern matching process.
146 Wrong order of offset capturing
147 Mark detection fails. Check illumination, gain/offset data, equipment.
148 Mark detection fails. Check illumination, gain/offset data, equipment.
149
Number of registered image data exceeds the limit.
%m Head%c1
Decrease the number of image data.
150 Wrong multiple view assignment %m Head%c1 Check image data or contact us.
151 Positioning fails. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
152 Lead detection failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
153 Lead detection failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
155
Result of lead-ends-distance detection for connector
exceeds allowable range. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
156
Lead pitch of measured component exceeds allowable
value. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
157
Lead pitch of measured component exceeds allowable
value. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
158 Gain and offset is not properly set. %m Head%c1
As the result of measurement, less number of leads
are found.
159 Lead count is less than set value. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
160 Lead count is less than set value. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
161 Component corner detection fails. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
162 BGA ball detection fails. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
163 Ball size exceed allowable range. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
164 Ball shape is not proper. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
165 Cannot handle the component. Contact us.
166 Inapplicable illumination is assigned. Contact us.
167 Pre-angle-designation fails.
Pre-rotation function is not available for the mount
angle.
168 Internal Error 168 Both sizes do not match in image copy. Contact us.
170 Designation of brightness measurement is wrong. Contact us.
172 Downloading of model data fails. Contact us.
173 Wrong setting for communication. Contact us.
174 Internal Error 174
Invalid communication command is received. Contact
us.
175 Communication fails. There is no valid packet. Contact us.
176 Communication fails. Timeout occurs during packet receiving. Contact us.
177 Communication fails.
Check-sum error occurred in received packet.
Contact us.
178 Received packet size error
179 Downloading of model data fails. Recapture model or contact us.
180 Downloading of model data fails. Recapture model or contact us.
181 Display mode designation error Window switching mode is wrong. Contact us.
182 Image recognition by camera fails. %m Head%c1 Continuous image capture is out of spec. Contact us.
183
Continuous component recognition by camera fails.
%m Head%c1
Check for valid head designation. Contact us.
184 Multiple-view process fails. %m Head%c1
Image acquisition fails or wrong assignment of result
display of multiple-view process. Contact us.
185 Image capture error
186 Chucking process failed. %m Head%c1 No vision target is found in chucking process.
187 Failed in positioning transistor. %m Head%c1
Disturbing image is shot in provisional positioning
area. Or no vision target is found.
188
Failed in positioning process for CPL process. %m
Head%c1
Check component data/thickness/condition,
illumination, and camera.
189 Failed to detect a circle. Candidate circle edges are not enough.
190 Reverse and Direction Check Error. Check image data/component condition
191 Failed in Bright Decision.
192 Edge search window exceeds limit.
200 Provisional positioning failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
201 Provisional positioning failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
202 Provisional positioning failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
203 Provisional positioning failed. %m Head%c1
Check component data/thickness/condition,
illumination, and camera.
