1172 Cannot create order to feed components. System error. Contact us immediately. 1173 MX-40 operation error Check MX-40 setting and conditions of MX-40B. 1128 Interlock error occurred between Z-axis of Head%c6 and Scan…

1127

(%d2-%d3)

Origin discrepancy between %c6%s dual axes %d1 <

Servomotors alarm at Head%c1 %s (alarm Error at servomotors or power source. Check the

1084

code:%d2(%d4) %e)

Servomotors alarm at %c1 %s (alarm code:%d2(%d4)

alarm code and contact us.

Error at servomotors or power source. Check the

1085

%e) alarm code and contact us.

Mark recognition for Camera coordinate correction

1086

cannot be performed. ( %s%c2 %c1 %m )

1087 The entrance sensor turns ON. Remove the PCB from the conveyor.

1088 Switched to Image Re-edit mode.

1089 The feeder is removed. %s %d1 %m

1090 EMG stop switch (software) is activated.

Head height cannot be changed when any nozzle is in

Detected EMG SW.

1091

the ANC.

Use only one nozzle.

1092 The tray direction is wrong. (Pallet-%d1)

An error occurred during Feeder Support Function. %s

Check the tray direction.

Check the pickup data, image data, and condition of

1093

: %d1 pickup point.

To restart the production, cancel the error and

1094 Conveyor width is changed.

Electrodes partly could not be recognized. %m

remove the PCB.

Component centering is performed only by the

1095

Head%c1

%c4 has been failed. (Head%c6%s Target %d1

recognizable electrodes.

Check for a dropped component beneath the head.

1096

Pushdown Stroke %d5 Feedback %d2 Tolerance %d3 Then resume production.

System is not functioning normally. Acquire the Log

1097 System failure is detected.

File and. contact us immediately.

1098 Drive phase error Contact us.

1099 Safety stop has been detected.

1100 System error Contact us.

1101 %s is open. Close the cover.

1102 Invalid program step number is specified. Correct Start Step and/or Repeat Offset Step.

1103 %s pallet stopper is open. Close the pallet stopper.

1104 Feeder setting error Check if the feeder's ready lamp (green) is on.

Error is found in the program or in libraries during a

1105 Data error is found in the program or in libraries.

job run. Contact us.

1106

1107

MX-20 pallet stopper is open.

Safety guard sensor responded.

Close the pallet stopper.

Remove the obstacle from the sensing area. If no

obstacle is present, clean the sensor and check the

sensor's wiring.

1108 Cancel process is interrupted. Recover the interrupted process by manual operation.

1109 Forcible immediate stop (debug mode)

1110 Servo motors are off. You can turn them on.

1111 Detected %s axis immediate stop signal. Remove the cause of the error (open cover, etc.).

1112 Executed immediate stop. Failed to execute cycle Current cycle is not complete.

1113 Timeout in completing the cycle stop Remove the cause of other provided errors.

1114 Cycle stop sequence error Remove the cause of other provided errors.

1115 Error in activating <Start> switch. Remove the cause of other provided errors.

Identify the cause of error and reset the machine

1116 Error in activating <Cancel> switch.

state using the Manual menus.

This error is caused by effect of other errors. Check

1117 Axes motion error

Dual axis following-up error (Y1axis %d1 Y2axis %d2

the other error messages near around.

Dual axis following-up error occurred. Check the

1118

Tolerance %d3)

%c6%s positioning timeout (Target %d1 Feedback %d2

movement of Y axes.

Timeout for completion of positioning occurred.

1119

Tolerance %d3) Check the system parameters for encoder input for

Software limit over is detected. Check the parameter

1120 %c5%c6%s Software limit over (Target%d1 Limit%d2)

setting.

1121

Interlock error occurred between Z-axis1 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1122

Interlock error occurred between Z-axis2 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1123

Interlock error occurred between Z-axis3 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1124

Interlock error occurred between Z-axis4 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1125

Interlock error occurred between Z-axis5 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1126

Interlock error occurred between Z-axis6 and Scan-

axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1172 Cannot create order to feed components. System error. Contact us immediately.

1173 MX-40 operation error Check MX-40 setting and conditions of MX-40B.

1128

Interlock error occurred between Z-axis of Head%c6

and Scan-axis (scan:%d1 %d2->%d3).

S-axis error. Check the machine state and contact

us.

1129

Origin discrepancy between y dual axes %d1 < (%d2-

%d3)

Origin sensor for Y2 axis may be troubled.

1130

Nozzle presence check upon ANC cannot be

Process is not properly performed. Contact us.

performed.

1131 Nozzle presence check on head cannot be performed. Process is not properly performed. Contact us.

1132 Image capture of fiducial mark cannot be performed. Process is not properly performed. Contact us.

1133

1134

Image capture of bad mark cannot be performed.

Image capture of component cannot be performed.

Process is not properly performed. Contact us.

1135

Nozzle specified in placement program is not

identified in nozzle ID recognition.

Check program and nozzle information.

1136

Error is found in program in recognition process for

Check placement program.

nozzle on head.

1137

1138

Error program data is found in fiducial mark process.

Error program data is found in bad mark process.

Check Fiducial in placement program.

Check Bad mark in placement program.

1139

Error program data is found in vision-processing

component.

Check component name in placement program and

component data.

1140

Failed to identify fiducial mark. %m %c4%c5 step

No.%d2 for repeat offset step No.%d3

Check the fiducial mark data.

1141

Failed to identify bad mark. %m %c4%c5 step No.%d2

Check the bad mark data.

for repeat offset step No.%d3

1142

1143

Cannot perform bring back detection.

Cannot capture an image in bring back detection.

Cannot perform Component remain check.

Cannot capture an image in Component remain check.

1144

Open %s was detected during axis movement in the

MANUAL mode.

Close the cover.

1145

The system switched to the MANUAL mode in the job

Place the system in the AUTO mode.

run.

1146

1147

Job run cannot be performed in the MANUAL mode.

%s is not set up.

Place the system in the AUTO mode.

Set up the CFB.

1148 No nozzle is set on the head. %s

No nozzle is set on the head which is specified for

fixed nozzle in the user parameter..

1149 Nozzle is set on the head. %s

Auto nozzle change in scanning nozzles is prohibited.

1150 Nozzle Information includes errors. %s

Manually return the nozzle(s) to ANC.

Redo ANC scanning.

1151

Nozzles in heads and Nozzle Information contradict. Check nozzle setting. Contact us for ANC scanning

%s error.

1152 ANC slide channel operation timeout. %s Actuate ANC slide channel in Manual>Actuator.

1153 Required nozzle isn't found in ANC. %s Set required nozzle in ANC.

1154

1155

No available nozzle station. %s

No PCB fed from pre-process machine (SMEMA).

Check ANC.

Check interface setting of pre-process conveyor.

1156

Entrance sensor gets ON without input of machine-

not-ready signal (SMEMA).

Check interface setting of pre-process conveyor.

1157

Axis status mismatch.(X:%d1 %d2->%d3 Y:%d4 %d5- Obtain log data by clicking the <LOG> button and

1158

>%d6 [%d8])

Fluid shortage on Head%c1.

1159

Board jams between exit of pre-process and arrival

sensor.

Check conveyor belts and conveyor motors.

1160

Board jams between exit of pre-process and buffer

Check conveyor belts and conveyor motors.

1161

sensor.

Board jams between buffer sensor and arrival sensor. Check conveyor belts and conveyor motors.

1162

Board jams between arrival sensor and entrance of

post-process.

Check conveyor belts and conveyor motors.

1163 Main clamp error

Check support pins and adjust plate for foreign

obstacles.

1164

1165

Side clamp error

Rear clamp error

Check side clamp for foreign matter.

Check rear clamp for its set position.

1166 Board stopper error

Actuate board stopper in manual menu

(Actuator/LoadBoard).

1167 Conveyor error

Check conveyor belts and associated

sensors/cylinders.

1168 Machine-not-ready signal does not turn OFF. Check interface setting of pre-process conveyor.

1169

1170

Machine-not-ready signal does not turn OFF.

The syringe is not set on Head%c1.

Check interface setting of post-process conveyor.

Check the syringe for the head.

1171 Fluid shortage warning sensor error on Head%c1.

Check the fluid shortage warning sensor and the

syringe.

1248

Halt of message output: %d1times. System time: %d2.

Halted time: %d3 seconds.

Message buffer is full, and message is paused.

1174 Shuttle of MX40 contacts with conveyor rail.

Check conveyor rail position against board Y at Board

1175 MX-20 operation error (Pallet-%d1)

menu.

Check MX-20 setting and conditions of MX-20F.

1176 MX-20's shuttle interferes with conveyor rail.

Compare conveyor rail position with

BoardData>BoardSize(Y).

1177 PCB is on the conveyor. Cannot adjust conveyor Remove the PCB from the conveyor.

1178

1179

Detected support pins under the conveyor rail.

LIM unit error.

Reject conveyor %s %d1 is full. Remove components

Remove the support pins under the conveyor rail.

Check the component ID. Check the LIM unit.

Remove components from Reject Conveyor and keep

1180

and press RESET switch. Then press START switch.

pressing TRANSFER/RESET switch for 3 seconds.

Then press START switch.

1181

Interlock against interference between Z-axis1 and %s

worked (Travel height:%d1 X:%d2 Y:%d3).
