1709 Specified illumination level is set. 1710 Model data is acquired. Model data is stored in file. 1711 Model centering Center of F mark is detected, where camera moves. 1622 PCB through ends. 1623 Run ends. 1624 start…

1619 Teaching ends.

1620 Manual ends.

1621 Origin detection ends.

1573 PCB Vacuum Error. Check PCB Vacuum for error.

1574

MX-20 Relay Hook Retract End Sensor Off (Pallet-

Check conditions of MX-20.

1575

%d1)

Start %s (%d1,%d2,%d3,%d4,%d5,%d6,%d7,%d8)

1576 End %s (Total:%d1 NG:%d2 Time:%d3.%d4sec)

1577

Error is detected on %s-%d1(Count:%d1 NG

Count:%d2Code:%d3 ID:%d4-%d5)

1578

1579

Skip %s %d1 times.(NG:%d2 Time:%d3.%d4sec)

Communication error happened between Mounter

Check the ID Database Server and LAN condition.

1580

and Feeder ID Database.(%d1<%d2msec)

Feeder position error. %s-%d1 -> %c4-%d5 %m" Feeder set position is wrong. Relocate it to the

1581

ID:%d2-%d3"

Feeder position error. %s-%d1 -> %c4-%d5 %m"

specified.

Feeder set position is wrong. Relocate it to the

ID:%d2-%d3" specified.

1582 Set position: %s-%d <- %m""

Remove the feeder from the specified station and set

the component.

1583

1584

Set position: %s-%d <- %m""

Component %m" has already been set."

Set the component to the specified station.

This component has already been set.

1585

1586

Component %m" is not used for this production."

Lead/Ball Height deviation is out of tolerance.

This component is not used for this production.

Check Lead/Ball floating condition and Lead/Ball

1587

Head%c1 %m

Lead/Ball Position XY deviation is out of tolerance.

Height Tolerance value.

Check Lead/Ball bending condition and Lead/Ball

1588

Head%c1 %m

No Lead/Ball-like object is found in measuring image.

pos. XY Tolerance value.

Check component data/thickness/condition.

1589

Head%c1 %m

Component image is out of measuring image range.

Check component data/thickness/condition.

1590

Head%c1 %m

Measured position of Lead/Ball markedly differs from

the setting of component data. Head%c1 %m

Check component data/thickness/condition.

1591

Lead/Ball is missing at predetermined location.

Head%c1 %m

Check Lead/Ball condition and settings of Component

Feature, Darkness level, Lead/Ball Pitch, and

1592

Tilt amount of Reference Surface is out of tolerance.

Lead/Ball Width in Coplanarity Check data.

Check component tilt condition and value of Tilt

1593

Head%c1 %m

Coplanarity Check Error occurred. Head%c1 %m

Tolerance of Ref. Surface in Coplanarity Check data.

Check component data/thickness/condition. Refer to

Error Code List for details.

1594 Fails to perform Coplanarity Check.

Check Coplanarity Check Unit and Communication

1595 Fails to capture the image at Coplanarity Check.

cables for any abnormal conditions.

Process is not properly performed. Contact us.

1596

1597

Fails to acquire the result at Coplanarity Check.

The head cannot reach a nozzle.

Process is not properly performed. Contact us.

Change a pickup head or the nozzle position. Or

enable the Automatic Nozzle Arrangement.

1598

Exceeded the maximum correction value. %s(X:%d1 Check that the maximum correction value is set

Y:%d2 T:%d3) Head%c4 %m properly.

1599 Improper component feeding %s #%d1 Head%c2 Stop operation and check feeding conditions.

1600 Processing ends. (servo motor off)

1601 Edition in pause.

1602 Teaching is possible. Perform operation safely. Each axis operates in safety speed.

1603 Manual is possible. Perform operation safely. Caution: Z axis does not move in safe height.

1604 Ready (Alarm off and recovery possible)

1605 Pause (Cancel or start possible)

1606 Run (Press cycle stop for stop and cancel for end)

1607

1608

Drive OFF

Maintenance possible.

Drive ON possible

Servo off for operation

1609 Alarm of servo/DC motor %s Check servo unit.

1610 Servo of caused by emergency stop

Emergency stop is pressed. System detects trouble

automatically.

1611 Wait until origins are taken. Each axis is taking its origin.

1612 Wait until movement ends.

Axis moves to specified coordinates. Press

emergency stop switch to stop movement.

1613 Load board

1614 starting signal is accepted. Data for run is collected.

1615 Run-starting-signal is accepted. Data for run is collected.

1616 Quit the system. Power is automatically turned off.

1617 Performance record is collected. Performance record is written on management data

1618 is saved. Data is saved on file. Use to prevent mis-saving.

1709 Specified illumination level is set.

1710 Model data is acquired. Model data is stored in file.

1711 Model centering Center of F mark is detected, where camera moves.

1622 PCB through ends.

1623 Run ends.

1624 starts.

1625 ends.

1626 ended without completing the job.

1627 MMI MSG

1628 MMI MSG

1629 Job run ended without completing the job.

1630 Job run ended without completing the job.

1631 Start warm-up

1632 End warm-up

1633 Start warm-up for the specified item.

1634 End warm-up for the specified item.

1635 Producible PCB count has reached the alarm setting. Replenish components.

1636

1637 Pause the current job and enter Edit&Teach mode.

(clear signal tower of 1635)

1638 Exit Edit&Teach mode and resume the current job.

Contact failure of CPU and CPU controller board.

1639 Failed to load the controller program. [%d1]

Check the contact of each board.

1640

1641

execute ends.

Instantaneous power failure is detected.

1642 Pause (Cancel or start possible)

The UPS does not operate normally. Contact i-

1643 The control board is not adapted to the system.

PULSE local distributor.

1644 Feeders setup are verified.

1650 Operational switch is pressed.

1651 System condition changes.

1656 System condition changes.

1659 Prearrange process starts.

1660 MX Info. starts.

1661 Nozzle ID recognition starts.

1662 Nozzle change starts.

1663 Prearrange process ends.

1664 MX Info. ends.

1665 Nozzle ID recognition ends.

1666 Nozzle change ends.

1667 Nozzle ID manual setting ends.

1668 Nozzle ID recognition ends without completing the

1669 Nozzle change ends without completing the job.

1670

1671

%c1 MMI MSG

1672 Fiducial mark coordinates have been obtained.

Coordinates have been obtained without fiducial

1673

correction.

1680 User parameter is saved. Data is saved on file. Use to prevent mis-saving.

1681 System parameter is saved. Data is saved on file. Use to prevent mis-saving.

1682 Component library is saved. Data is saved on file. Use to prevent mis-saving.

1683 Image library is saved. Data is saved on file. Use to prevent mis-saving.

1684 Feeder library is saved. Data is saved on file. Use to prevent mis-saving.

1685 Pallet library is saved. Data is saved on file. Use to prevent mis-saving.

1686 Packaging library is saved. Data is saved on file. Use to prevent mis-saving.

1687 Tray library is saved. Data is saved on file. Use to prevent mis-saving.

1688 Nozzle library is saved. Data is saved on file. Use to prevent mis-saving.

1689 Dispense library is saved. Data is saved on file. Use to prevent mis-saving.

1690 Syringe library is saved. Data is saved on file. Use to prevent mis-saving.

1691 Dispense Nozzle library is saved. Data is saved on file. Use to prevent mis-saving.

1692 Production plan is updated. Data is saved on file. Use to prevent mis-saving.

1701 Camera change

1702 Image mode change

1703 Image test is performed. Image test is performed. Warning; any axis may move.

1704 Guide frame display command

1705

1706

Camera center cross line

ADA is performed. ADA(Automatic Data Acquisition) is performed.

1707 Multi-view image test result is displayed.

Component (except chip) size is automatically

1708 ADA is performed.

measured.

1838 X of ST(R) exceeds moveable range.

data.

1839 Y of ST(R) exceeds moveable range.

Check Y offset in pickup data and Y offset in Feeder

data.

1712 Model data is displayed. Acquired model image is displayed.

1713 Resolution is measured.

1714 Camera brightness is measured.

1715 Camera tilt is measured.

1716 T-axis center is measured.

1717 Focus is taken.

1718 VCS is requested.

1719 Version No. is acquired.

1720 Packet loop back is requested.

1721 Communication speed changes.

1722 All device & model data are deleted.

1723 Specified device data is deleted.

1724 Specified model data is deleted.

1725 Specified resolution data is deleted.

1726 All device data is sent.

1727 Device data is sent.

1728 Model data is sent.

1729 Gain/offset of camera is sent.

1730 Model data is received.

1731

1732

Detailed result of Image processing is sent.

Resolution data is backed up.

1733 Resolution data is restored.

System automatically resets vision system to cancel

1734 Reset is required.

error.

1735 Cancel is required.

1736 Head offset (S axis) is sent.

1737 Image test is completed.

1738 ADA is completed.

1800 No header file is found. Save data in Data Edit window.

1801 No board data is found. Save data in Data Edit window.

1802 No placement data is found. Save data in Data Edit window.

1803 No pickup data is found. Save data in Data Edit window.

1804 Header file is abnormal. Save data in Data Edit window.

1805 Board data file is abnormal. Save data in Data Edit window.

1806 Placement data file is abnormal. Save data in Data Edit window.

1807 Pickup data file is abnormal. Save data in Data Edit window.

1808 No component file is found. Save data in Component Library window.

1809 No feeder library is found. Save data in Feeder Library window.

1810 No packaging library is found. Save data in Packaging Library window.

1811 No nozzle ID is found. Perform automatic nozzle ID recognition.

1812 No pallet library is found. Save data in Pallet Library window.

1813 No tray library is found. Save data in Tray Library window.

1814 Component library is abnormal. Save data in Component Library window.

1815 Feeder library file is abnormal. Save data in Feeder Library window.

1816 Packaging library is abnormal. Save data in Packaging Library window.

1817 Nozzle library file is abnormal. Save data in Nozzle Library window.

1818

1819

Pallet library file is abnormal.

Tray library file is abnormal.

Save data in Pallet Library window.

Save data in Tray Library window.

1820 Image library file is abnormal. Save data in Image Library window.

Check task setting of Start block placement and End

1829 Task setting for repeat program is wrong.

block placement.

Check task setting og Multiple pickup and End

1830 Multiple pickup assignment is wrong.

multiple pickup.

The same head cannot be specified in a multiple

1831 Head specification is wrong in multiple pickup.

pickup block.

1832

Multiple pickup steps in a cycle exceeds the number

of heads.

Check the number of steps in the multiple pickup

cycle.

1833 Theta of ST(F) exceeds +/-180.00 deg. Theta must be within +/-180.00 deg.

Check X offset in pickup data and X offset in Tape

1834 X of ST(F) exceeds moveable range.

feeder data.

Check Y offset in pickup data and Y offset in Tape

1835 Y of ST(F) exceeds moveable range.

feeder data.

1836 Z of ST(F) exceeds moveable range.

Check Z offset in pickup data and Thickness in

Component data.

1837 Theta of ST(R) exceeds +/-180.00 deg. Theta must be within +/-180.00 deg.

Check X offset in pickup data and X offset in Feeder
